Gastronorm trolleys, low
execution, with work top
Manufacturer:
Model:
No. of article:
HUPFER®
RWG / 7
0112445
Dimensions
Width:
Depth:
Height:
664 mm
744 mm
854 mm
Execution
Structure
Gastronorm trolleys made from stainless steel,
25 x 25 mm, with 7 pairs of solidly welded U-shaped
insert rails to be fed with GN 1/1 – 65 containers and
their partitions, rail distance amounts 75 mm. Tipping
and push-through protection device according to DIN
18867-2.
Upper top made from sheet metal, 1,0 mm thick,
folded by 40 mm at all sides, with sound isolating
lining, useful as work top.
Chassis
4 castors, 2 of them with total clamps, in a corrosion
resistant and maintenance-free, galvanised chromated
housing, with slide bearing, Ø 125 mm, dimensions
according to DIN 18867, part 8.
Bumpers at the chassis protect against damage by
touching the wall.
Technical Data
Number of partitions:
Dimension of insert:
Direction of loading:
Further dimensions of insert:
Number of supporting pairs:
Capacity:
Load capacity per castor:
Net weight of the trolley:
Load capacity of the trolley:
1
GN 1/1
transversal loading
GN 2/1, GN 2/4
7
14 x GN 1/1 or
7 x GN 2/1 or
28 x GN 2/4
100 kg
16 kg
85 kg
