Standards
Why Emergency Lighting
● In case of event which make a power cut, Emergency Lighting must
provide enough light in order to:
Guarantee clear marking
of emergency exits
Facilitate the safe
evacuation of people
Help to localise fire alarm
and first aid devices
Schneider Electric - Division - Nom – Date
Guarantee a minimum
light level to avoid panic
by occupants and enable
activities to continue
2
Synthesis of EN standard
● Market hold by EN regulation and possible local deviation:
● Chance to pull up market (technology / price) connected to safety market
● Schneider Electric is fully aligned with this approach.
> EN 1838
> EN 60598-2-22
> EN 50172
For the E.Lighting
For the E.Lighting
For the E.Lighting
applications rules
product design
maintenance and
test procedures
Schneider Electric - Division - Nom – Date
3
EN Standard
EN 1838: Application rules
Schneider Electric - Division - Nom – Date
4
EN1838: Application rules
EN1838
Emergency
lighting
Safety lighting for
escape routes
Schneider Electric - Division - Nom – Date
Anti-Panic area
High risk area
Lighting
5
EN1838: Application rules
Types of applications
●
3 sub-categories for Safety Lighting:
Escape
routes
> Facilitate
the evacuation
of buildings
> To help the
emergency
services
Anti-panic
> To keep
people quiet
Schneider Electric - Division - Nom – Date
High risk
area
> To avoid
accidents
especially
in production
plants, building
construction...
6
EN1838: Application rules
Escape route
● Standard EN 1838 says:
● If Escape routes wider up to 2 m, luminaries must be
installed to ensure a minimum level of lighting (1 lux)
on the floor along the central line of the escape route.
Schneider Electric - Division - Nom – Date
7
EN1838: Application rules
Anti-panic area
● Standard EN 1838 says:
● For anti-panic area, luminaries must be installed to ensure
a minimum level of lighting on the floor until 0.5 m from
the wall.
Schneider Electric - Division - Nom – Date
8
EN1838: Application rules
Example 1/3
● Example of Escape Route and Anti-panic area
Escape Routes
Anti-panic
Schneider Electric - Division - Nom – Date
Escape Routes
Escape Routes
Anti-panic
9
EN1838: Application rules
Example 2/3
● Example of Escape Route and Anti-panic area
Escape Routes
Schneider Electric - Division - Nom – Date
Anti-panic
10
EN1838: Application rules
Example 3/3
● Example of High Risk Area: Production Plants, workshops
Chemical process
Schneider Electric - Division - Nom – Date
11
EN1838: Application rules
Photometric rules
● Lumen:
lighting flux unit
or lighting power
● Lux:
flux received per unit
area of the illuminated
element.
1 lux = 1 lumen / 1 m²
Schneider Electric - Division - Nom – Date
Different level
Midday on a sunny day
A sunny afternoon
Overcast sky
Top of a TV
Counter in a department store
Railway ticket office
Underground station platform
Apartment; domestic light
A well-lit street at night
Light from a candle 10 cm away
Full moon
50,000 to 100,000 lux
35,000 lux
32,000 lux
800 to 1600 lux
500 to 700 lux
650 lux
300 lux
100 to 300 lux
20 to 100 lux
10 lux
0.1 to 1 lux
12
EN1838: Application rules
Parameters - Lighting level
● On the floor level:
Escape
routes
Anti-panic
> 0.5 lux
> 1 lux
High risk
area
> 15 lux
0m
Schneider Electric - Division - Nom – Date
13
EN1838: Application rules
Exit indication
Schneider Electric - Division - Nom – Date
14
EN1838: Application rules
Parameters - Safety signalling
● d: observation distance
● p: pictogram height
● s: 100 for signs externally lluminated 200
for signs self-illuminated
d=sxp
p
d
Schneider Electric - Division - Nom – Date
15
EN1838: Application rules
Parameters - Safety signalling
● Internally illumated signs
Schneider Electric - Division - Nom – Date
● Externally illumated signs
16
EN1838: Application rules
Luminescence measurement of the signs
Luminescence ratio between the
2 colours at a distance of 15 mm
compared to the separation line
of the 2 colours
Frame 10 mm not included
in the measurement
Sign luminescence
Schneider Electric - Division - Nom – Date
Background luminescence
17
EN1838: Application rules
Location
of the luminaires
Schneider Electric - Division - Nom – Date
18
EN1838: Application rules
Location of the luminaires
● At each Door
Schneider Electric - Division - Nom – Date
19
EN1838: Application rules
Location of the luminaires
● Signs are required whenever the direction of escape is ambiguous
Schneider Electric - Division - Nom – Date
20
EN1838: Application rules
Location of the luminaires
● Near changes of direction
Schneider Electric - Division - Nom – Date
21
EN1838: Application rules
Location of the luminaires
● Near each flight of stairs
Schneider Electric - Division - Nom – Date
22
EN1838: Application rules
Location of the luminaires
● At each change of floor level
Schneider Electric - Division - Nom – Date
23
EN1838: Application rules
Location of the luminaires
● Near each intersection
Schneider Electric - Division - Nom – Date
24
EN1838: Application rules
Location of the luminaires
● Near each Fire Alarm call point - fire fighting equipment
Schneider Electric - Division - Nom – Date
25
EN1838: Application rules
Location of the luminaires
● Near first aid posts
● But:
● First Aide Site, Fire fighting equipment and call points
should be more lighted than escape route, when not
located on an escape route not located on an escape
route or in an anti-panic area.
Schneider Electric - Division - Nom – Date
26
EN1838: Application rules
Location of the luminaires
● Over High Danger Areas
Schneider Electric - Division - Nom – Date
27
EN1838: Application rules
Location of the luminaires
● Over Technical Areas
Schneider Electric - Division - Nom – Date
28
EN1838: Application rules
Location of the luminaires
● Outside each final exit
Schneider Electric - Division - Nom – Date
29
EN1838: Application rules
Anti-panic
Escape Route
> Provide a minimum lighting level to avoid
panic
0.5 Lux
> Signalisation of the way out
d=sxh
0.5 Lux
1 Lux
0.5 Lux
Schneider Electric - Division - Nom – Date
0.5 Lux
30
EN1838: Application rules
Anti-panic
Schneider Electric - Division - Nom – Date
Escape Route
31
What type of product to be used
depending on the need:
● Anti-panic area
Luminance to provide the right
luminous flux at the ground level
● Criteria:
● Height of the ceiling
(impact on the needful
flux).
● Surface of the area
(impact on nb
of luminaires
to be installed).
Schneider Electric - Division - Nom – Date
32
What type of product to be used
depending on the need:
● Escape Route
Luminance to provide
the right luminous flux
at the ground level
Visibility distance to
indicate efficiently
the route of escape
● Criteria:
● Height of the ceiling
(Flux of the product).
● Dimension of the screen
(impact on nb of
luminaires to be installed).
Schneider Electric - Division - Nom – Date
33
EN1838: Application rules
Distance between E.Lighting blocks
● Influent parameters
● Safety Lighting
● It depends of the
luminaire (shape,
composition, flux…)
● Location of the product
1 lux
1 lux min. on
Floor level
Escape Route
● Height over the floor,
the mounting: wall,
ceiling, axes positioning
● The level of light required
● 1 lux, 0.5 lux, 15 lux…
Schneider Electric - Division - Nom – Date
Transverse
Spacing
to Wall
Transverse Spacing
Between Luminaires
34
EN1838: Application rules
Distance between E.Lighting blocks
● Spacing Tables
● For each products exits a table which defines whether fittings are needed
in addition to those required for the points of emphasis.
Escape routes 1 lux min. along centre line
Open (Anti-panic) Areas 0.5 lux min.
luminaires arranged in a regular array
Ceiling
Transverse
mounting to wall
Height (m)
Transverse
spacing
Axial
to wall
Axial
spacing
Transverse
to wall
Transverse
spacing
Axial
to wall
Axial
spacing
2.5
1.8
5.6
1.5
4.7
2.1
5.6
1.7
4.6
3
1.5
5.5
1.2
4.6
2.0
5.8
1.7
4.8
4
-
-
-
-
1.7
5.8
1.5
4.9
5
-
-
-
-
0.8
5.4
0.6
4.6
Schneider Electric - Division - Nom – Date
35
EN Standard
EN 50172:
rules for maintenances
Schneider Electric - Division - Nom – Date
37
Maintenance rules EN 50172
● EN 50172 Periodic Maintenance & test records
Series of procedures to keep the safety lighting system working efficiently
●Daily
●Monthly
●Make a daily
check of the
energy source
power supply
indicators.
Schneider Electric - Division - Nom – Date
●Make a test of
the luminaires,
simulating failure of
the standard power
supply for enough
time to allow
verification of the
start-up of the
lighting devices
and signs.
●Annually
●Make a
duration test
on each lighting
and sign
luminaires
simulating loss
in standard
power supply for
sufficient time.
●System
failures Should
have be
recorded
on a register
38
