STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
Critical Materials short presentation (who are we?)
3
PRODDIA® Wind arguments (why Proddia®?)
7
Technical information (how it works?)
10
Case study – rotor blade (over request)
2
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
CRITICAL GROUP
© 2010 Critical Materials
Critical Links
New Jersey, USA
Critical Links
Coimbra, PT
Critical Materials
Guimarães, PT
Critical Health
Coimbra, PT
Critical
Manufacturing
OPorto, PT
Critical Software
PT, UK, USA,
RO, BR, MOZ
Critical
Manufacturing
Regensburg, DE
Critical
Manufacturing
Suzhou, China
3
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
VISION & MISSION
VISION
Self-healing bio-inspired materials will revolutionize the
design and maintenance of long lasting equipment.
Critical Materials will be a technology provider
for the “nervous system and bio-brain” of critical
applications of advanced materials.
© 2010 Critical Materials
MISSION
To Provide Technology and Efficient Products
for Diagnosis and Prognosis of Critical
Applications of Advanced Material Systems
4
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
CORE
CMT is focused on the continuous
evaluation of the material condition
and on the structural integrity of
critical components.
Aeronautics,
Defense &
Space
© 2010 Critical Materials
Wind
Offshore
PRODDIA® looks beyond the
traditional CBM and SHM solutions!
5
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
PRODDIA® IS AN ADVANCED SHM
SOLUTION. BUILT INTO ONE
INTEGRATED SENSORS & SOFTWARE
TOOL.
PRODDIA® focus on the continuous
evaluation of the material condition
and on the structural integrity of
critical components.
PRODDIA® looks beyond the traditional
SHM solutions featuring:
•
© 2010 Critical Materials
•
•
•
A USER FRIENDLY GRAPHICAL
USER INTERFACE,
AN INNOVATIVE CONDITION
ASSESSMENT TECHNOLOGY allowing accurate damage
diagnostics & prognostics,
A LOW-DENSITY SENSOR
NETWORK
AN INTEGRATED
MANAGEMENT SOLUTION.
6
© 2010 Critical Materials
WHY PRODDIA?
7
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
MAINTENANCE PROBLEM (€)
In WTG farms (specially offshore) the
costs for maintenance are high, being
dominated by unexpected severe failures
leading to reactive maintenance. The
costs of downtime (among others..)
drive the need for condition monitoring.
Cost variables:
- Downtime
- Expensive material savings
- Unexpected maintenance costs
- Inspection costs (planned)
© 2010 Critical Materials
It seems to be clear: We badly need BLADE CMS to predict blade
failure. We need indication of upcoming blade structural degradation in
order to launch proactive maintenance or repair process.
Linkedin, Wolfang Holstein, Jan 2012
David Brown’s research emphasizes that reactive maintenance for the
average utility-scale wind farm can cost $1.5million more – each year –
than preventative maintenance.
Linkedin, Jon Hartman, Jan 2012
8
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
PRODDIA™ CONTRIBUTION
INCREASE ASSET AVAILABILITY
•
EXTEND ASSET LIFETIME (“small defects remain small”)
•
SIGNIFICANT REDUCTION OF O&M COSTS
© 2010 Critical Materials
•
•
•
•
•
Management of dispersed and distant assets
Integrated planning of inspection and maintenance operations
Planning operations based on weather forecasts
Optimization of intervention times, travels and resources
9
© 2010 Critical Materials
HOW IT WORKS?
10
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
© 2010 Critical Materials
PRODDIA® WIND IS COMPOSED BY 2 SUB-SYSTEMS
the ON-SYSTEM DATA
and the PRODDIA®
ACQUISITION and
SOFTWARE WORKBENCH
SENSOR NETWORK
11
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
PRODDIA® WIND IN 5 SINGLE STEPS
© 2010 Critical Materials
Real data
collection
Sensor
study and
placement
Calculation
(data and
structure
assessment)
Customized
information to
maintenance
“Baseline”
definition
(initial set-up
and
adjustments)
12
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
PRODDIA® WIND STRUCTURAL SYSTEMS ARCHITECTURE
FARM
STRUCTURAL SYSTEM
SUB-SYSTEM
COMPONENT
Blade
Rotor
Hub
turbine
Gearbox
Shafts
Bearings
...
nacelle
© 2010 Critical Materials
Tower
...
tower
Foundations/
footing
Jacket
Pillars
...
13
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
© 2010 Critical Materials
PRODDIA® WIND SOFTWARE WORKBENCH
14
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
PRODDIA® WIND CAPABILITIES
DAMAGE DIAGNOSTIC
•
•
•
DETECTION AND LOCALIZATION OF DAMAGED
COMPONENTS
EVALUATION OF DAMAGE SEVERITY
ASSESSMENT OF CONTINUOUS MATERIAL
PROPERTY DEGRADATION (AGING)
STATE PROGNOSTIC
© 2010 Critical Materials
•
•
•
•
FORECASTING OF THE FUTURE COMPONENT STATE
CALCULATION OF THE REMAINING USEFULL LIFE, RUL
PREDICTION OF COMPONENT BEHAVIOUR UNDER LOADING
PROBABLISTIC UPDATING OF COMPONENT BEHAVIOUR
INTEGRATION WITH OTHER TOOLS
•
•
•
INSPECTION AND MAINTENANCE
LOGISTICS AND PLANNING
ASSET AVAILABILITY AND COSTS
15
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
PROTOTYPE – POSEIDON – www.poseidonorgan.com
SHM system for Offshore Power Plant
Detection of damage
•
Localization & Severity Evaluation
•
Early warning alarms
•
Inspections on predictive information
© 2010 Critical Materials
•
16
STRUCTURAL
SYSTEMS
HEALTH
MANAGEMENT
CRITICAL MATERIALS, SA
Critical Materials S.A.
HTC – Headquarters and Technical Centre
SPINPARK - Centro de Incubação de Base Tecnológica
AVEPARK - Zona Industrial da Gandra | Apartado 4152
4806-909 Caldas das Taipas
Guimarães – Portugal
UK
Critical Materials SA
2 Venture Road
Southampton Science Park
Southampton SO16 7NP, UK
© 2010 Critical Materials
t +351 253 421 032
f +351 253 421 033
e info-materials@critical-materials.com
BRASIL
Critical Materials SA
S. José dos Campos
S. Paulo, Brasil
