IGEL Technology is now shipping the first evaluation units of its new
UD2-LX MultiMedia – a compact and cost-effective system-on-chip (SoC)
thin client for virtualized desktops and Server Based Computing environments.
IGEL Technology |
Andreas Buis, Software Engineer | Page 1
Update webinar
UD2-LX MultiMedia
ARM / Firmware 1.01.500.01
Andreas Buis
Systems Engineer
How to use the webinar - Questions
IGEL Technology | <Topic>, <Month> <Year>
<First Name> <Last Name>, <Position> | Page 3
Agenda
Basic Information
SoC & DSP
Evaluation device
Citrix, Remote FX & Vmware View
Smartcard
Usage scenario
IGEL SoC Thin Client
Hardware specification:
–
–
–
–
–
–
–
–
–
Texas Instruments DM8148 board
Cortex A8 processor 1 GHz
DSP C674x for protocol acceleration
Good power/performance ratio (7W idle)
Dual monitor support through DVI-I with
maximum resolution of 1920x1200
Audio In/Out
4x USB Ports
1 GB DDR3 RAM on board
2GB NAND-Flash on board
IGEL Technology |
Andreas Buis, Software Engineer | Page 5
UD2-LX MultiMedia Software
►
►
►
►
IGEL Linux base system
Fully manageable through IGEL UMS
Keeps up look and feel of an IGEL Linux
desktop
Integration of DSP acceleration
infrastructure
IGEL Technology |
Andreas Buis, Software Engineer | Page 6
UD2-LX MultiMedia DSP optimizations
General Purpose
Special Tasks
RDP Client
RemoteFX
Decoder
WMV
H264
MPEG4
MediaDecoder
Decoder
Player
Citrix
HDX Receiver
Decoder
ARM CPU
DSP
SoC
IGEL Technology |
Andreas Buis, Software Engineer | Page 7
UD2-LX MultiMedia SoC device
►
►
Based on the ARM SoC development efforts
Software features
Feature
DSP accelerated
Citrix Receiver (XenApp/XenDesktop)
Optimized
Microsoft RDP/RemoteFX
Optimized
VMware View (RDP/PCoIP)
Mozilla Firefox Browser
Local media player (HD)
IGEL Technology |
Optimized
Andreas Buis, Software Engineer | Page 8
Why choose multiprotocol SoC devices
►
►
►
►
Thin Clients have a up to 7 years lifetime
IT infrastructure changes (not stuck in a one
way technology)
Changes in the backend infrastructure can be
handled easily
Always use the best protocol for your requirements
Requirements to the Thin Client change with
company‘s growth
No need to use different types of devices and
management approaches
all devices can be managed through UMS
IGEL Technology |
Andreas Buis, Software Engineer | Page 9
UD2-LX MULTIMEDIA
Evaluation device
Evaluation device (Firmware 1.01.500.01)
►
Available since 29.06.2012
►
Is not for Sale only for evaluation
This firmware has got some limitations which are only applied to
the current evaluation device. During the evaluation phase regular
updates are planned to address these limitations.
►
The final version of the UD2-LX MultiMedia is available at the end of
Q3 or the beginning of Q4 this year.
IGEL Technology |
Andreas Buis, Software Engineer | Page 11
First step: NTP
►
System time needs to be set either through NTP or manually after
initial boot up (Setup > System > Time and Date)
Evaluation device
IGEL Technology |
Andreas Buis, Software Engineer | Page 12
IGEL UD look & feel
Evaluation device
IGEL Technology |
Andreas Buis, Software Engineer | Page 13
Acceleration: Remote FX OR Citrix ICA?
►
To use the ARM for Remote FX OR Citrix ICA it must be selected in
the IGEL „Application Launcher / DSP-Chooser“
Evaluation device
IGEL Technology |
Andreas Buis, Software Engineer | Page 14
Citrix Receiver
DSP
accelerated
ICA
Multimedia
Redirection
USB
Redirection
XenDesktop
Citrix
Reciver
Smartcard
Authentication
XenApp/
PNA
Flash
Redirection
IGEL Technology |
Accelerated Citrix ICA works
only in a single display
environment
Andreas Buis, Software Engineer | Page 15
RDP/RemoteFX Client Version: 1.6.0
USB
Redirection
DSP
accelerated
RemoteFX
support
RemoteApps
Support
IGEL Technology |
Multimedia
Redirection
Remote
FX
Smartcard
Authentication
Andreas Buis, Software Engineer | Page 16
Remote FX - dual display
►
dual display support is limited to use only the same resolution and
orientation with both screens.
Evaluation device
IGEL Technology |
Andreas Buis, Software Engineer | Page 17
VMware View
►
►
View client is currently not accelerated
Version 1.5.0
USB Redirection
RDP
Smartcard Authentication
DSP accelerated PCoIP support
PCoIP
Note: Currently we only integrated the standard VMware View client which
only provides limited acceleration through the SoC architecture.
Evaluation device
IGEL Technology |
Andreas Buis, Software Engineer | Page 18
Print Services
►
Line Printer (LPD)
►
Internet Printing Protocol (IPP)
►
Printer Support with CUPS
►
ThinPrint .print
►
TCP/IP printing server
IGEL Technology |
Andreas Buis, Software Engineer | Page 19
Smartcard Support (HW)
(no memory card support)
►
Omnikey
►
Reiner SCT
►
Aladin e-token
►
SCM Microsystem
►
Gemalto gempc twin
IGEL Technology |
(opensource driver, no eHealth
support)
Andreas Buis, Software Engineer | Page 20
Smartcard Support (at local device)
►
►
►
►
►
►
IGEL Smartcard
A.E.T. Safesign
Gemalto .NET
Aladin e-token
SecMaker NetID
IGEL License Smartcard
Note:
• Citrix session roaming does not work.
• No smartcard support for local browser sessions.
IGEL Technology |
Andreas Buis, Software Engineer | Page 21
Dutch
English
German
Chinese (Mandarin)
French
Internationalisation: language support
Dictation Support
►
Grundig
►
Olympus
►
Philips
IGEL Technology |
Andreas Buis, Software Engineer | Page 23
IGEL Software Features
►
►
►
►
►
►
►
►
►
►
►
Shared Workplace
Universal Multi Display
Custom Partition
Buddy Update (ARM Master only)
USB access control
Shadowing
Dual View
Custom Scripts
Custom Boot Splash
(no fullscreen support)
Custom Wallpaper
Boot Menu
IGEL Technology |
Andreas Buis, Software Engineer | Page 24
Usage scenario
►
►
►
Local multimedia playback  full screen HD videos supported
Usage of accelerated protocols:
– Citrix XenApp/XenDesktop
– Microsoft RemoteFX
Fits best where a good user experience is needed, but
– No special driver support required
– Limited connectivity is sufficient (e.g. serial/parallel support)
– No device integrated smartcard reader required
IGEL Technology |
Andreas Buis, Software Engineer | Page 25
Any Questions?
IGEL Technology | <Topic>, <Month> <Year>
<First Name> <Last Name>, <Position> | Page 26
Further information on the current status
►
IGEL Webinar
please contact us for the update webinar dates
Phone +49 421 52094 3333
The next webinar dates are:
•
•
•
•
•
•
•
•
09.07.2012
09.07.2012
10.07.2012
11.07.2012
12.07.2012
12.07.2012
13.07.2012
13.07.2012
IGEL Technology |
09:00 – 10:00
11:00 – 12:00
14:00 – 15:00
09:00 – 10:00
10:00 - 11:00
13:00 – 14:00
09:00 – 10:00
11:00 - 12:00
(English)
(German)
(German)
(English)
(German)
(English)
(English)
(German)
Andreas Buis, Software Engineer | Page 27
Thank you
Questions?
