EVAPCO, INC.

Evaporative

Condensers

Specialists in Heat Transfer Products and Services

Evaporative Condensers

Types of Condensers:

Induced Draft Forced Draft

Specialists in Heat Transfer Products and Services

Evaporative Condensers

Types of Condensers:

Air Flow / Sound

Air Flow

Air Flow

Sound

Induced Draft Forced Draft

Specialists in Heat Transfer Products and Services

Evaporative Condensers

Types of Condensers:

Induced Draft

Forced Draft

ATC-E: Axial Fan

C-ATC: Containerized

PMC-E: Axial Fan

LSCB: Centrifugal Fan

LRC: Low Profile

Centrifugal Fan

Specialists in Heat Transfer Products and Services

Innovative Product Features

Superior Design

Superior Materials of Construction

IBC Compliance to 1.0g or 5.12g

Performance Design

Coil Design

Water Distribution Systems

NEW

ZMII Spray Nozzles

Ease of Rigging and Maintenance

Low Sound Options

GREEN Environmental Designs

Specialists in Heat Transfer Products and Services

EXCLUSIVE THERMAL-PAK

®

COIL

EVAPCO’S Patented

Thermal-Pak

®

Coil

Design Provides as much as 20% More Surface

Area per Plan Area Than

Any Other Design.

Specialists in Heat Transfer Products and Services

EXCLUSIVE THERMAL-PAK

®

COIL

Patent Granted

1988

No. 4,755,331

Specialists in Heat Transfer Products and Services

EXCLUSIVE THERMAL-PAK

®

COIL

Superior Performance Achieved by

Maximizing Effective Tube

Surface Area

Lowering Air Pressure Drop

Increasing Spray Water Flow

Specialists in Heat Transfer Products and Services

EXCLUSIVE THERMAL-PAK

®

COIL

Next Generation

– Thermal Pak II

Specialists in Heat Transfer Products and Services

THERMAL-PAK

®

II COIL

Design Features

Reduction in Refrigerant

Charge

Reduction in Operating

Weight

Reduction in Coil Volume

ZERO Performance Loss

Specialists in Heat Transfer Products and Services

THERMAL-PAK

®

II COIL

Design Features

Example - PMC-887E

Thermal Pak I

1,200 lbs

133 FT3

19,372 lbs

Thermal Pak II

870 lbs

119 FT3

17,464 lbs

Specialists in Heat Transfer Products and Services

Superior Design

Standard Material of Construction

G-235 Hot-Dip Galvanized Steel

PVC Water Distribution

PVC Drift Eliminators

PVC Inlet Louvers

Stainless Steel Strainers

Leak-Free Basins

Specialists in Heat Transfer Products and Services

Materials of Construction

G-235 Galvanized Steel Construction

Heaviest Mill Galvanizing Available

Fewer Casing Panels

Greater Structural Integrity

Type 304 Stainless Steel (Optional)

Superior level of corrosion protection

Stainless Steel Coil, Basin, and Casing Options

Greatest Structural Integrity in Corrosive Environments

Specialists in Heat Transfer Products and Services

Materials of Construction

PVC Water Distribution System

Corrosion-free Spray

Header & Nozzles

Threaded Nozzles

Eliminate Troublesome

“Rubber Grommets”

Threaded End Caps

Specialists in Heat Transfer Products and Services

CONDENSER DESIGN FEATURES

Fixed Position Nozzle

Heavy Duty ABS Plastic

Threaded Design

Eliminates Grommets

Installed on 24” Centers

Up to 75% Fewer Nozzles Required

Specialists in Heat Transfer Products and Services

Fixed Position Nozzle

Larger Diameter Opening

1-

5/16” vs. 1”

Larger Clearance for Debris

1-

1/2” vs. 5/16”

Specialists in Heat Transfer Products and Services

X

X

X

X

X

X

Example - PMC-887E

X

X

X

X

X

X

X

X

X

X

Old Style

108

Nozzles

X X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

X

75% Fewer Nozzles!

ZM II Nozzle

27

Nozzles

Specialists in Heat Transfer Products and Services

Fixed Position Nozzle

Retrofit Kits Available for ALL EVAPCO

Condensers Manufactured After 1986

Retrofits Available for MOST COMPETITOR’S

Models (i.e. BAC & IMECO)

Contact Your Sales Representative For Details

Specialists in Heat Transfer Products and Services

Materials of Construction

PVC Drift Eliminators

Superior Drift Control

Drift Rate Less Than .001% to .002% of Recirculated

Water Rate

Lightweight, Easy to Handle

Sections

PVC Design Eliminates

Corrosion

Specialists in Heat Transfer Products and Services

Materials of Construction

Stainless Steel Strainers

Corrosion-free

Eliminates Expensive

Maintenance Caused by “Corroded” and

“Collapsed” Galvanized

Strainers

Specialists in Heat Transfer Products and Services

Materials of Construction

Leak-Free Basins

Double-Break Flange

Nut & Bolt Construction

Integral Compression

Shim Sealer

Internal Sealant

Specialists in Heat Transfer Products and Services

EVAPCO, INC.

Induced

Draft

Condensers

Specialists in Heat Transfer Products and Services

INDUCED DRAFT CONDENSERS

ATC-E

C-ATC

Specialists in Heat Transfer Products and Services

INDUCED DRAFT CONDENSERS

IBC 2006 Compliant Construction as standard!

Specialists in Heat Transfer Products and Services

INDUCED DRAFT CONDENSERS

What is IBC?

The International Building Code requires that evaporative cooling equipment must meet the same seismic or wind load forces as the building to which they are attached

What does EVAPCO offer?

Standard structural design: < 1.0g seismic or 60psf wind loads

Upgraded structural design: >1.0g seismic or 60psf wind loads

Specialists in Heat Transfer Products and Services

INDUCED DRAFT FEATURES

Superior Drive System

Extruded Aluminum Fan

Aluminum Alloy Sheaves

Heavy Duty Pillow Block Bearings

(Rated L10 Life of 75,000 - 135,000 Hrs)

Polished Steel Shaft

Corrosion Protected Bushings

Totally Enclosed Fan Motor

Specialists in Heat Transfer Products and Services

INDUCED DRAFT FEATURES

Easy Rig Field Seam

Self guiding channels improve quality of field seam to help eliminating leaks

Reduced installation costs

Easy to Install

ATC-E Shown

Specialists in Heat Transfer Products and Services

ATC-E Evaporative Condensers

ATC-E

Axial Fan Design

181 Models

ATC-50E to ATC-3714E

IBC 2006 Compliant

Construction as standard

Specialists in Heat Transfer Products and Services

ATC-E Evaporative Condensers

Easiest Condenser to Maintain

Requires Less Maintenance

Largest Available Capacity

967 Nominal Tons in a Single Cell

3,714 Nominal Tons in a Single Unit

Low Recirculation Potential

Super Low Sound Fan Capabilities

Innovative Design Features

Specialists in Heat Transfer Products and Services

ATC-E FEATURES

WST Inlet Louvers

Developed with CFD and CAD Software

Patent Pending Technology

Specialists in Heat Transfer Products and Services

ATC-E Features

WST Inlet Louvers

Galvanized or Stainless Steel

Frame

Quick Release Mechanism

Specialists in Heat Transfer Products and Services

ATC-E Features

Accessibility - Cold Water Basin

Service Can Be Performed from Outside Unit

Float Valve Adjustment

Remove & Clean SST

Strainers

Clean Pan Bottom

Specialists in Heat Transfer Products and Services

ATC-E Features

Accessibility - Cold Water Basin

“Clean Basin” Design with Sloped Pan Bottom for

Ease of Cleaning

Specialists in Heat Transfer Products and Services

ATC-E Features

Low Maintenance Water Distribution System

No Service Necessary from Fan Deck

Thermal-Pak

®

Coil

Provides Safe Working

Platform

ZM Nozzles

Threaded End Caps for

Cleaning

Specialists in Heat Transfer Products and Services

ATC-E Features

Simplified Maintenance

Fans and Motors

Positioned for Easy Access

Optional Ladder Package

Specialists in Heat Transfer Products and Services

ATC-E Features

Simplified Maintenance

Fans and Motors

Positioned for Easy Access

Optional Access Ladder

Optional Service Platform

Specialists in Heat Transfer Products and Services

ATC-E Features

Simplified Maintenance

Fans and Motors

Positioned for Easy Access

Optional Access Ladder

Optional Service Platform

Optional Motor Davit

Specialists in Heat Transfer Products and Services

ATC-E Features

Maintenance - Mechanical Drive System

4, 8-1/2 & 17 Ft. Wide

Models

Externally Mounted Totally

Enclosed Motor

Power-Band Adjustment

Performed from Outside

Bearing Lubrication Lines

Extended to Outside

Large Hinged Access Door with Quick Release

Mechanism

Specialists in Heat Transfer Products and Services

ATC-E Features

Maintenance - Mechanical Drive System

12 & 24 Ft. Wide Models

Easy Belt Adjustment

Easy Bearing Lubrication

All Routine Maintenance is Performed from the

Outside

Specialists in Heat Transfer Products and Services

ATC-E Features

Maintenance - Mechanical Drive System

12 & 24 Ft. Wide Models

Unique Locking

Mechanism May Be

Released Without Tools

Locking Mechanism

Designed to be Used to

Adjust Belt Tension

Specialists in Heat Transfer Products and Services

ATC-E Features

Maintenance - Mechanical Drive System

12 & 24 Ft. Wide Models

Base Swings to Outside of

Unit Through Access Door

No Need to Wade in Water to Perform Maintenance or

Remove Motor

Specialists in Heat Transfer Products and Services

ATC-E EVAPORATIVE CONDENSERS

SSHHHHHH…….

Specialists in Heat Transfer Products and Services

ATC-E EVAPORATIVE CONDENSERS

Low Sound Solutions

Four Low Sound

Options:

Super Low Sound Fan

Low Sound Fan

Fan Discharge

Attenuation

Water Silencer

End User Benefits

Prevent Neighbor

Complaints

Avoid Potential Legal

Issues

Safer Working

Environment

Specialists in Heat Transfer Products and Services

ATC-E EVAPORATIVE CONDENSERS

Super Low Sound Fan

Extremely wide chord blade

One piece molded construction

High efficiency axial propeller

No loss of thermal performance

9-15 dB(A) Reduction

Specialists in Heat Transfer Products and Services

ATC-E EVAPORATIVE CONDENSERS

Low Sound Fan

12’ & 24’ wide models

Wide chord blade design

Extruded Aluminum blade

High efficiency axial propeller

Minimal Impact on Thermal

Performance

4-7 dB(A) Reduction

Specialists in Heat Transfer Products and Services

ATC-E EVAPORATIVE CONDENSERS

Fan Discharge

Attenuation

Can be used with Standard fan or with Low Sound Fan option

Constructed of G-235 Galvanized

(Stainless Steel optional)

Includes insulated walls

Minimal impact on thermal performance

Up to 10 dB(A) Reduction

Specialists in Heat Transfer Products and Services

ATC-E EVAPORATIVE CONDENSERS

Water Silencer

Reduces the Noise of Falling Water

Constructed of Lightweight PVC

Sections

Easily Removed for Access to Basin

Area

Prevent Louver Ice Buildup in Cold

Weather

No Loss of Thermal Performance

Up to 7 dB(A) Reduction

Specialists in Heat Transfer Products and Services

Induced Draft Features

IBC 2006

Specialists in Heat Transfer Products and Services

EVAPCO, INC.

Induced

Draft

Condensers

Specialists in Heat Transfer Products and Services

C-ATC Evaporative Condenser

C-ATC

Axial Fan Design

24 Models

C-ATC-181 to C-ATC-504

All the benefits of the

ATC at a fraction of the ocean freight!

Specialists in Heat Transfer Products and Services

C-ATC Evaporative Condenser

Designed to Ship in Standard Containers

Largest Capacity Available per Container

40 FT Container: 504 R-22 Nom. Tons

20 FT Container: 251 R-22 Nom. Tons

Cost Effective

Ample Container Availability

Protected from Damage

During Transportation

Specialists in Heat Transfer Products and Services

C-ATC Evaporative Condenser

Optimized Unit Width

Designed for Maximum Possible Width

All C-ATC Models are 2.24 Meters Wide

Specialists in Heat Transfer Products and Services

C-ATC Evaporative Condenser

Avoid High Costs and Limited

Availability of Flat Racks!

FOOTPRINT

MINIMUM

CONTAINER

CAPACITY RANGE

7’ 4” x 9’

2.24M x 2.73M

7’ 4” x 12’

2.24M x 3.65M

THROUGH

7’4” x 18’

2.24M x 5.49M

181TR to 251TR

7 models

264TR to 504TR

Specialists in Heat Transfer Products and Services

17 models

C-ATC Evaporative Condenser

Shipping Arrangement

Unit Requires Minimal Field Assembly

Fan Section Ships Together with Basin Section

Casing Section Ships Individually

Basin Section

Coil Section

Fan Section

Specialists in Heat Transfer Products and Services

C-ATC Evaporative Condenser

C-ATC Advantages

Significant Freight Price Savings

Minimal Field Assembly Required

Most Standard Accessories Available, Including:

Stainless Steel Construction

Low Sound Solutions

Electric Basin Heaters and Water Level Control

Inverter Duty and 2-Speed Motors

And Many More!

ALL STANDARD ATC DESIGN ADVANTAGES!

Specialists in Heat Transfer Products and Services

EVAPCO, INC.

Forced

Draft

Condensers

Specialists in Heat Transfer Products and Services

FORCED DRAFT CONDENSERS

LSCB

LRC

PMC-E

Specialists in Heat Transfer Products and Services

FORCED DRAFT CONDENSERS

IBC 2006 Compliant Construction as standard!

Specialists in Heat Transfer Products and Services

FORCED DRAFT CONDENSERS

PMC-E Models

Axial Fan Design

115 Models

PMC-175E to

PMC-1985E

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Two Stage Axial Fan

Layout Flexibility with Larger Box Sizes and

More Models with Increased Capacity

Energy Efficient Compared to Centrifugal Fan

Models

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Increased Performance

Larger Diameter Fans

More Capacity vs PMCB

12% More Capacity!

More Capacity than the Competition!

New Features

Simplified Installation

Improved Reliability

Easy to Service

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

More Choices

115 PMC-E Models vs. 75 PMCB Models

New Box Sizes

12 x 20 Plan Area

12 x 40 Plan Area

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

New Nomenclature

PMC-939E

Product Line Designator

Condensing Capacity (R-22)

Power Mizer Condenser

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

New Plan Areas

– 12 x 20

PMC-811E thru PMC-992E

575 to 704 NH

3

Tons

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

New Plan Areas

– 12 x 40

PMC-1705E thru PMC-1985E

1,209 to 1,408 NH

3

Tons

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Design Features

– Simplified Rigging

External Lifting Ears

Available on All Models Except 5x’s

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Features

– Simplified Rigging

External Lifting Ears

Available on All Models Except 5x’s

Unique Field Seam Design

Approximately 85% Fewer Bolts

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Features - New Fan & Drive System

Larger Fan

Accessible Front-Mounted Drives

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Features - Individual Fan Drives

Independently Driven Fans

Increased Flexibility

Capacity Control

Improved Reliability

Redundancy

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Features - Easy Access

Horizontally Mounted Pumps

Simplified Pump Piping

All models except:

5x’s

12’ x 20’s

12’ x 24’s w/ single end connection

12’ x 40’s

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Features - Sloped Pan Bottom

Simplifies Basin Cleaning

Drains at Lowest Point

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Features - Water Saver Drift Eliminators

Patented Design

0.001% Drift Rate

Increased Structural Integrity

Recessed into Casing for Better Protection

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condenser

Signature Design Features

Thermal Pak Coils

ZM II Nozzles

Optional Equipment

Man-Sized Access Doors

External Service Platforms

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condensers

External Service Platform

OPTION A

Single-Side Platform Located on Side Opposite

Fans for All Models

PLATFORM

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condensers

External Service Platform

OPTION B

Wrap-Around Platform for Models with Coil

Connections on One End

PLATFORM

PLATFORM

Specialists in Heat Transfer Products and Services

PMC-E Evaporative Condensers

External Service Platform

OPTION C

Wrap-

Around Platform for 24’ & 36’ Long Models with

Coil Connections on Both Ends

PLATFORM

PLATFORM

Specialists in Heat Transfer Products and Services

PMC-EQ EVAPORATIVE CONDENSERS

Super Low Sound Fan

Extremely wide chord blade

One piece molded construction

High efficiency axial propeller

Centrifugal Sound levels,

Axial HP

10-13 dB(A) Reduction

Specialists in Heat Transfer Products and Services

Forced Draft Condensers

LSCB Models

Centrifugal Fan Design

57 Models

LSCB-36 to LSCB-1610

Specialists in Heat Transfer Products and Services

Forced Draft Condensers

LRC Models

Centrifugal Fan Design

43 Models

LRC-25 to LRC-379

Low Profile

Applications

Specialists in Heat Transfer Products and Services

LSCB/LRC Condensers

Superior Design Features

Superior Materials of Construction

G235 Hot-Dipped Galvanized Steel as Standard

304 Stainless Steel Construction Options

Corrosion Free PVC Water Distribution

Performance Design

TPII Advanced Coil Design

ZM Spray Nozzles

TEFC Motors

Ease of Rigging and Maintenance

Specialists in Heat Transfer Products and Services

LSCB/LRC Condensers

Low Sound Design

(Optional Inlet and Discharge Attenuation Available)

Capable of Handling Static Pressure

Indoor Installations with Duct Work

Tapered Discharge Hoods for Recirculation

Prevention

Overall Higher Horsepower than Condensers with Axial Fans

Specialists in Heat Transfer Products and Services

Forced Draft Features

IBC 2006

Specialists in Heat Transfer Products and Services

EVAPCO, INC.

Taking

Quality

and

Service

to a

Higher Level . . .

Specialists in Heat Transfer Products and Services

Download
