Grant Ronald
Principal Product
Manager
JDeveloper and ADF for
Forms Developers:
Taking it to the next level
Agenda
• What you should know
• What this presentation is
• What this presentation isn’t!
• Getting into the code
• Extending the business logic
• Common “Forms trigger” points
• Searching and querying
• Calling a stored procedure from ADF BC
• Extending the user interface
• Conditional page flow
• Stacked canvases
What You Should Know
•
•
•
•
JDeveloper
ADF
ADF Business Components
JSF
ADF Architecture
ADF Swing
JSP
JSF/ADF Faces
View
Struts
JSF
Controller
ADF Data Binding/ Data Control
Model
(JSR 227)
EJB
Java
Classes
ADF
Business
Components
Web
Services
Portlets
JSR-168
WSRP
Metadata Services (MDS
Toplink
Business
Services
Data
Source
Relational Data
XML Data
Legacy Data
Packaged Apps
ADF Business Components
CustView
CustView
OrdView
OrdView
Customer
Order
OrdView
LineItem
Application
Module
View
Objects
Entity
Objects
Getting into the code
• ADF BC doesn’t “generate
code”
• “default” XML definition
• Allows you to expose
more and more of the
implementation code
Getting into the code
• Exposing code in the Entity Object
Getting into the code
• Exposing code in the View Object
Getting into the code
• Exposing code in the Application Module
Common “Forms Trigger”
points
• Validation
• When-Validate-Item, When-Validate-Record
• Query
• Pre-Query, Post-Query
• Transaction
• Pre-Commit, On-Commit, Post-Commit
• Pre-Insert, On-Insert, Post-Insert
• Pre-Delete, On-Delete, Post-Delete
Validation Triggers
• When-Validate-Item
• When-Validate-Record
Query Triggers
• Post-Query
• Non-base table population
• Running totals
• Pre-Query
• Modify query
Transactional Triggers
• Insert, Delete, Update
• Pre• Post• On-
The Best of the Rest
• When-Create-Record
• When-Remove-Record
• When-Button-Pressed (UI processing – later)
D E M O N S T R A T I O N
Adding “trigger”
code
Searching and Querying
• Parameterize search form
• ADF Search Form
• ADF provides option to “ExecuteWithParams”
• Execute Query
D E M O N S T R A T I O N
Adding search
code
D E M O N S T R A T I O N
Calling a stored
procedure
Next Level – UI Processing
• Auto Submit
• Conditional UI processing
• Expression Language validation
• Backing/Managed Beans
• “Stacked canvases”
• Conditional page flow
Auto Submit
• HTML UI validates only on POST
• ADF Faces provides Partial Page Rendering
• AutoSubmit submits page when field changed
• PartialTrigger defines fields that re-act to changes
D E M O N S T R A T I O N
Auto Submit
Conditional UI Processing
• JSF Expression Language (EL)
• Backing/Managed Beans
Stacked Canvas
• <af:switcher>
• Number of facets
• Each facet is a “canvas”
• Property to defines which
canvas to render
D E M O N S T R A T I O N
Stacked Canvas
Conditional Page Flow
• Button action returns a string
• When-Button-Pressed
• Define page flow based on runtime criteria
D E M O N S T R A T I O N
Conditional Page
Flow
Summary
• ADF provides Forms developers with
• All your favorite triggers
• Many of the common Forms concepts
• Stacked canvases
• Defining search criteria
• Conditional page flow
• And a lot more besides!
• JDeveloper and ADF continue to provide more
and more productivity features for Forms
developers
