Raspberry Pi Workshop
BSidesDFW, 2013  MAKEUP SESSION
@BrandenWilliams
Format

Intro to Raspberry Pi

Walk around the setup

Set up for use

EXERCISE

Review

Additional Resources
Callout box
What is this thing?
$35 Wunderdevice
What we’re going to do today

Interface with the Raspberry Pi

Do some basic configuration work

Walk through scenarios in which it can be used

Exercise

Discuss results

Q/A
Fun Ideas for Covert Hacking
 Network
sniffer
 Wireless backdoor
 2-wifi dongles = Wi-Fi sniffer that you
can connect to via Wi-Fi for downloads!
 Attach GPS and track a car (power with
cigarette lighter/battery)
 How much fun to be had at
STARBUCKS!!
Fun Ideas for Covert Hacking
 Mobile
fun with hacked baseband
 Audio listening device
 Spooky Halloween automation!
 Camera system
 Pair with Arduino for alarm systems
 Tweet stuff when you want it to
 Covert signaling!
Things to remember:







BE CREATIVE!
2 onboard USB ports
Ethernet
Audio
Video
Low power required
Extra pins for EXTRA HACKING
Let’s get to the fun
stuff!
Prep work before we plug her in

First, we need to make some adjustments to BerryBoot

Your Pi comes with BerryBoot installed, allowing you
to drop multiple operating systems on one card

You could also carry a wallet of smaller cards (they
are cheap) with each OS on there

Plug your SD card into your laptop and open
cmdline.txt, edit it like this:

smsc95xx.turbo_mode=N elevator=deadline quiet
nobootmenutimeout datadev=mmcblk0p2
ipv4=192.168.1.50/255.255.255.0/192.168.1.1
vncinstall
OK, now what did we just do?

Couple of things:
– BerryBoot now set up for HEADLESS operation
– There is a STATIC IP setup
 You can make it DHCP if you like
 You can also set it to default to WiFi device
– We also removed the autoboot…

Options you may want to consider for covert use:
– Put a boot timeout (bootmenutimeout=60)
– Potentially set static on WiFi for berryboot
– Remember, BerryBoot can be different from OS.
Plug her in!
 OK,
time for some power & ethernet
 Insert
SD card & Wi-Fi dongle
 Plug
the ethernet crossover cable into
your laptop first
 Then
plug in the power
Wait a few!

Take a moment to review the indicator lights on
the top of your Pi.

Basic troubleshooting starts here:
– ACT: Green, flashes during SD card activity
– PWR: Red, solid light when unit has power
– FDX: Green, solid light when Ethernet is Full Duplex
– LNK: Green, flashes on activity
– 100: Orange, On when connection is 100Mbps, off
10Mbps
Try testing connectivity

You should be able to pull up your VNC client now
and connect to 192.168.1.50

You can also ping it

You will be presented with the BerryBoot screen…
What you should be seeing…
Try testing connectivity

Choose Raspbian!

Wait a little more…

Then you should be able to ping/ssh into the
device at 192.168.1.50

Few more things to set up!
– SSH to pi@192.168.1.50, password raspberry
– CHANGE THE PASSWD! (enter command ‘passwd’)
– Consider changing root password as well
– Next, let’s do some wifi!
Connecting to WiFi

/etc/network/interfaces:
allow-hotplug wlan0
iface wlan0 inet manual
wpa-roam /etc/wpa_supplicant/wpa_supplicant.conf
iface default inet dhcp

/etc/wpa_supplicant/wpa_supplicant.conf
network={
ssid=“GuestNetwork”
scan_ssid=1
proto=RSN
key_mgmt=WPA-PSK
psk=“CC06062010”
}
Fire up WiFi

ifup wlan0

Check our routes...
– route add default gw 192.168.2.1 wlan0
– route del default gw 192.168.1.1 eth0

Magic! Ping something! 8.8.8.8

Now, let’s get some updates and some new
packages we need:
– apt-get update
– apt-get upgrade
– apt-get install netatalk x11vnc
Next, we need a couple of files.

cd ~/.config/

mkdir autostart ; cd autostart

wget http://brando.ws/piwork1
– Then rename the file piwork1 to x11vnc.desktop

cd /etc/avahi/services

sudo wget http://brando.ws/piwork2
– Then rename the file piwork2 to rfb.service

Then REBOOT!
Next, connect back VNC

Boot to Raspbian, and then VNC in again…

You should see…
Now, you should see your desktop:
Next, Kali!
Exercise:
This is where we start to have some fun

Please choose one of the following:
– Set up the web server and some wiki software
 (apache2, wiki software like mediawiki)
 Apt-cache search wiki
 Get it serving up a page!
– Compromise the vulnerable machine (CTF)
 There is a vulnerable machine on the wireless network
 Identify it, and break in
– CREATE YOUR OWN!
Additional Resources

www.raspberrypi.org

www.arduino.cc

elinux.org/RPi_Distributions

elinux.org/RPi_Hub

www.raspbian.org

www.kali.org

BerryBoot

Karlssonrobotics.com
Some additional notes

If you break your distro, no worries. Just reflash
SD card.

You can mount the card & OS on most machines to
edit files if you have a config error.

Your Pi comes with BerryBoot. You can add more
operating systems by following the instructions on
their website.
