Training
Guide
tm
TM-1873
AVEVA Everything3D™ (2.1)
Isodraft Administration
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
2
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Revision Log
Date
Revision
Description
Author
Reviewed
26/06/2014
0.1
Issued for Review AVEVA E3D™ (1.1)
ST
30/06/2014
0.2
Reviewed
ST
KB
01/07/2014
1.0
Issued for Training AVEVA E3D™ (1.1)
ST
KB
08/03/2016
1.1
Issued for Review AVEVA E3D™ (2.1)
ST
08/03/2016
1.2
Reviewed
ST
BT
21/03/2016
2.0
Issued for Training AVEVA E3D™ (2.1)
ST
BT
Approved
KB
KB
Updates
Change highlighting will be employed for all revisions. Where new or changed information is presented section
headings will be highlighted in Yellow.
Suggestion / Problems
If you have a suggestion about this manual or the system to which it refers please report it to AVEVA Training
& Product Support at tps@aveva.com
This manual provides documentation relating to products to which you may not have access or which may not
be licensed to you. For further information on which products are licensed to you please refer to your licence
conditions.
Visit our website at http://www.aveva.com
Disclaimer
1.1
AVEVA does not warrant that the use of the AVEVA software will be uninterrupted, error-free or free
from viruses.
1.2
AVEVA shall not be liable for: loss of profits; loss of business; depletion of goodwill and/or similar
losses; loss of anticipated savings; loss of goods; loss of contract; loss of use; loss or corruption of
data or information; any special, indirect, consequential or pure economic loss, costs, damages,
charges or expenses which may be suffered by the user, including any loss suffered by the user
resulting from the inaccuracy or invalidity of any data created by the AVEVA software, irrespective of
whether such losses are suffered directly or indirectly, or arise in contract, tort (including negligence)
or otherwise.
1.3
AVEVA's total liability in contract, tort (including negligence), or otherwise, arising in connection with
the performance of the AVEVA software shall be limited to 100% of the licence fees paid in the year
in which the user's claim is brought.
1.4
Clauses 1.1 to 1.3 shall apply to the fullest extent permissible at law.
1.5
In the event of any conflict between the above clauses and the analogous clauses in the software
licence under which the AVEVA software was purchased, the clauses in the software licence shall
take precedence.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
3
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Copyright Notice
All intellectual property rights, including but not limited to, copyright in this Training Guide and the associated
documentation belongs to or is licensed to AVEVA Solutions Limited or its affiliates.
All rights are reserved to AVEVA Solutions Limited and its affiliates companies. The information contained in
this Training Guide and associated documentation is commercially sensitive, and shall not be adapted, copied,
reproduced, stored in a retrieval system, or transmitted in any form or medium by any means (including
photocopying or electronic means) without the prior written permission of AVEVA Solutions Limited. Where
such permission is granted, AVEVA Solutions Limited expressly requires that the Disclaimer included in this
Training Guide and this Copyright notice is prominently displayed at the beginning of every copy that is made.
Licenses issued by the Copyright Licensing Agency or any other reproduction rights organisation do not apply.
If any unauthorised acts are carried out in relation to this copyright work, a civil claim for damages may be
made and or criminal prosecution may result.
AVEVA Solutions Limited and its affiliate companies shall not be liable for any breach or infringement of a
third party's intellectual property rights arising from the use of this Training Guide and associated
documentation.
@AVEVA Solutions Limited 2015
Trademark Notice
AVEVA™, AVEVA Everything3D™, AVEVA E3D™, [AVEVA Tags], Tribon and all AVEVA product and service
names are trademarks of AVEVA Group plc or its subsidiaries
Use of these trademarks, product and service names belonging to AVEVA Group plc or its subsidiaries is
strictly forbidden, without the prior written permission of AVEVA Group plc or AVEVA Solutions Limited. Any
unauthorised use may result in a legal claim being made against you.
Fluent is a trade mark of Microsoft Corporation. The Fluent user interface is licensed from Microsoft
Corporation by AVEVA and use of the Fluent trademark is strictly forbidden.
All other trademarks belong to their respective owners and cannot be used without the permission of the
owner.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
4
CONTENTS
1
Introduction .............................................................................................................................................. 7
1.1
Aim ..................................................................................................................................................... 7
1.2
Objectives.......................................................................................................................................... 7
1.3
Prerequisites ..................................................................................................................................... 7
1.4
Course Structure............................................................................................................................... 7
1.5
Using this guide ................................................................................................................................ 7
2
Isometric Administration......................................................................................................................... 9
2.1
Entering an Isodraft session ......................................................................................................... 10
2.2
Isometric Option Files .................................................................................................................... 11
Company Option Files ............................................................................................................... 11
Project Option Files ................................................................................................................... 11
2.3
Creating a Standard Isometric Project Option File – A Worked Example................................. 12
2.4
Drawing sheet layout...................................................................................................................... 14
2.5
Administrative Options – A Worked Example ............................................................................. 15
Using True Type Fonts on Isodraft Output files......................................................................... 18
2.6
Sheet Layout Options – A Worked Example ................................................................................ 20
Size/Stacking ............................................................................................................................. 20
Graphics .................................................................................................................................... 20
Specifications............................................................................................................................. 22
Flow Arrows and Margins .......................................................................................................... 22
Reserved Areas ......................................................................................................................... 23
2.7
Dimensioning Options – A Worked Example............................................................................... 24
Units........................................................................................................................................... 24
Dimensions ................................................................................................................................ 25
Skew Box................................................................................................................................... 27
Tapping Branches...................................................................................................................... 28
2.8
Annotation Options – A Worked Example ................................................................................... 28
Whitespace Search ................................................................................................................... 29
Part number enclosure types..................................................................................................... 29
Spindle and Gearbox Direction Format ..................................................................................... 29
Display of Item Codes ............................................................................................................... 29
Coordinates ............................................................................................................................... 30
Keys ........................................................................................................................................... 30
2.9
Material List – A Worked Example ................................................................................................ 31
Options ...................................................................................................................................... 31
Detail Texts................................................................................................................................ 32
Item Codes ................................................................................................................................ 32
Bolting........................................................................................................................................ 32
Cutting List................................................................................................................................. 33
Cutback Rules ........................................................................................................................... 34
Pipe Piece Names ..................................................................................................................... 34
Spooling..................................................................................................................................... 34
Material List File......................................................................................................................... 35
2.10
Material Columns – Worked Example ....................................................................................... 35
2.11
Weld Numbering.......................................................................................................................... 38
2.12
Pipe / Spldrg Attribute Table – A Worked Example ................................................................. 40
2.13
Revision Table ............................................................................................................................. 41
2.14
Bend Table and File .................................................................................................................... 41
2.15
Reports and Symbol File ............................................................................................................ 42
2.16
Title block..................................................................................................................................... 43
2.17
Attribute Frame Texts ................................................................................................................. 43
2.18
Standard Texts ............................................................................................................................ 44
Using True Type Fonts on Isodraft Output files......................................................................... 45
Typical Option File Including a Backing Sheet .......................................................................... 45
2.19
Component Tags ......................................................................................................................... 46
2.20
Detail Plots................................................................................................................................... 46
2.21
Compipe Interface ....................................................................................................................... 49
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
5
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.22
2.23
2.24
Alternative Texts ......................................................................................................................... 49
IDF Processing ............................................................................................................................ 50
Change Highlighting ................................................................................................................... 50
Exercise 1 Isodraft Administration.............................................................................................................. 52
3
Isodraft Symbol Libraries...................................................................................................................... 53
3.1
Entering Isometric Symbol Library Administration Mode .......................................................... 54
3.2
Creating an Isometric Symbol Library – A Worked Example ..................................................... 55
3.3
Creating Isodraft Symbol Templates – A Worked Example ....................................................... 57
Drawing the Isometric Symbol................................................................................................... 59
Exporting Isodraft Symbols........................................................................................................ 60
3.4
Importing Isodraft Symbols ........................................................................................................... 64
Typical Isodraft Symbol Definition File ...................................................................................... 64
Exercise 2
Isodraft Symbol Libraries.................................................................................................... 66
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
6
CHAPTER 1
1 Introduction
AVEVA Everything3D™ (AVEVA E3D™) allows designers to utilise an array of applications contained within
the program modules. This training guide provides discipline specific training for the Isodraft module.
1.1
Aim
The aim of this training module is to provide Draw Administrators with the knowledge and skills necessary to
customise the Isodraft working environment.
1.2
Objectives
In general terms, the course objectives are to provide participants with the ability to configure and customise
Isometric Production and Symbols.
1.3
Prerequisites
It is expected that trainees will have completed the TM-1831 AVEVA Everything3D™ Automatic Drawing
Production training course. Trainees who can demonstrate appropriate knowledge of other AVEVA E3D
applications and techniques may also be permitted to undertake the training.
1.4
Course Structure
Training will consist of oral and visual presentations, demonstrations and set exercises. Each workstation will
have a training project, populated with model objects. This will be used by the trainees to practice their
methods, and complete the set exercises.
1.5
Using this guide
Certain text styles are used to indicate special situations throughout this document, here is a summary;
Menu pull downs and button press actions are indicated by bold dark turquoise text.
Information the user has to key-in will be in bold red text.
Where additional information is presented, or reference is made to other documentation the following
annotation will be used:
 Additional information
 Refer to other documentation
System prompts will be bold, italicised, and presented in inverted commas i.e. 'Choose function'.
Example files or inputs will be in the courier new font.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
7
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
This page is intentionally left blank.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
8
CHAPTER 2
2 Isometric Administration
Isodraft, the Isometric drawing production module uses a series of Option Files that describe how the Isometric
should be drawn. This chapter describes how the Draw Administrator can modify and create a Standard
Isometric Project Option File. A selection of options is discussed to give the trainee an outline of how to
configure Isodraft.
 This Chapter should be read in conjunction with Chapter 3 Isodraft Symbol Libraries.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
9
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.1
Entering an Isodraft session
Login to AVEVA E3D using the details provided by the trainer. They will typically be as shown below:
Project: Training (TRA)
Username: A.DRAWADMIN
Password: A
MDB: A-PIPING
After entering the login details click
the Isodraft tile.
When AVEVA E3D Isodraft has been loaded, a default screen layout will be displayed.
 In order to create certain elements in the Isodraft module it is necessary that the User is a member of the
Isodraft administration team ISOADMIN.
 Model Explorer can be opened by selecting this option from Display> Explorers> Model Explorer.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
10
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.2
Isometric Option Files
The Isodraft Option File describes how the Isometric should be drawn.
There are two types of Isometric option files:
 Standard Pipe or Pipe Spool Isometric.
 System and Vessel Trim Isometrics.
Company Option Files
Default Option files are supplied with AVEVA E3D for both types and can be found in folders in the AVEVA
E3D Data Area typically: C:\Users\Public\Documents\AVEVA\Everything3D\Data2.10 which holds a sub
folder called DFLTS. Q EVAR 'AVEVA_DESIGN_DFLTS'


%AVEVA_DESIGN_DFLTS%\std
%AVEVA_DESIGN_DFLTS%\sys
for Standard Isometrics.
for System Isometrics.
These are referred to as Company Option Files.
Project Option Files
The project environment variable, for example %TRAISO% for this training session, describes the location of
the project specific Option Files which are held in the sub folders.
This variable can be checked in the Command Window using the command q evar (Project-Code) ISO in
AVEVA E3D. For example, typing: q evar TRAISO, returns:
Environment variable TRAISO :C:\Users\Public\Documents\AVEVA\Projects\E3D2.1\Training\traiso

The directory “lis” is used to store System Isometric Lists and the “und” directory is used to store
company Isometric backing sheets, the use of both of these directories are discussed later.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
11
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.3
Creating a Standard Isometric Project Option File – A Worked Example
In order to create or modify Option Files the Administrator is required to be a member of the ISOADMIN team.
Select Options > Create from the main menu.
The Create Options file form is displayed with the following
sections:

Filename of the new Options file.

Initial setup Defaults or Existing Option File
controls the initial content of the file.

Option file directory, Project, Company or Local
controls the location of the Options file.

Isometric type Standard Iso or System Iso.
The Options file gadget lists the existing option files set up at project initialisation.
Enter the following data on the Create Options form:
Filename:
TRAINING
Initial Setup:
Defaults
Options file Directory:
Project, Standard iso
Click the OK button to confirm.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
12
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
The Options File form is then displayed. If this form is dismissed all options will be set to default values.
Clicking any of the functional area gadgets allows the relevant options to be set individual by the
Administrator.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
13
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
For example, Dimensioning… displays the Dimensioning Options form.
2.4
Drawing sheet layout
The default layout of an isometric drawing produced through Isodraft is shown in the figure below. By editing
the options file it is possible to modify the output format of the isometric. Some of the possible changes will be
discussed here.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
14
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.5
Administrative Options – A Worked Example
This form is used to set the Plot File Path, Name and Output Type. The form is also used to specify the
TrueType Font, Message file location and Sheet Splitting.
Comments
This descriptive text entered by the Administrator describes the content of the Options File.
Enter the comment TRAINING OPTION FILE.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
15
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
The Plots options on the Administrative Options form controls the types of isometric files that are produced,
allowing a choice of PDMS, DXF, PDMS + DXF or the more modern output formats of PDF, PRINT, IMAGE
and EMF.
The newer output types can be used with True Type Fonts.
 Plotfile (Directory/Filename) - The Plotfile options set the directory for plotfiles in the Directory text
box (this will be set to Local, i.e. the current directory, if no name is specified) and the filename in the
Filename box.
Plotfile names have a three digit number appended to them, so the default filename (plot), will give
plotfiles named plot001, plot002 etc.
If Use Drawing Name is selected, Plot files can be named based on the Pipe or Spooler Drawing Name.
If one of the other formats is selected then plot files have the appropriate suffix appended for example
if DXF output is specified, the filenames have .dxf appended (i.e. plot001.dxf etc.) and for PDF .pdf is
appended (i.e. plot001.pdf etc.).
Uncheck the PDMS and DXF Output check boxes and check PDF Output, Colour Mode BW and View.
 True Type Fonts - Selecting the True Type Font Option allows the Administrator to select one of the
TTF as defined in Admin.
Tick True Type Fonts and Font Comic Sans MS.
 Messages (Directory/Filename) - The Messages options on the Administrative Options form set the
directory for the message file
in the Directory text box (this will be set to Local, i.e. the current
directory, if no name is specified) and the filename in the Filename box.

A message file will overwrite an existing file of the same name.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
16
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Sheet Splitting - Isodraft automatically splits isometrics onto several sheets if there is too much
information to be read easily on a single sheet. The Sheet splitting options on the Administrative Options
form control how the isometrics are split. The default amount of information is described as 100%.
Increasing Sheet Splitting value with Percentage set increases the complexity of the sheets, decreasing
it will decrease the complexity of the sheet.
It is possible to change the number of sheets as follows:
Set the number of drawings you want the isometric to be split onto in this case to 3 and the select the
Drawings option.
 Split points can be set precisely by creating split ATTAs at the required 3D position in the design, there
is an option to ignore there attas. Selecting Drwg split point repeatability will create an inter-database
macro that can be run in Model.
 Miscellaneous options
Detail Flag
Creates an inter-database macro to set the Detail Flag in
Model
Increment Revisions Attribute
Will create an inter-database macro to increment the Pipe
Revision Flag in Model.
Once the settings have been made, click the OK button on the Administrative Options form and click the
Dismiss button on the Options form.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
17
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Using True Type Fonts on Isodraft Output files
In the Model Explorer navigate to PIPE 250-B-5 within ZONE-PIPING-AREA01.
Select Isometrics > Standard… from the main menu.
Select the Option File TRAINING.
Click the Apply button.
 3 Sheets will be created.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
18
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Open Modify Options form by selecting Options > Modify
from the main menu and select TRAINING option file and
click on the OK button.
Open the Administrative… form and set the sheet splitting to 100 Percentage and repeat the process to
produce a single sheet.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
19
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.6
Sheet Layout Options – A Worked Example
This form is used to define the sheet layout options for the Drawing. The divisions of the Sheet Layout
Options are explained in the following sections.
Size/Stacking
The Size/Stacking section of the Sheet Layout Options form contains the following:
 The Drawing size of the plotted sheet produced by ISODRAFT can be set to an ISO (International
Standards Organisation) A–size, to an American standard size, or to specified dimensions. The default
size is A2. The selected paper size will be divided between the isometric area, the material list area, the
title block area, the margins, and so on.
 The Drawing size option button sets the sheet to a standard size or you can specify the sheet
dimensions explicitly by entering the values in millimetres or inches into the Height and Width text boxes.
For a non-standard size, the Drawing size option will be shown as User.
Graphics
The Graphics section of the Sheet Layout Options form contains the following:
 The View direction option controls the isometric view direction.

The North arrow will always be at the top left hand corner of the drawing unless part of the isometric
itself occupies this area, in which case the arrow will be moved automatically.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
20
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Isometric type - This option controls the type of isometric plot produced:
o Combined (fab/erec) outputs a fully dimensioned and annotated isometric drawing with a detailed
material list specifying all piping components, bolts etc.
o Fabrication outputs a similar format to the Combined format except that the following information,
which is relevant only to the erector, is omitted:
-
Plant coordinates.
'Connected to' and 'continued on' comments at pipeline ends.
Attachment point details.
The sequence numbers of valves and related items in the material list, hand-wheel spindles,
flow arrows etc., unless relevant to a welded pipe assembly.
Gasket and bolt item numbers in the material list.
The erection materials list.
o Erection outputs a similar format to the combined format except that:
-
All fabrication materials are omitted from the material list apart from loose flanges. Material
list item numbers for fixed flanges are not listed, although full information is still included for
any flanges which are to be left loose for onsite welding.
o Combined + fabrication produces a combined isometric and a fabrication isometric.
o Combined + erection produces a combined isometric and an erection isometric.
o Spool. This type of isometric is intended for the fabricator. A separate fabrication drawing is
produced for each spool. Only fabrication information will appear. In-line components, including
valves, will be omitted unless they are to be welded in to form an integral part of the spool assembly
during shop fabrication.
o No Isometric plot. This option does not produce a plot file. Output filenames must be specified, e.g.
for a Material List file, to obtain any output.
 Backing sheets - It is possible to specify up to nine backing sheets. Set the Backing sheet directory
option button on the Sheet Layout options form to Project or Company and then select the sheet
filenames from the scrolling list.
Select the All off button to switch off all backing sheets.
Select Backing Sheet BlankA2.S1.plt
Project Backing Sheets are stored in the folder <project>iso>und
Typically: q evar TRAISO
C:\Users\Public\Documents\AVEVA\Projects\E3D2.1\Training\traiso select folder und
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
21
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873

The Macro BlankA2.pmlmac was used to create the plot file and is not normally needed.
 Piping line thickness - The Piping line thickness specifies the line width drawn for pipe. The value
must be between 1 and 10. The default is 3.
Specifications
The Specifications section of the Sheet Layout Options form contains the following:
 Insulation / Tracing - Allows the administrator to determine how the specifications are shown through
the selection of Off, Tube Only or Tube + Components
Flow Arrows and Margins
The Flow Arrows and Margins section of the Sheet Layout Options form contains the following:
 Flow Arrows - Flow Arrows can be drawn inline and on components.
 Margins - The Margins text boxes allow the administrator to set different widths for each margin
edge independently for each side of the drawing, i.e. the areas between the isometric frame borders
and the sheet.
For example, a large bottom margin will allow space for information from an AutoCAD drawing frame.
Set the Margins Left, Right and Top to 18mm and the Bottom to 54mm.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
22
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Reserved Areas
The Reserved Areas section of the Sheet Layout Options form contains the following:
 Reserved area height – Drawing / Material List - The Reserved area height text boxes can be used
to specify the height of an area at the bottom of the drawing area, or at the bottom of the Material List,
which ISODRAFT is to leave blank. This reserved area is inside the bottom margin. You can use a
reserved area to avoid overwriting pre-printed information on the sheet, or to allow for the addition of
other data from an underlay plot.
To create a reserved area for a drawing, enter the height of the area in the Drawing text box and to
create a reserved area for a Material List, enter the height of the area in the Material List text box. Both
are measured from the top of the bottom margin.
The following Isometric is produced as described before to show the new Backing Sheet and margin settings.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
23
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.7
Dimensioning Options – A Worked Example
Units
The Units section of the Dimensioning Options form contains the following:
 Input units - The Bore and Distance option allows the user to modify the dimensional units used in
the forms. When the input units are changed, displayed defaults (e.g. margin sizes) will change when
the window they are displayed in is re-displayed.
 Output units - The options available for dimensional units used on the drawing are as follows:
-
Metric lengths + Imperial diameters
-
Metric lengths + diameters
-
Imperial lengths inch<2ft + diameters - distances less than 2 ft. will be output in inches;
lengths of 2 ft. or more will be in feet and inches.
-
Imperial lengths inch<1ft + diameters - distances less than 1 ft. will be output in inches;
lengths of 1 ft. or more will be in feet and inches.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
24
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Set the Output Units to Metric lengths + diameters
Bores can be specified as Nominal or Actual.
The Tolerances option sets Offset and Angle tolerances. These should match the data consistency checking
tolerances used in Model.
Other Unit Settings …..
The Current Session Units Form is used to specify
the units to be used on the Isometric for example
Temperature and Pressure.
Dimensions
The Dimensions section of the Dimensioning Options form contains the following:
 Representation - Controls how dimensions are drawn for component, overall and support dimensions.
Component dimensions can be switched Off, or shown as String or Composite.
String dimensions are measured between the following points:
-
The start or end of a Branch, changes of direction & component connection points.
Composite dimensions are measured between the following points:
-
The start or end of a Branch, changes of direction (bends, elbows, etc.) & some component
connection points.
Support dimensions can be switched Off, or shown as String or Overall and have additional settings
of:
-
Alongside
Support dimensions shown on the same side of the Pipe as component
dimensions.
-
Opposite
Support dimensions shown on the opposite side of the Pipe from
component dimensions.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
25
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 The Standout text boxes control the standout distances for different dimensions.
Standout distances can be set for component dimensions, overall dimensions and support/hanger
dimensions separately. By default, support dimensions are positioned at ½ the standout for string or composite
dimensions and overall dimensions are positioned at 1½ times the standout for string or composite
dimensions.
If the string/composite standout distance is reset, the support and overall standouts will be changed
automatically so that they are still ½ and 1½ times the string / composite standout, respectively. These values
can then set them separately if required.
Standouts default from pipeline to dimensioning. d = default
The above figure shows some settings for dimensioning. The default settings in Dimensioning Options form
are:
-
String dimensioning on (and, therefore, composite dimensioning off).
Overall dimensioning off.
Support dimensioning on (String).
Valve centreline dimensioning off.
Support/hanger dimensions shown alongside other pipeline dimensions.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
26
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Vertical Pipes - This option can be set to Dimensions only, Elevations Only, Dimensions +
Elevations or Suppress all elevation notes.
 Bend radius - Standard bend radius can be set as a Distance or Diameters, for example, Diameters
5. In this case the bend radius will only be output on the Isometric if it differs from this default.
 Plotted fitting leg length - Defines the length of the Isodraft symbols.
 Fall indicator - Defines how slopes on falling lines are indicated:
-
Degrees
Ratio
Percent
Grads
Inch/foot
mm/metre
Skew Box
The Skew Box section of the Dimensioning Options form contains the following:
 Skew Display - Sets the representation of Full Box or Triangle. For Triangles, the dimensioning style
can be specified using the Triangles options.
Triangle
Full Box
 Hatching - The Administrator may use this pull-down to control hatching of the skew box triangles.
Partial hatching is controlled by setting the maximum length of hatch line (in the Extent text box) that
will be drawn. The default hatching Spacing is 3 mm.
 Zero length skews on falling lines - Falling lines containing Butt Weld Tees or Olets are often
modelled with a zero length variable angle bend at the offline p-point of each Tee or Olet. Toggling the
zero length skews checkbox allows the user to switch skew boxes on/off for the off line legs. They can
be represented by full boxes or by triangles.
 OFFTOL and NONDIR - The addition of OFFTOL attributes to catalogue ppoints means that
components can have a connection whose direction is allowed to be offset within the limits of the offtol
angle. When a ppoint has an offtol set, the attribute NOMDIR can be used to set the intended
arrive/leave direction of the component.
NOMDIR is the equivalent to the use of zero length bends to generate a small angle in a joint and is
meant to replace the use of zero length bends where possible.
In practice the main use of zero length bends is with tee components where vertical branches are
required from a sloping line. Other possibilities for offsets include flanges where it might be a
requirement to offset slightly from a horizontal flange to obtain a fall.
The supplied catalogues provided by AVEVA contain examples of offset ppoints on tees and flanges.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
27
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Tapping Branches
The Tapping Branches section allows the user to set the scale and representation on Tappings.
 The bores are now specified in millimetres.
2.8
Annotation Options – A Worked Example
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
28
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Character size – Denotes the size of drawing text.
 Continuation Notes - Continuation notes can be output on Pipe, Drawing or Pipe + Drawing.
 Support Names - Can be defined as: Off, Tag only or Tag + Item Code
 Instrument Tags/Size - Names or Item Codes can be used for instrument tags. Instrument Balloon
Sizes can be specified as a numeric value.
 Component Name Tags - Tag Components with Name.
 Pulled Bend Numbers - Pulled Bend Numbers On/Off.
Whitespace Search
The Whitespace Search section of the Annotation Options form contains the following:
 Message whitespace search accuracy - This can be set to Normal, High or Extreme and is used to
prevent text strings overwriting the graphics.
 Max Iterations to uncross lines - Set to a numeric value.
Part number enclosure types
When the border round a part number is changed the border around the weld number is also changed in
shown below:
Part number enclosure types
Straight box (default)
Weld Numbers in circles
Round Box
Weld Numbers in rectangles
Angled Box
Weld Numbers in rectangles
Spindle and Gearbox Direction Format
The direction of valve spindles and gearboxes can be changed from E,N,U to X,Y,Z.
Display of Item Codes
The Display of item codes section controls the display of item codes in the material list and the isometric.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
29
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Coordinates
The Coordinates section of the Annotation Options form contains the following:
 Format - Controls the co-ordinate origin system allowing the User to select from: User, ENU, XYZ, or
Numbers. Select the X, Y, Z option.
 Units - Controls the format of the co-ordinate value.
 End Coordinates at - Toggles the display of end co-ordinates in relation to the feature of the pipe ends
and connections.
 Origin of Coordinates - Specifies the co-ordinate origin system.
Keys
The Keys section of the Annotation Options form contains the following:
 Use name as Item code on components with SKEYs - These options enable specific SKEYs to use
the name attribute instead of a derived name from the spref attribute.
 Text to indicate Logical True/False - Replacement logical text for example YES or NO.
Click the OK button on the form.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
30
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.9
Material List – A Worked Example
Options
The Options section of the Material List form contains the following:
 Plotted List - Controls the position of the material list. The options are Off, Left or Right.
Set the Plotted List to Right.
 Character size - Set size to 3.00mm
 Listing per - Defines how the material list is generated, i.e.: one/pipe or one/sheet.
 Line Spacing Percent - Controls the space between lines on the material list.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
31
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Overflow - Sheet 1,2,3… or Sheet 1,1a,1b… or On the same sheet.
 Part Numbers - From db, individual, From db, totalled, From db, pipe indiv and Generated.
If spooling has been used, part numbers are already generated and can be taken from the database.
Columns in the material list can then be user defined, though they need to be set through another form.
 See section 2.10 Material Columns.

Fabrication Material - Material can be output Per Drawing or Per Spool.

Equipment Trim – Can be set Per Nozzle or Continuous.
Detail Texts
The Detail Texts section of the Material List form contains the following:
 Descriptions - Controls output of detail and material text and where to obtain them. The options are
Off, Detail & Material texts, Detail text only, Material text only.
 Detail Text - Can be taken from the Rtext, Stext or Ttext attributes of the SDTE element.
 Material Test - Can be taken from Xtext, Ytext, or Ztext attributes of the MATXT element.
Item Codes
Item codes can be derived from the name of SPCOM or from a UDA. The Item codes section of the Material
List form contains the following:
 Length - Set to a maximum number of characters, set the value to 12.
 Delimiter - The character used in the SPCOM name. e.g. & @ . +.
 Standard Component Source - Can be set to Spref or UDA.
 Support Component Source - Can be set to numerous values.
Typically a spref of /A1A/AABA200NN:150 would be output on the isometric as AABA200NN.
Bolting
Bolting information can be turned off; bolt lengths can be added to the descriptions and/or the item codes. The
length can replace some ‘default text’ in the Description and/or item code stored in the database by using the
replacement text input gadget.
The Bolting section of the Material List form contains the following:
 Bolting - This check box determines whether bolting information is required.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
32
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Length in Description – Can be set to Excluded, Prefixed, Appended and Replace Text.
 Length in Itemcode - Presents three options of Excluded, Appended and Replace Text.
Cutting List
The CUTTINGLIST command adds a list of cut pipe lengths to the material list. Each separate pipe length is
always identified by:
• Its cut piece number, enclosed in angled brackets; e.g. <1>.
• The pipe bore.
• The cut length in mm (e.g. 2219) or feet and inches (e.g. 7’2.5/8”) depending on the type of units
selected (refer to UNITS command).
For pulled bends, the length measured around the centre line of the tube will be included on the cutting list.
The RADI attribute of the bend must be set.
A length which includes either a loose flange or a field-fit weld will have a fitting allowance incorporated into
the plotted length (refer to LOOSEFLANGEALLOWANCE command).
Any special requirements, such as a pulled bend; loose flange; a field-fit weld or cutback allowance, this will
be highlighted in the remarks column.
Additionally the user can add the following items to the table
• Item code for that pipe.
• The end preparations for the pipe, according to the following list:
PE
Plain
BE
Bevelled
TH
Threaded
SC
Screwed
SA
Saddled end
 These codes are Atexts which can be changed.
 Where a pipeline is split over more than one drawing, the cut pipe list on each drawing contains only the
pipe lengths for that sheet. The default is that the numbering will follow on from the last number on the
preceding drawing. The cut piece numbering sequence can be restarted from 1 on each continuation
drawing by giving the command CUTTinglist PERDrawing
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
33
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Cutback Rules
The Cut Back Rule Definition form is displayed from the Cutback Rules… Link Label.
The following are typical cutback Rules
CUTBack 2 INCH ON ALL BENDS WITH (ABOR GE 100 AND ABOR LT 200)
CUTBack 175 ON THREAD
Pipe Piece Names
Pipe Piece Names can be sub-stringed using delimiters, tagged and included in the Cutting List.
Spooling
The Spooling section of the Material List form contains the following:
 Spool Numbers - Off, From db, Number across Sheets or Number per Sheet.
 Spool Prefix - Off, Default (Atext 257), From SPLP attribute (Spooler database) or Text.
 Spools can also include Pspools Names
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
34
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Material List File
The Material List File section of the Material List form allows the user to determine whether the material list
can be output to a file per drawing or for all drawings, the size of the file, the directory and filename.
Check the Material list file check box. Click the OK button on the form.
2.10 Material Columns – Worked Example
If the SPOOL module is used, with the part numbers from the database option, the Administrator is able to
define the material list format. Further to this, the user can specify which items to appear on the list, and in
what order they appear.
The form controls the content, nature and order of standard column details in the material list. Additional
columns can also be defined by setting column title, attribute or UDA, column width and order.
To use the form select the ‘?’ button under the required column
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
35
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Select the Attribute Type of Standard, Component, or Spref and click
the OK button.
Selecting Standard gives the normal items used on the Material List.
Selecting Component gives information about the component for
example position.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
36
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Selecting Spref gives information stored on the spref for example a UDA.
Add the following columns:
Title 1
Title 2
Fill
From
Width
1
Part
No
PARTNUMBER
Standard
3
2
Description
3
N.S.
4
Item Code
5
Quantity
6
Weight
DESCRIPTION
Standard
41
BORE
Standard
8
ITEMCODE
Standard
12
QUANTITY
Standard
8
WEIG
Component
10
Uncheck Material List Gridlines and Check Weight Fabrication Total, Erection Total and Combine Total.
Click the OK button on the form.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
37
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.11
Weld Numbering
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
38
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Weld Numbers - Checking the box activates the form to generate weld numbers on the isometric.
 Source - Contains options of Generated or From db.
 Types - Contains options of All, Shop or Field.
 Weld table - Check the box to produce a weld table. Use the Corner, Xpos, Ypos, and Char Height
text boxes to position and construct table content.
Check the Weld Numbers and Weld Table check boxes.
If the From db option is chosen as a Source, the Additional Welds check box becomes active.
The Weld Table can be defined as shown below:
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
39
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.12 Pipe / Spldrg Attribute Table – A Worked Example
The following option is only available when detailing with Pipe Spools or System Isometrics.
 Setting X and Y Position coordinates and Char height automatically check the Pipe attributes table
position and column definition check box.
 Clicking the ? button allows access to the pipe attributes including UDAs.
 Select the Example Column Definitions link label to view a typical example.
Click the OK button on the form.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
40
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.13 Revision Table
 Setting X and Y Position coordinates and Char height automatically check the Revision table
position and column definition check box.
 Clicking the ? button allows access to the pipe attributes including UDAs.
 Select the Example Column Definitions link label to display typical examples.
 The column definitions displayed would need to be set up by the system administrator in Lexicon.
2.14 Bend Table and File
This option is only available if Part numbers are generated from the database.

Setting X and Y Position coordinates and Char height automatically check the Bend table check
box.

A file will be created containing:
-
Schematic drawing of bend (dimensioned and annotated.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
41
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
-
Table with leg lengths radii and angles.
2.15 Reports and Symbol File
Enables the Output to file of the following reports:
 Material Control File.
 Cut Pipe Lengths.
 Centreline Lengths.
 Supports Summary.
 Bolt Report.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
42
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Transfer File (save a copy of the intermediate data transfer file from Isodraft to Isodraw - required if
reporting a fault to AVEVA).
 Symbol Definition - to load existing saved User defined symbol definitions from binary file or load in
macro file containing User defined symbols.
2.16
Title block
 Customises the standard title block.
 Adds extra lines of text, and creates boxes round them by using underscore and vertical bar characters.
 When an isometric drawing is reissued after a change, the issue number of the drawing can be updated
and plotted automatically by ISODRAFT. The issue number is taken from the REV attribute of the pipe
being detailed.
2.17
Attribute Frame Texts
Enables positioning of standard or UDA attributes of pipe or spool drawing. The text size and angle can be
specified.
 It is normal practice to position each text on a project backing sheet.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
43
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
In this example the Pipe NAME has been positioned X 380mm, Y 37mm and Height 3.0mm.

As True Type Fonts are being used in this example all the text shown has been added as described in
the next section “Standard Texts”.
2.18 Standard Texts
 Enables standard isometric annotation to be repositioned.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
44
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 User Defined Text can be positioned.
 Options include character height, angle and boxing.
Using True Type Fonts on Isodraft Output files
Currently in Isodraft there is only the option to underlay a Plot File. As True Type Fonts are NOT supported
on Plot Files, all the Text must be added in Isodraft.
The Administrator is limited to the amount of Standard text that can be added via the form so it is necessary
to edit the option file manually using a suitable text editor. Typical syntax is as follows:
TextPosition 'TITLE' X 335mm Y 50mm CharHeight 3mm
TextPosition 'DRWG. No' X 334mm Y 37mm CharHeight 3mm
TextPosition 'SHEET' X 429mm Y 37mm CharHeight 3mm
TextPosition 'Third Angle Projection' X 334mm Y 20mm CharHeight 3mm
TextPosition 'A2' X 555mm Y 21mm CharHeight 8mm
TextPosition 'SCALE' X 476mm Y 20mm CharHeight 3mm
TextPosition 'Drawn to' X 409mm Y 20mm CharHeight 3mm
TextPosition 'DRAWN BY' X 334mm Y 32mm CharHeight 3mm
TextPosition 'DATE' X 429mm Y 32mm CharHeight 3mm
TextPosition 'CHECKED BY' X 333mm Y 26mm CharHeight 3mm
TextPosition 'DATE' X 409mm Y 26mm CharHeight 3mm
TextPosition 'JOB No' X 476mm Y 32mm CharHeight 3mm
TextPosition 'LOCATION' X 476mm Y 26mm CharHeight 3mm
TextPosition 'REV No' X 19mm Y 48mm CharHeight 3mm
TextPosition 'REVISION' X 45mm Y 48mm CharHeight 3mm
Typical Option File Including a Backing Sheet
The following Isometric has been produced using the option file TTF_with_backing_sheet.opt.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
45
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.19
Component Tags
 Enables output of selected component attributes including UDAs in the isometric drawing area.
 Also allows for output of blank box.
 Option for style of boxing (unboxed, straight, angled, round, triangular or round).
2.20 Detail Plots
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
46
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Enables the display on the isometric of details of particular items of interest, for example:
-
Welded supports.
-
Drain and vent assemblies.
-
Reinforcement pads.
-
Complex manifolds and so on.
Plot is produced in Draw or any other suitable 2D drawing program.
All branch members and specification components possess a DPFN attribute, which can be set to hold a Detail
Plot File Name. Dpfname ‘/C:\AVEVA\Plant\PlantTraining2.1\Training\userdata\tapping.plt’. In this
example the DPFN has been set on Instrument /FE-117.
Isodraft can automatically pick up these plot files when detailing and place them on the isometric. The detail
plot is output on the same drawing sheet as the component with which it is associated.
Detail Area output is switched on using the ‘Detail Plots’ form. The plots can be positioned by stacking them
from a position and in a direction. Up to 20 Detail Areas can be plotted on a single isometric.
3D View of Instrument Flanges
2D Detail Plot
Detail plots may also include the parameterised values of system and user defined attributes (UDAs). The
User can select which attributes to show, the x & y co-ordinate (relative to the origin of the plot file), the
character height and the angle at which the text is to be plotted.
The different attribute types are displayed as follows:
-
Array type attributes are shown separated by a new line.
-
Reference attributes are expanded to give the full AVEVA E3D name.
-
Logical attributes are output as T or F.
-
Position, orientation and direction attributes are separated by spaces.
Example Detail on Plot
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
47
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
In the example above, the Detail Plot is positioned as shown and the Attributes NAME and SPRE are displayed
in the positions shown below.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
48
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.21 Compipe Interface
Used for outputting data to the Compipe module of the Comdace program. This is a user specific facility.
2.22 Alternative Texts
All of the default texts output on an isometric can be changed or removed using these forms.
The form is split down into various parts of the
Isometric
And a choice of Default, User or no text.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
49
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
2.23 IDF Processing
This enables system commands to be executed either before or after Isodraw processes the intermediate
transfer file.
2.24 Change Highlighting
Change highlighting represents changed items on a drawing in a different colour. Change Highlighting enables
you to set standards for how changed items on drawings will be represented. By default, Change Highlighting
is OFF. If set to be ON, all changed components complying with the defined change highlighting rules, will be
shown in the specified highlight colour.
A Change Rule applies to components only.
For table entries, material list entries,
annotations and Dimensions; these will
always be drawn in the specified highlight
colour if they have changed. The default
highlight colour is red. The user may specify
one of 12 pen colours to represent the
changed items.
In order to determine which items have
changed a Comparison Date must be
specified, this determines the baseline in time
for the drawing. Any item that has changed
since this baseline time will then be subject to
Change Highlighting. The Comparison Date
is entered either as an actual date/time or as
a Stamp.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
50
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
The Comparison date is set using Settings > Comparison Date.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
51
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Exercise 1 Isodraft Administration
Using the previous Chapter as a guide, complete the following:

Create a new Isometric Option file, modify the Material list position it on the right hand side, change
the text size to 3mm and code length to 12 characters.

Change the Material List Columns to include weight.

Reposition some text for example “NAME”.

Check that the Isometric produced is as expected.

Using the Plot file provided attach it to a suitable design item, and produce an Isometric containing a
Detail Plot.

Set Change Highlighting, modify a suitable pipe and check that Change Highlighting is shown.

Remember to set the comparison date.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
52
CHAPTER 3
3 Isodraft Symbol Libraries
This chapter explains how to set up Isodraft Symbol Libraries (ISOLB) containing the Isometric Symbol
Templates (ISOTM). This allows the Administrator to create and modify Isometric Symbol Keys.
Symbol keys are used in Isodraft to represent piping symbols on the isometric plot. Some examples are:

This Chapter should be read in conjunction with Chapter 2 Isometric Administration.

Symbol Key Reference Index of the AVEVA E3D Help describes which Isodraft Symbols can be
customised.
Copyright © 2012.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
53
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
3.1
Entering Isometric Symbol Library Administration Mode
To be able to create or modify Isometric Symbol Libraries the administrator will need to enter the Draw
Isometric Symbol Library application.
Select Isodraft > Modules > Draw …
Pick Yes
Pick No
Alternatively Login to AVEVA E3D using the details provided by the trainer. They will typically be as shown
below:
Project: Training (TRA)
Username: A.DRAWADMIN
Password: A
MDB: A-PIPING
After entering the login details click
the Draw tile.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
54
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
3.2
Creating an Isometric Symbol Library – A Worked Example
To create a new isometric symbol library (ISOLB), navigate to the appropriate LIBY or create a new LIBY by
selecting the Create option from the Library button within Libraries group from the Admin tab. The Create
LIBY form is displayed.
Enter the Name AVEVA-ISO-LIBY and click the OK
button.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
55
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
The Library Attributes form is prompted. Click the Apply and Cancel buttons to close the form.
At the correct LIBY element, select the Create option from the Isodraft Symbol button within Libraries
group from the Admin tab to display the Create ISOLB form.
Enter the Name AVEVA-ISO-LIBY/ISOSYMBOL and click the OK button to confirm.
The Isodraft Symbol Library form will then be displayed. The ISOLB is effectively a drawing sheet
template, on which ISOTM’s are placed. The dimensions must be specified, either explicitly or by selecting
a standard sheet size.
The Isodraft Symbol Library can reference a backing sheet; select the required sheet, by using either the
Reference or Filename options.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
56
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
If attributes are defined at ISOLB
level, they will be inherited by the
ISOTM elements on creation. Click
on the Attributes button to set
values for Text colour, spacing, line
spacing, etc. (These attributes can
be modified for individual ISOTMs if
required.)
Select Apply and Cancel on both
the Iso Symbol Library Attributes
form and the Isodraft Symbol
Library form
3.3
Creating Isodraft Symbol Templates – A Worked Example
The Isodraft Symbol Templates allows the Draw administrator to produce user-defined isometric symbols
using the Draw interface. The symbol definition is made up of two components, straights and markers.

Straights - can be solid for normal lines, dashed for insulation and chained for tracing.

Markers - can be defined for symbol arrive and leave points, tee points and spindle points.
Select the Create option from the Isodraft Symbol
button within Templates group from the Admin tab
The New menu option is displayed.
Select Isodraft Symbol Template option from the New menu option and click Create button to display Create
ISO Symbol Template form.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
57
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Select AVEVA ISOLIBY/ISOSYMBOL and enter name AVEVA-ISO-LIBY/ISOSYMBOL/ISOTM1
Click the Create button.
The Symbol Template form is displayed and is used to define a new symbol or redefine an existing symbol.

Symbol Key Reference Index of the AVEVA E3D Help describes which Isodraft Symbols can be
customised.
Enter the Skey name PCFL.

If the SKEY specified in the field already exists,
the symbol would be redefined.
Enter the Base Skey name CVFL.

The Base Skey must exist and be user
definable. Any new symbol definition takes its
characteristics from the Base SKEY specified.
Enter the Spindle type required: NONE.
 NONE is the default value. There are 13 spindle
available spindle types 01SP-13SP.
Click Apply Button and Cancel to close the form.

Spindle Skeys of the AVEVA E3D Help describes the definition of Spindle symbols.
Scale changes the size of the symbol, without redefining the co-ordinates of the plotted shape (100% = full
size).
The Orientation option list has the following options:
 None - specifies a symmetrical fitting, where the flow is not relevant.
 Flow - specifies a fitting for which the flow direction is important, such as check valves.
 Reducer - specifies a reducing fitting.
 Flange - specifies a fitting which begins with a flange and is preceded by a gasket.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
58
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Check boxes exist for the display of the following: Flow arrows on the symbol, otherwise they are suppressed (this is the default).
 Dimensions (this is the default) will plot dimensions alongside the symbol.
 Fill, the symbol will be filled; otherwise the symbol is not filled (default).
 Insulation will show insulation on the symbol (default), otherwise insulation is not shown.
 Tracing will show tracing on the symbol (default), otherwise tracing is not shown.
Drawing the Isometric Symbol
Select the Create Isodraft Primitive option from the
Isodraft Symbol button within Templates group from
the Admin tab to display the Create Isodraft 2D
Primitives form.
Isodraft Symbols are created using line primitives. Arrive and Leave points must be specified for the symbol.
Tee points are used to define the start position of off-line legs. The spindle position can also be specified.
Follow the following steps to create a new valve symbol.
As shown below, from the Status bar open up the Advanced Drafting Settings form.
In the Grid settings tab of this form, set a grid, (25mm x 25mm) and select the Grid On and Grid Snap On
check boxes.
From the Style option menu, select CROSSES.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
59
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Change the Grid Spacing to X: 5mm Y: 2.5mm and
the Snap Spacing to X: 5mm Y:2.5mm
Click Apply Button and Cancel to close the form.
Draw the valve shape and Add suitable arrive and leave points
Exporting Isodraft Symbols
Export the Isodraft Symbol by clicking the Export button within Isodraft Symbols
group from the Admin tab.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
60
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
The Export Isodraft Symbols
form is displayed.
There is an option which is Open Selected SYTMs under the View
option.
The options available under File are as follows:
New - Displays a file browser to create a new file, into which the Isodraft
Symbols will be exported.
Open - Displays a file browser. An existing Isodraft Symbol file will be
opened and the Isodraft Symbols will be exported into the existing file.
Close - Closes the current open file.
Specify a new file: C:\temp\Isometric_Symbols
Highlight the symbol PCFL for export into the file and click the Add button. The contents of the file will be
displayed in the File Contents section panel of the form.
Use File > Close followed by the Cancel button to close the form.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
61
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
62
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
 Component Isodraft symbols are defined on the Detail Text Definition form in Paragon
 The component symbol file is set on the Symbol Definition section of the Reports and Symbol File
Options form.
Copyright © 2014.
AVEVA Solutions Limited and its subsidiaries.
All rights reserved.
www.aveva.com
63
AVEVA Everything3D™ (2.1)
Isodraft Administration TM-1873
3.4
Importing Isodraft Symbols
Symbols can be imported by selecting the Import button within Isodraft Symbols
group from the Admin tab.
The form allows the user to import Isodraft
symbol macro files into Draw symbol libraries.
Specify the file name containing the Isodraft
symbol macros.
Enter the name of the library and symbol
library.
Enter the prefix if required for the Isometric
Symbol template.
Click the Apply button to import the given
symbol macro file into the specified Draw
symbol library.
The first symbol is positioned at the bottom left hand corner of the Sheet. Subsequent symbols are tabulated
across and up the page. When there is no space left on the Sheet, a new ISOLB is created.
Typical Isodraft Symbol Definition File
Taking the symbol template example in the adjacent form and using Draw > Primitives to create the straights,
Draw could produce a 2D representation as follows:
SYMBOLFILENAME /NEW_SYMBOLS
SKEY 'RKFL' 'CKFL' INSU ON ORI FLOW
PEN UP 0 4 PEN UP 0 7 PEN DOWN 10 7 PEN DOWN 10 1
PEN DOWN 0 1 PEN DOWN 10 4 PEN DOWN 0 7 PEN DOWN 0 1
PEN TEE 2.5 1 PEN TEE 7.5 1 PEN TEE 2.5 7 PEN TEE 7.5 7
PEN UP 0 0 PEN INSU 10 0 PEN UP 0 8 PEN INSU 10 8
PEN UP 0 0 PEN TRAC 10 0 PEN UP 10 4
ENDSKEY
