Fire Protec on System – repair booth.
The way to connect the sprinkler to the main line.
-
Zone control valve with tamper switch (normally open)
Check valve.
Flow Switch
The are to be isolated only in case off sprinkler maintenance or replacing sprinkler
Even there are a fire inside or outside the booths the ZCV must be open
