Objective:
The objective of this experiment is to: • To test a specimen
• To draw stress- strain diagram
• To determine:
❖ Proportional limit
❖ Modulus of elasticity
❖ Yield strength
❖ Unlimited tensile strength
❖ Breaking strength
❖ Percentage of elongation
❖ Percentage of reduction in area
❖ Modulus of resilience
EQUIPMENTS:
• 10 KN Universal testing machine.
• Digital slide calipers.
• Extensometer.
Hydraulic Ram
Strain gauge
Force Censors
Loading Platform
Chucks for specimen
Tie Bars
Results:
Data Table:
Specimen type: Mild Steel
Initial gauge length, L(i)=50mm
Initial diameter of specimen, d(i), = 9.11 mm
Initial cross section area of the specimen, A(i)= 65.18 mm²
Final diameter of specimen, d(f)= 5.31 mm
Final cross section area of the specimen, A(f)= 22.15 mm²
Final gauge length, L(f) = 59.6 mm
Obs. No.
Force(KN)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
0
1
2
3
4
5
6
7
8
9
10
10.5
11
11.5
12
12.5
13
13.5
14
14.5
15
Extensometer
0
0.001
0.003
0.005
0.008
0.012
0.018
0.024
0.028
0.033
0.038
0.04
0.042
0.045
0.047
0.05
0.052
0.054
0.055
0.056
0.058
Strain, €(mm)
Stress (Mpa)
0
0
0.00002 15.34212949
0.00006 30.68425898
0.0001 46.02638846
0.00016 61.36851795
0.00024 76.71064744
0.00036 92.05277693
0.00048 107.3949064
0.00056 122.7370359
0.00066 138.0791654
0.00076 153.4212949
0.0008 161.0923596
0.00084 168.7634244
0.0009 176.4344891
0.00094 184.1055539
0.001 191.7766186
0.00104 199.4476833
0.00108 207.1187481
0.0011 214.7898128
0.00112 222.4608776
0.00116 230.1319423
Obs. No.
Force(KN)
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
15.5
16
16.5
17
17.5
18
18.5
19
19.5
20
20.5
21
21.5
22
22.5
23
23.5
24
24.5
25
24.5
24
24.5
25
25.5
26
26.5
27
27.5
28
28.5
Extensometer
0.06
0.062
0.064
0.065
0.067
0.069
0.07
0.072
0.074
0.076
0.078
0.08
0.082
0.083
0.087
0.089
0.094
0.15
0.225
0.27
0.31
0.4
0.461
0.5
0.56
0.63
0.74
0.85
0.97
1.14
1.25
Strain, €(mm)
Stress (Mpa)
0.0012 237.8030071
0.00124 245.4740718
0.00128 253.1451365
0.0013 260.8162013
0.00134 268.487266
0.00138 276.1583308
0.0014 283.8293955
0.00144 291.5004603
0.00148 299.171525
0.00152 306.8425898
0.00156 314.5136545
0.0016 322.1847192
0.00164 329.855784
0.00166 337.5268487
0.00174 345.1979135
0.00178 352.8689782
0.00188 360.540043
0.003 368.2111077
0.0045 375.8821724
0.0054 383.5532372
0.0062 375.8821724
0.008 368.2111077
0.00922 375.8821724
0.01 383.5532372
0.0112 391.2243019
0.0126 398.8953667
0.0148 406.5664314
0.017 414.2374962
0.0194 421.9085609
0.0228 429.5796257
0.025 437.2506904
Obs. No.
Force(KN)
53
54
55
56
57
58
59
60
61
62
63
64
Graph:
29
29.5
30
30.5
31
31.5
32
32.5
33
32
31.5
30
Extensometer
1.42
1.52
1.75
1.89
2.15
2.72
3.63
4.56
5.38
6.5
7.8
8.75
Strain, €(mm)
Stress (Mpa)
0.0284 444.9217551
0.0304 452.5928199
0.035 460.2638846
0.0378 467.9349494
0.043 475.6060141
0.0544 483.2770789
0.0726 490.9481436
0.0912 498.6192083
0.1076 506.2902731
0.13 490.9481436
0.156 483.2770789
0.175 460.2638846
Discussion:
The primary objectives of this experiment were to get a stress-strain curve and
determine the specimen's breaking tensile strength. The graph makes it clear
how closely stress and strain are related. The graph's curve experiences an
increase known as yielding as it reaches the proportional limit. At this point, the
material starts to undergo plastic deformation. A material becomes flexible and
may stretch without needing more stress once it reaches its yield point. The
strain grows in together with the tensile load until it reaches its maximum
tensile strength. The specimen can be stretched even more by decreasing the
weight. The graph shows the specimen's breaking point.
Conclusion:
According to the results of a tension test taken on a mild steel specimen, mild
steel has good toughness, high ductility, and high tensile strength. It is ideal for
applications requiring strength and the capacity to absorb energy under tensile
pressures since it can experience significant plastic deformation after failure.
Reference:
1. Universal Testing Machine – Components and Functions - The
Constructor
2. Universal testing machine - Wikipedia
