Lab 8: MATLAB – Curve Fitting – Least Squares
Regression
➢
PREPARED BY ENG. SARAH ZEIDAN
➢
SUBJECT: NUMERICAL ANALYSIS LAB – MATH 284L
➢
DUE ON: THURSDAY, 31, OCT. 2024
31 OCT. 2024
MATH 284L – Eng. Sarah Zeidan
2
Outline
 Curve Fitting – Linear Regression
 Recall
 Method 3 – Using Curve
Fitting Apps/Tool
 Steps
 Example 1
 By-hand/Excel Solution
 Notations
 MATLAB Solutions
 Notes
 Linear Model
 Method 1 – Basic Code
 Steps
 Note + Code
 Method 2 – Using ployfit() function
 Steps
 Code
 Extra Practice
 Assignment Five
 Exercise 1
 Exercise 2
 Reference & Useful Links
31 OCT. 2024
MATH 284L – Eng. Sarah Zeidan
Curve Fitting – Linear Regression – Recall
3
Equations & Formulas Used
Line Equation:
𝑦𝑖 = 𝑎0 + 𝑎1 𝑥𝑖
σ𝑛𝑖=1 𝑦𝑖 = 𝑛𝑎0 + 𝑎1 σ𝑛𝑖=1 𝑥𝑖
σ𝑛𝑖=1 𝑦𝑖 𝑥𝑖 = 𝑎0 σ𝑛𝑖=1 𝑥𝑖 + 𝑎1 σ𝑛𝑖=1 𝑥𝑖 2
𝑛: 𝑛𝑢𝑚𝑏𝑒𝑟 𝑜𝑓 𝑑𝑎𝑡𝑎 𝑝𝑜𝑖𝑛𝑡𝑠
σ𝑛𝑖=1 𝑦𝑖
𝑦=
𝑛
Normal Equations: (used to compute
𝑎0 & 𝑎1 )
Arithmetic Mean:
𝑛
The Total Sum of the residuals squared:
𝑆𝑡 = ෍(𝑦𝑖 −𝑦)2
𝑖=1
The Standard Error of the Estimates (𝑆𝑦/𝑥 ):
𝑺𝒓 : the sum of squares of the residuals.
𝑛
𝑆𝑦/𝑥 =
𝑆𝑟
, 𝑆𝑟 = ෍[𝑦𝑖 −(𝑎0 + 𝑎1 𝑥𝑖 )]2
𝑛−2
𝑖=1
The Correlation Coefficient (𝑟):
𝑟=
𝑆𝑡 − 𝑆𝑟
× 100 → r = 100 for perfect fit.
𝑆𝑡
31 OCT. 2024
MATH 284L – Eng. Sarah Zeidan
4
Curve Fitting – Linear Regression – Example 1
➢
Use the least-square regression to fit a straight line to the given data.
➢
Along with the slope and intercept, compute the standard error of the estimate
and the error correlation coefficient. Plot the data and the regression line.
➢
You can find your instructor’s PDF solution on Moodle, “Sheet 1 – Solution”.
x
0
2
4
6
8
10
y
4.5
8.2
11.5
15.8
21
23.5
31 OCT. 2024
MATH 284L – Eng. Sarah Zeidan
5
Curve Fitting – Linear Regression – Example 1 – By
Hand/Excel Solution (1)
Given
Computed
For the error
calculations
𝒙
𝒚
𝒙×𝒚
𝒙𝟐
𝑺𝒓
𝑺𝒕
𝒚𝒊 = 𝟒. 𝟐𝟒𝟕𝟔𝟏 + 𝟏. 𝟗𝟔𝟕𝟏𝟒 𝒙𝒊
0
2
4
6
8
10
30
4.5
8.2
11.5
15.8
21
23.5
84.5
0
16.4
46
94.8
168
235
560.2
0
4
16
36
64
100
220
0.06370
0.00033
0.37967
0.06273
1.03077
0.17557
1.71277
91.83964
34.61322
6.67344
2.94706
47.84074
88.67424
272.58834
4.24761
8.18189
12.11617
16.05045
19.98473
23.91901
-
MATH 284L – Eng. Sarah Zeidan
31 OCT. 2024
6
Curve Fitting – Linear Regression – Example 1 – By
Hand/Excel Solution (2)
➢
Using the data above, the normal equations for the given set of data are:
84.5 = (6)𝑎0 + 𝑎1 30
𝑎 (𝑖𝑛𝑡𝑒𝑟𝑐𝑒𝑝𝑡) = 4.24761
𝑠𝑜𝑙𝑣𝑖𝑛𝑔 𝑡ℎ𝑒𝑠𝑒 𝑒𝑞𝑢𝑎𝑡𝑖𝑜𝑛𝑠 ⟹ 0
𝑎1 (𝑠𝑙𝑜𝑝𝑒) = 1.96714
560.2 = 𝑎0 30 + 𝑎1 220
➢
Thus, the best fit is: 𝑦𝑖 = 4.24761 + 1.96714 𝑥𝑖
➢
The Mean: 𝑦 = 14.0833
➢
The Standard Error of the Estimates: 𝑆𝑦/𝑥 = 0.65436
➢
The Correlation Coefficient: 𝑟 = 99.6853 % ≈ 99.69%
MATH 284L – Eng. Sarah Zeidan
Basic Code
31 OCT. 2024
7
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 1 – Steps
➢ Steps Followed:
Define x and y, as the given set of data, and n to be the length of x.
2. Compute x*y & x squared, then the sum of x, of y, of x*y, and of x squared.
3. Solve the normal equations to get the intercept 𝐚𝟎 and the slope 𝐚𝟏 . This could
be done as follows:
1.
1.
2.
3.
Write the coefficient square matrix and the constant column vector, then either use:
The right-division (backslash \) operator, or
The inv() function
Put your best fit (or the regression line) as, 𝒚𝒎𝒐𝒅𝒆𝒍 = 𝒂𝟎 + 𝒂𝟏 𝒙𝒊
5. Plot the original data set along with the regression line obtained in step 4.
6. Compute the standard error of the estimate (𝑆𝑦/𝑥 )and the error correlation
coefficient (𝑟).
4.
MATH 284L – Eng. Sarah Zeidan
Basic Code
31 OCT. 2024
8
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 1 – NOTE
➢ Solving Linear Equations:
➢
With the matrix notation, a system of simultaneous linear equations is written as
𝑨𝒙 = 𝑩, where there are as many equations as unknown.
➢
𝑨 is a given square matrix of order n, 𝑩 is a given column vector of n components and 𝒙
is an unknown column vector of n components.
In linear algebra, the solution for 𝒙 is 𝒙 = 𝑨−𝟏 𝐁, 𝐰𝐡𝐞𝐫𝐞 𝑨−𝟏 𝒊𝒔 𝒕𝒉𝒆 𝒊𝒏𝒗𝒆𝒓𝒔𝒆 𝒐𝒇 𝑨.
➢
In our example, the normal equations are the system of equations to be solved (for a):
➢
𝑠𝑢𝑚_𝑦 = 𝑛 ∗ 𝑎0 + 𝑎1 ∗ 𝑠𝑢𝑚_𝑥
84.5 = (6)𝑎0 + 𝑎1 30
ቊ
→ ቊ
𝑠𝑢𝑚_𝑥_𝑦 = 𝑎0 ∗ 𝑠𝑢𝑚_𝑥 + 𝑎1 ∗ 𝑠𝑢𝑚_𝑥_𝑠𝑞𝑢𝑎𝑟𝑒𝑑
560.2 = 𝑎0 30 + 𝑎1 220
➢
𝒏
𝒔𝒖𝒎_𝒙
𝒔𝒖𝒎_𝒚
The coefficient matrix 𝑨 = 𝒔𝒖𝒎_𝒙 𝒔𝒖𝒎_𝒙_𝒔𝒒𝒖𝒂𝒓𝒆𝒅 , and the vector 𝑩 = 𝒔𝒖𝒎_𝒙_𝒚
MATH 284L – Eng. Sarah Zeidan
Basic Code
31 OCT. 2024
9
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 1 – NOTE
➢ Solving Linear Equations:
➢
𝒏
𝒔𝒖𝒎_𝒙
𝒔𝒖𝒎_𝒚
The coefficient matrix 𝑨 = 𝒔𝒖𝒎_𝒙 𝒔𝒖𝒎_𝒙_𝒔𝒒𝒖𝒂𝒓𝒆𝒅 , and the vector 𝑩 = 𝒔𝒖𝒎_𝒙_𝒚
➢
Our equations are solved for 𝑎0 and 𝑎1 , this could be done in MATLAB in two ways:
1)
Using the backslash (\) operator, which uses the numerically reliable way of solving the
system of linear equations, namely, the well-known process of Gaussian Elimination.
➢
2)
Define A and B, put a = A\B → a will be a column vector of 𝒂𝟎 = a(1) and 𝒂𝟏 = a(2).
Using the matrix inverse function, inv()
➢
Define A and B, put a = inv(A)*B → a will be a column vector of 𝒂𝟎 = a(1) and 𝒂𝟏 =
a(2). The matrix A MUST be a square matrix.
MATH 284L – Eng. Sarah Zeidan
Basic Code
31 OCT. 2024
10
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 1 – Steps
➢ Steps Followed:
Define x and y, as the given set of data, and n to be the length of x.
2. Compute x*y & x squared, then the sum of x, of y, of x*y, and of x squared.
3. Solve the normal equations to get the intercept 𝐚𝟎 and the slope 𝐚𝟏 . This could
be done as follows:
1.
1.
2.
3.
Write the coefficient square matrix and the constant column vector, then either use:
The left-division (backslash \) operator, or
The inv() function
Put your best fit (or the regression line) as, 𝒚𝒎𝒐𝒅𝒆𝒍 = 𝒂𝟎 + 𝒂𝟏 𝒙𝒊
5. Plot the original data set along with the regression line obtained in step 4.
6. Compute the standard error of the estimate (𝑆𝑦/𝑥 )and the error correlation
coefficient (𝑟).
4.
MATH 284L – Eng. Sarah Zeidan
Basic Code
31 OCT. 2024
11
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 1 – Code
% Step 1: Define x and y, and n as the length of x
x = 0:2:10;
y = [4.5 8.2 11.5 15.8 21 23.5];
n = length(x);
Check the full commented code in
the attached notepad file named
“Lab_8_Curve_Fitting_Method_1”.
% Step 2: Compute the required summations
x_y = x.*y;
% Step 3: Solve the normal equations
x_squared = x.^2;
B = [sum_y; sum_x_y];
sum_x = sum(x);
A = [n sum_x; sum_x sum_x_squared];
sum_y = sum(y);
a = A\B
sum_x_y = sum(x_y);
% a = inv(A)*B
sum_x_squared = sum(x_squared);
% Set a0 (intercept) and a1 (slope)
a0 = a(1);
a1 = a(2);
MATH 284L – Eng. Sarah Zeidan
Basic Code
31 OCT. 2024
12
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 1 – Code
% Step 4: Write your model as a0 +
a1*x
ymodel = a0 + a1*x;
% Step 6: Compute the standard error
of the estimate
% and the correlation coefficient
% Step 5: Plot your original data and
your regression line (model)
plot(x,y,'bd',x,ymodel,'mo-')
xlabel('x')
ylabel('y and ymodel')
legend('y','ymodel')
title('The Best Fit')
grid on
% the mean:
y_mean = mean(y);
s_t = sum((y-y_mean).^2)
s_r = sum((y-ymodel).^2)
s_y_x = sqrt(s_r/(n-2))
r_squared = (s_t - s_r)/s_t
r = sqrt(r_squared) *100
MATH 284L – Eng. Sarah Zeidan
Using polyfit() Function
31 OCT. 2024
13
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 2 – Steps
➢ Steps Followed:
1.
2.
3.
4.
5.
Define x and y, as the vectors containing the coordinates of the given data
points, and m as the degree of the polynomial to fit.
Use the polyfit() function to get the intercept 𝐚𝟎 and the slope 𝐚𝟏 .
Syntax: p=polyfit(x,y,m), Fit polynomial to data.
Put your best fit (or the regression line) as, 𝒚𝒎𝒐𝒅𝒆𝒍 = 𝒂𝟎 + 𝒂𝟏 𝒙𝒊
Plot the original data set along with the regression line obtained in step 4.
Compute the standard error of the estimate (𝑆𝑦/𝑥 )and the error correlation
coefficient (𝑟).
P = polyfit(X,Y,N) finds the coefficients of a polynomial P(X) of degree N that fits the data Y best in a least-squares
sense. P is a row vector of length N+1 containing the polynomial coefficients in descending powers, P(1)*X^N +
P(2)*X^(N-1) +...+ P(N)*X + P(N+1).
MATH 284L – Eng. Sarah Zeidan
Using polyfit() Function
31 OCT. 2024
14
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 2 – Code
% Step 1: Define x and y, and n as the order of the polynomial
x = 0:2:10;
y = [4.5 8.2 11.5 15.8 21 23.5];
n = length(x);
m = 1;
% Step 2: Use the polyfit() function
% The order of the polynomial is 1,
% NOTE: here p(1) is the slope and p(2) is the intercept
p = polyfit(x,y,m);
Check the full commented code in
a1 = p(1)
the attached notepad file named
“Lab_8_Curve_Fitting_Method_2”.
a0 = p(2)
MATH 284L – Eng. Sarah Zeidan
Using polyfit() Function
31 OCT. 2024
15
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 2 – Code
% Step 3: Write your model as a0 +
a1*x
ymodel = a0 + a1*x;
% Step 5: Compute the standard error
of the estimate
% and the correlation coefficient
% Step 4: Plot your original data and
your regression line (model)
plot(x,y,'bd',x,ymodel,'mo-')
xlabel('x')
ylabel('y and ymodel')
legend('y','ymodel')
title('The Best Fit')
grid on
% the mean:
y_mean = mean(y);
s_t = sum((y-y_mean).^2)
s_r = sum((y-ymodel).^2)
s_y_x = sqrt(s_r/(n-2))
r_squared = (s_t - s_r)/s_t
r = sqrt(r_squared) *100
MATH 284L – Eng. Sarah Zeidan
Using Curve Fitting APPS/Tool
31 OCT. 2024
16
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 3 – Steps
➢ Steps Followed:
1.
2.
3.
Define x and y (make sure they appear in your workspace), as the vectors
containing the coordinates of the given data points.
Go to the “APPS” tab, choose the “Curve Fitting”
from the “APPS”
section.
Specify the x and y already defined and put the polynomial to 1 and Done!
MATH 284L – Eng. Sarah Zeidan
Using Curve Fitting APPS/Tool
31 OCT. 2024
17
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 3 – Steps
Inputs
Fit name
Your data
ymodel
Outputs
Coefficients
Error
calculations
plot
MATH 284L – Eng. Sarah Zeidan
Using Curve Fitting APPS/Tool
31 OCT. 2024
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 3 –
Notations
18
➢ Goodness of Fit Notations:
➢ The Sum of Squares due to Error (SSE), also called the summed squares of
residuals  𝑺𝒓 .
➢
R-squared, also called the coefficient of determination  𝒓𝟐 .
➢
(Not required)Adjusted r-squared is generally the best indicator of the fit quality
when you compare two models in specific cases.
➢
Root Mean Squared Error (RMSE), also called the standard error of the regression (or
of the estimate)  𝑺𝒚/𝒙 .
➢ For more details, please refer to:
https://www.mathworks.com/help/curvefit/evaluating-goodness-of-fit.html
https://www.mathworks.com/help/curvefit/evaluating-goodness-of-fit.html
MATH 284L – Eng. Sarah Zeidan
Using Curve Fitting APPS/Tool
31 OCT. 2024
19
Curve Fitting – Linear Regression – Example 1 –
MATLAB Solutions – Linear Model – Method 3 – Notes
➢ After you get your results from the Curve Fitting APPS, you can save them.
➢ Also, you can ask MATLAB to generate the code behind its work:
➢
Click on “File”, in the Curve Fitting Tool Window, and choose “Generate Code”.
➢
A new script “Untitled”, with the code, will be created in your “Editor”.
➢ You can also click on the “Help – Curve Fitting Tool Help” in the Curve Fitting
Tool Window for more guidance about how to use the Curve Fitting App.
➢
you will see the Documentation for the “Interactive Curve and Surface Fitting”.
To save,
Generate code,
Etc.
To get the
Documentation
31 OCT. 2024
MATH 284L – Eng. Sarah Zeidan
20
Curve Fitting – Linear Regression – Extra Practice
➢
You can try the rest of your sheet 1 exercises.
➢
Also, here are some set of data that you can test your code on (line equation).
Set 1
Set 2
x
1
2
3
4
5
6
7
y
0.5
2.5
2.0
4.0
3.5
6.0
5.5
x
0
4
8
16
24
30
y
12
18
20
26
26
22
31 OCT. 2024
MATH 284L – Eng. Sarah Zeidan
21
Assignment Five – Exercise 1
➢ For the data shown in the table, write a code that will:
1.
Find the equation of the straight line that best fit the tabulated data (equation
of the straight line is given by y = a0 + a1*x).
2.
Find the mean, standard deviation, and standard error of estimate.
3.
Find the correlation coefficient then the coefficient of determination.
x
1
2
3
4
5
y
2
4
5
4
5
31 OCT. 2024
MATH 284L – Eng. Sarah Zeidan
22
Assignment Five – Exercise 2
➢ Use a proper code that best fit the given tabulated data to
the model: 𝑦 = 𝑎𝑒 𝑏𝑥
x
2
y
144
3
4
5
6
172.8 207.4 248.8 298.5
MATH 284L – Eng. Sarah Zeidan
31 OCT. 2024
23
Reference & Helpful Links
1. Lecture Sheet 1, Numerical Analysis Course, MATH 284, Curve Fitting,
Questions Sent By the Course Instructors (Tripoli) & Old Solutions By the
Lab Instructor.
2. D. Houcque, Introduction to MATLAB for Engineering Students,
Northwestern University, 2005.
3. Polynomial Curve Fitting:
https://www.mathworks.com/help/matlab/math/polynomial-curvefitting.html
4. Lecture Notes, Numerical Analysis Lab, MATH 284, Curve Fitting, Sent By
the Course Instructors (Tripoli & Debbieh).
5. For more about the backslash, matrix-left division:
https://www.mathworks.com/help/matlab/ref/mldivide.html
