Choosing the Right Servo Gearbox
www.agvmotor.com
When you need a Right Angle Servo Gearbox – proper sizing can make all the difference. A wide range of factors
should be considered to avoid any issue down the road. This blog shares an overview of the most crucial factors before
sizing the gearbox.
In a right-angle gearbox the input shaft and the output shaft meet at 90-degree angle. In addition, the configuration of
the system allows the torque to be transmitted from one axis to perpendicular axis.
Well, right angle Servo Gearbox can be used for various mechanical designs – including automotive transmission and
industrial applications. Make sure to choose a quality brand to ensure their efficiency, reliability and durability.
www.agvmotor.com
Different Types of Gearbox
Though there are several sub-varieties of right angle gearbox- there are typically four main
types of gearboxes including:
Worm:
worm gear boxes are looks like a lot as it sounds – a worm drives the gear. The design of the gear
box enables the control over rotational direction that helps to regulate the speed and adds high
torque transmission.
Bevel:
as its name suggests it contain two interlocking bevel gears. On a standard gear – the pitch
surface is cylindrical. The angle is formed by the pitch face and the axis is called pitch angle.
Bevel gears are classified by their geometry and each type of bevel gear offers its advantage.
www.agvmotor.com
Helical:
They are known for their smooth and quiet operation – making a
reliable choice for industrial applications. Helical gear provides certain
advantages like improved load capacity and quieter operation –
especially in right angle configuration.
Planetary:
it is an age-old design – that got its name because of the different gears
move together like planets. The torque of the gearbox is divided over
three gears and the torque is three times higher than typical gearboxes.
www.agvmotor.com
Choosing the Appropriate Gear Box
While determining the right angle gearbox that works best for
mechanical design – it is crucial to identify the key aspects of the
design and application.
You should determine the target speed and then output torque and
lastly consider service factor. Make sure to consider the horsepower
that would be transmitted in the application. Also, gearbox
manufacturer publishes charts that accounts for the working
condition of the gearbox to withstand hours of service per day and
type of load. Follow the step-by-step sizing instruction to choose the
right equipment.
www.agvmotor.com
Contact Us:
Shenzhen Hengketong Robot Co., Ltd.
Address : Block 4, Tian'an Cloud Park, Longgang
District, Shenzhen, Guangdong 518129, China
Phone Number : 86 181 2370 8792
Email : market@agvmotor.com
www.agvmotor.com
Thank You!
