Types of Boilers
: Purvendu Pratik (B22ME051)
Boilers are essential components in various industrial and residential applications,
primarily used for heating water or generating steam. They come in different types,
each designed to meet specific needs based on efficiency, capacity, and fuel type.
Here are the main types of boilers:
1. Fire-Tube Boilers:
Description: In fire-tube boilers, hot gases pass through tubes that are surrounded
by water. The heat from the gases is transferred through the tube walls to heat the
water.
Applications: Commonly used in small-scale industries and for heating buildings.
Advantages: Simple design, easy to operate, and relatively low cost.
Disadvantages: Lower efficiency and limited capacity for high-pressure steam.
2. Water-Tube Boilers:
Description: In water-tube boilers, water flows through tubes that are heated
externally by combustion gases. These boilers can handle higher pressures and are
more efficient.
Applications: Used in power plants and large industrial facilities.
Advantages: High efficiency, ability to produce high-pressure steam, and safer
operation.
Disadvantages: More complex design and higher initial cost.
3. Electric Boilers:
Description: Electric boilers use electricity to heat water or generate steam. They
are compact and do not require a fuel storage system.
Applications: Suitable for areas with strict emissions regulations and where
electricity is cheaper than other fuels.
Advantages: Clean operation, no emissions, and easy installation.
Disadvantages: Higher operational costs due to electricity prices and limited
capacity.
4. Condensing Boilers:
Description: These boilers are designed to recover heat from exhaust gases by
condensing water vapor in the flue gases, thus increasing efficiency.
Applications: Used in residential and commercial heating systems.
Advantages: High efficiency and reduced fuel consumption.
Disadvantages: Higher initial cost and more complex maintenance.
5. Combi Boilers:
Description: Combination boilers provide both heating and hot water from a single
unit, eliminating the need for a separate water heater.
Applications: Ideal for small homes and apartments with limited space.
Advantages: Space-saving, energy-efficient, and cost-effective.
Disadvantages: Limited hot water supply for multiple uses simultaneously.
6. Biomass Boilers:
Description: These boilers use organic materials like wood pellets, chips, or
agricultural waste as fuel.
Applications: Suitable for sustainable energy projects and rural areas with
abundant biomass resources.
Advantages: Renewable fuel source, reduced carbon footprint.
Disadvantages: Requires regular fuel supply and maintenance, higher initial cost.
Each type of boiler has its unique advantages and limitations, making it crucial to
select the appropriate boiler based on specific requirements, fuel availability, and
operational conditions.
