A Welding Procedure Specification (WPS) is a formal document that provides detailed
instructions on how to perform a specific welding operation. It is essential for ensuring that welds
are made consistently and meet the required standards. Here are the key components typically
included in a WPS:
1. Welding Process: Specifies the type of welding process to be used (e.g., MIG, TIG, Stick).
2. Base Materials: Details the materials to be welded, including their specifications and
grades.
3. Filler Materials: Lists the type and specifications of the filler materials to be used.
4. Joint Design: Describes the geometry and dimensions of the weld joint.
5. Position: Indicates the welding positions (e.g., flat, horizontal, vertical, overhead).
6. Preheat and Interpass Temperature: Specifies the required temperatures before and
during welding.
7. Welding Parameters: Includes details such as current, voltage, travel speed, and heat
input.
8. Shielding Gas: If applicable, specifies the type and flow rate of shielding gas.
9. Post-Weld Heat Treatment: Describes any heat treatment required after welding.
A WPS ensures that all welds are performed under controlled conditions, leading to consistent
quality and compliance with relevant standards.
