Engineering Mechanics
Quiz No. 2
Semester 462
Time Allowed: 20 min
Name:
(GE 210)
ID:
1. For the shown figure determine the centroid of the shaded area (both x and y ).
y
5 cm
4 cm
3 cm
3 cm
9 cm
x
4cm
11 cm
1
2. Beam AD is loaded and supported as shown in the diagram below. Determine the
reactions at A and at C. (Neglect the mass of the bar).
200 kN
90 kN/m
60 kN/m
A
300
2m
D
C
B
5m
3m
2
