Al Maaref University Faculty of Engineering Department of Mechanical Eng Course code: MEE322L Course Title: Mechanics of Materials I Lab Experiment Title: Tensile testing on metallic materials Instructor : Hussein Mouzanar Group No.: A Students Name: Mohammad Ali Nasreddine Ahmad Fakih Jawad Rachid Yousef Kassir Date of Testing: 17-6-2020 Date of Submission: 21-6-2020 1- Objectives This tensile test was made on steel to: • Determine the modulus of elasticity of steel in addition to other properties • Learn how to use the Universal Testing Machine to test specimens in axial tension. 2- Theoretical Background Tensile test is one of the most common tests for steel. The test involves straining a test piece by tensile force, generally to fracture, for the purpose of determining tensile strength, yield strength, ductility and reduction of area. a) Modulus of elasticity: The modulus of elasticity E can be determined by finding the slope of the elastic part of the stress strain diagram; this part is linear and has the following relation: π = πΈπ Where: [π⁄π2 ] (1) π ππ π‘βπ ππππππ π π‘πππ π [ππ] { π ππ π‘βπ ππππππ π π‘ππππ [ππ/ππ] πΈ ππ π‘βπ ππππ’ππ’π ππ ππππ π‘πππ‘π¦ [ππ] b) Yield Stress and Strain: To find the yield stress and yield strain, the 0.2% offset method is used. Draw a line parallel to the elastic part after moving 0.2% on the strain axis; the intersection of this line with the curve will give the yielding point having the yield stress and the yield strain. c) Ultimate Stress and Strain: This will correspond to the stress when the loading force has its highest value. d) Failure Stress and Strain: • To determine the failure stress, look at the stress reading just before the specimen broke. 2 • To determine the failure strain, two ways can be used: 1. Measure the final length (L) and initail length (L0) of the specimen, then use the formula: ππ’ππ‘ππππ‘π¦ = πΏ−πΏ0 πΏ0 (2) 2. Use the graphicl method: At the failure point, draw a line parallel to the elastic part of curve until it intersect the strain axis. The strain of the intersection point is the permanent strain, also called ductility of the material. 3- Test Procedure 3-1 Test Setup a) First we measured the dimesnions of the specimen using caliper meter b) Place the specimen in the tensile machine using the grips c) Ajust the extensometer on the specimen d) Attach the machine to a given software on the computer to give the stess-strain graph e) Adjust the testing machine to have suitable speed f) The test is applied until the specimen breaks and the resulting graph is saved 3-2 Materials and Equipments a) A cylindrical dogbone shaped steel bar is needed: Figure 1. A cylindrical dogbone shaped steel bar 3 b) Note that in our case we weren’t able to get this shape so we used a normal steel bar instead: Figure 2. Circular cross sectional steel bar c) A ruler and a caliper meter is needed to measure the dimensions properly: Figure 3.. Caliper meter d) A testing machine known as tensile machine: Figure 4. Tensile machine 4 e) An extensometer (of gage lenth=50mm) to get more accurate results in the elastic zone of test: Figure 5. Extensometer f) A computer that is attached to the machine to visualize the graphs and variation of the load with respect to displacement: Figure 6. Computer 3-3 Tasks First we measured the length using the ruler and the diameter using caliper meter; and wrote down the measurements and the error values of the length, force and displacement. Then we placed the steel bar in the machine using the grips in a way that it won’t slide. We then placed the extensometer on the specimen to get more accurate values. Afterwards, we closed the machine door to make sure that no one gets hurt during the experiment. We then opened the software that is responsible to display the loaddisplacement graph, and entered the values of the dimensions and the speed upon which the machine will run. Finally, we started the test and waited until the steel bar broke into pieces. 5 4- Results 1. Dimensions of steel bar: The steel bar had the following dimensions: { Stress-Strain curve: To get the stress-strain curve, you have to divide each force value by the original cross sectional area of the specimen and divide the extension by the initial length of the bar. 800 700 600 500 Stress (MPa) 2. ππππππ‘ππ = 10ππ ππππ πππππ‘β = 219ππ 400 300 200 100 0 0 0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.16 0.18 0.2 Strain(mm/mm) Figure 7. Stress-Strain diagram 6 3. Modulus of Elasticity: Using equation (1), we can calculate Young’s Modulus. But first we have to zoom in into the elastic zone of the curve as shown in figure 8. 700 600 Stress (MPa) 500 400 300 200 100 0 0 0.001 0.002 0.003 0.004 0.005 0.006 0.007 Strain Figure 8. Elastic part of stress- strain diagram of steel The young’s modulus is then: πΈ= 4. βπ 400 − 200 = = 200πΊππ βπ 0.002 − 0.001 Yield Stress and Strain: Using figure 8 and the 0.2% offset method discussed before, we can calculate the Yield Stress and Strain: ππ¦ = 580 πππ { ππ¦ = 0.004 7 5. Ultimate stress: Using figure 7: π = 678 πππ { π’ππ‘ππππ‘π ππ’ππ‘ππππ‘π = 0.175 6. Failure stress: Using figure 7: ππππππ’ππ = 380 πππ Ductility: Using the graphical method -mentioned before in the theoretical background- we can calculate ductility by drawing in figure 7 a line parallel to the elastic part from the rupture point. The intersection with strain axis gives the ductility: 800 700 600 500 400 Stress (MPa) 7. 300 200 100 0 0 0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.16 0.18 0.2 Strain(mm/mm) π·π’ππ‘ππππ‘π¦ = 0.17 = 17% 8 5- Discussion 1. Steel Properties: the bar showed a great resistance to tension under the tensile loading of speed 10mm/min. This explains the relatively high value of E. Thus steel is a hard and strong material and have high stiffness. Comparing the values with the internet values, the modulus of elasticity is exactly equal to that known of steel (200GPa). 2. Errors: In any experiment there is an error percentage due to inaccuracy in measurements and devices used. a) Errors in length measuring that is found by dividing smallest unit on ruler over 2: π€πΏ = ±0.05ππ b) Errors in force measuring that is given by the tensile machine: π€πΉ = ±0.5π c) Errors in displacement that is given by the tensile machine: π€πΏ = ±0.001ππ d) Errors in area measurement: ππ΄ ππ π€π΄ = √( )2 × π€πΏ 2 = √( )2 × 0.052 × 10−6 = ±7.85 × 10−7 π2 ππ 2 Where: π = 10ππ e) Errors in stress: π€π = √( ππ 2 ππ 1 −πΉ ) × π€πΉ 2 + ( )2 × π€π΄ 2 = √( )2 × 0.52 + ( 2 )2 × π€π΄ 2 ππΉ ππ΄ π΄ π΄ Where: ππ 2 π΄= = 7.85 × 10−5 π2 4 { πΉ π= π΄ 9 1. For Yield stress: π€π = ±5.8 πππ 2. For Ultimate stress: π€π = ±6.78 πππ f) Errors in strain: π€π = √( ππ 2 ππ −πΏ 1 ) × π€πΏ 2 + ( )2 × π€πΏ 2 = √( 2 )2 × π€πΏ 2 + ( )2 × π€πΏ 2 ππΏ ππΏ πΏ πΏ Where: πΏ = 0.219 π ππ π‘βπ ππππππππ πππππ‘β ππ πππ πΏ ππ π‘βπ ππ₯π‘πππ πππ (π) { πΏ π= πΏ 1. Yield strain: π€π = 4.656 × 10−6 2. Ultimate Strain: π€π = 4.021 × 10−5 g) Errors in modulus of elasticity: π€πΈ = √( ππΈ 2 ππΈ 1 −π ) × π€π 2 + ( )2 × π€π 2 = √( )2 × π€π 2 + ( 2 )2 × π€π 2 = ±0.9πΊππ ππ ππ π π Where: πΈ ππ ππππ’ππ’π ππ ππππ π‘ππππ‘π¦ (ππ) {π ππ π‘βπ π π‘πππ π (ππ) ππ‘ πππ¦ πππππ‘ ππ ππππ π‘ππ ππππ‘ π ππ π‘βπ π π‘ππππ ππ π‘βππ‘ πππππ‘ 10 3. Reasons for errors: i. Sliding of the bar during the test because of rust and the deformed shape ii. Inaccuracy of measurments of devices used for measurement and the T.M. 6- Conclusions In this experiment, we were able to calculate the modulus of elasticity of a circular cross section steel bar upon doing the tensile test. We were also able to find other properties as yielding, ultimate and failure stress. The results were reasonable and the error values were calculated for each. 7- Appendix . The following figure shows the steel bar during the test: 11
