ALL DIMENSION ARE IN MM UNLESS
OTHERWISESPECIFIED.
ALL NUTS & BOLTS ARE HOT DIP GALVANIZE.
ALL STRUCTURE WORK SHALL BE WELDED
INACCORDANCE WITH AWS D1.1
WELDINGELECTRODES SHALL BE E70XX.
ALL DIMENSION AND ELEVATION SHALL BEFIELD
VERIFIED PRIOR TO FABRICATION.
ALL CONNECTION BOLTS SHALL BE
WELDEDUNLESS NOTED OTHERWISE, MAXIMUM
FILLETWELD SHALL BE PER AISC STEEL MANUAL.
CONNECTION BOLTS SHALL BE COMPLY WITHASTM
A325/GRADE 8.8 STD.
ALL STEEL SHALL BE ASTM A36
STRUCTURALGRADE
FABRIC SPECIFICATION
MADE : AUSTRALIA
COLOR : STANDARD
WEIGHT: 340 20 GSM
TYPE : HEAVY DUTY KNITTED WITH UV
BLOCKBREAKING FORCE :2146 N
TEAR RESISTANCE : WARP 187N WEFT
359NBUSTING PRESSURE 3500 Kpa
SHADE DENSITY (uvr) 90-96%
FABRIC
TYPE
HDPE
STRUCTURE
POWDER COATED
GSM
340
HDG
COLOUR
BAIGE
EPOXY PAINT
√
DWG. TITLE:
CAR PARKING 6X6 MTR CONNECTION
COLOUR
BEIGE
