VLSI ASSIGNMENT NAME - HARSH RAJ ( ROLL NO.- 21BEC019 ) DECEMBER 2023 1 1.1 Experiment 01: Design and Simulation of a 2-Input NOR Gate Aim: The aim of this experiment is to design and simulate a 2-input NOR gate using VLSI design tools. The objective is to understand the operation of a NOR gate and gain practical experience in schematic design, simulation, and layout creation. 1.2 THEORY A NOR gate is a fundamental digital logic gate that performs a logical NOR operation. It has two or more inputs and a single output. The NOR gate produces an output signal that is the logical inverse (complement) of the logical OR of its input signals. In other words, it outputs a ’1’ (high) when none of its inputs are ’1,’ and it outputs ’0’ (low) when at least one input is ’1’. 1.3 Truth Table and Diagram: 1 1.4 Circuit Design: 1) A 2-input NOR gate comprises two NMOS transistors (M1 and M2) in parallel, forming the pull-down network. M1 and M2 are controlled by inputs A and B. Their sources connect to ground (0 V), and drains go to the output node (OUT). 2) The gate also includes two PMOS transistors (M3 and M4) in series to create the pull-up network. M3 and M4 are also controlled by inputs A and B. Their sources connect to the power supply voltage (Vdd), and drains are connected to the output node (OUT). 1.5 SPICE CODE: * SPICE3 file created from NOR.ext technology: scmos .option scale=1u .include techfile130.txt .subckt nor A B Vdd Gnd Out M1000 Gnd B Out Gnd nmos w=4 l=2 + ad=40 pd=36 as=28 ps=22 M1001 Out B an 33 V ddpmosw = 9l = 2 + ad = 45pd = 28as = 63ps = 32 M 1002OutAGndGndnmosw = 4l = 2 + ad = 0pd = 0as = 0ps = 0 M 1003an 33 AV ddV ddpmosw = 9l = 2 + ad = 0pd = 0as = 45ps = 28 .ends 1.6 SIMULATION CODE: * SPICE3 file created from nor.ext - technology: scmos .option scale=1u .include techfile130.txt .include NOR.spice Vdd Vdd 0 1.2 Va A 0 PULSE(0 1.2 1n 1n 1n 50n 100n) Vb B 0 PULSE(0 1.2 1n 1n 1n 100n 200n) Xnor A B Vdd 0 Out nor .control tran 0.1n 400n plot v(Out) v(A) v(B) .end 2 1.7 SIMULATION GRAPH: 1.8 Layout Design (Using Magic) : 3 1.9 Conclusion: In conclusion, the experiment successfully simulated a 2-input NOR gate using SCmos technology. This hands-on experience in VLSI design and CMOS logic deepened our understanding of digital circuits. The NOR gate’s functionality was verified, highlighting its crucial role in digital systems. This knowledge serves as a foundation for more complex designs, emphasizing the significance of NOR gates in digital circuitry. 4 2 2.1 Experiment 02: Design and Simulation of a 2-Input NAND Gate Aim: The aim of this experiment is to design and simulate a 2-input NAND gate using VLSI design tools. The objective is to understand the operation of a NAND gate and gain practical experience in schematic design, simulation, and layout creation. 2.2 THEORY A NAND gate is a fundamental digital logic gate that performs a logical NAND operation. It has two or more inputs and a single output. The NAND gate produces an output signal that is the logical inverse (complement) of the logical AND of its input signals. In other words, it outputs a ’0’ (low) when none of its inputs are ’1,’ and it outputs ’1’ (high) when at least one input is ’1’. 2.3 Truth Table and Diagram: 2.4 Circuit Design: A 2-input NAND gate comprises two NMOS transistors (M1 and M2) in series, forming the pull-down network. 1) M1 and M2 are controlled by inputs A and B. 2) Their sources connect to the power supply voltage (Vdd), and drains are connected to the output node (OUT). The gate includes two PMOS transistors (M3 and M4) in parallel to create pull-up network. 3) M3 and M4 are also controlled by inputs A and B. 4)Their sources connect to ground (0 V), and drains go to the output node (OUT). 5 2.5 SPICE CODE: * SPICE3 file created from NanD.ext - technology: scmos .option scale=1u .include techfile130.txt .subckt nand Va Vb Out Vdd Gnd M1000 Vdd Vb Out Vdd pmos w=18 l=3 + ad=342 pd=110 as=198 ps=58 M1001 an 5n 39V aGndGndnmosw = 10l = 3 + ad = 110pd = 42as = 80ps = 36 M 1002OutV aV ddV ddpmosw = 18l = 3 + ad = 0pd = 0as = 0ps = 0 M 1003OutV ban 5n 39Gndnmosw = 10l = 3 + ad = 110pd = 42as = 0ps = 0 .ends 2.6 SIMULATION CODE: .option scale=1u .include techfile130.txt .include NanD.spice Vdd Vdd 0 1.2 Va Va 0 PULSE(0 1.2 0n 1n 1n 50n 100n) Vb Vb 0 PULSE(0 1.2 0n 1n 1n 100n 200n) Xnand Va Vb Out Vdd Gnd nand .control tran 0.1n 400n plot v(Out) v(Va) v(Vb) .endc .end 6 2.7 SIMULATION GRAPH: 2.8 Layout Design (Using Magic) : 7 2.9 Conclusion: n conclusion, this experiment effectively designed and simulated a 2-input NAND gate. It offered valuable hands-on experience in VLSI design, CMOS logic, and simulation techniques. The results verified the gate’s NAND operation, which is fundamental in digital logic circuits. This knowledge can be applied to create more intricate digital systems and serves as a foundational building block in the realm of digital circuit design. 8 3 3.1 Experiment 03: Design and Simulation of a 2-Input XOR Gate Aim: The aim of this experiment is to design and simulate a 2-input XOR gate using VLSI design tools. The objective is to understand the operation of an XOR gate and gain practical experience in schematic design, simulation, and layout creation. 3.2 THEORY An XOR gate is a fundamental digital logic gate that performs a logical Exclusive OR (XOR) operation. It has two inputs and a single output. The XOR gate produces an output signal that is ’1’ (high) when an odd number of its inputs are ’1,’ and it outputs ’0’ (low) when an even number of inputs are ’1.’ It effectively represents inequality, where it is true when the inputs are different and false when they are the same. 3.3 Truth Table and Diagram: 9 3.4 Circuit Design: A 2-input XOR gate comprises two NMOS transistors (M1 and M2) connected in a parallel arrangement, forming the pull-down network. M1 and M2 are controlled by inputs A and B. Their sources connect to ground (0 V), and drains are connected to the output node (OUT). The gate also includes two PMOS transistors (M3 and M4) in series to create the pull-up network. M3 and M4 are also controlled by inputs A and B. Their sources connect to the power supply voltage (Vdd), and drains go to the output node (OUT). 3.5 SPICE CODE: * SPICE3 file created from 2xor.ext - technology: scmos .option scale=1u .include techfile130.txt .subckt xor Va Vb Vab Vbb Vdd Out Gnd M1000 Out Vbb Va Gnd nmos w=8 l=2 + ad=128 pd=64 as=64 ps=32 M1001 Out Vbb Vab w3 5n 17pmosw = 8l = 2 + ad = 128pd = 64as = 128ps = 64 M 1002V ddV aV abwn 27n 8pmosw = 8l = 2 + ad = 128pd = 64as = 0ps = 0 M 1003V abV aGndGndnmosw = 8l = 2 + ad = 120pd = 62as = 128ps = 64 M 1004OutV bV aw3 52 3pmosw = 8l = 2 + ad = 0pd = 0as = 64ps = 32 M 1005V bbV bGndGndnmosw = 8l = 2 + ad = 56pd = 30as = 0ps = 0 M 1006V ddV bV bbwn 2n 8pmosw = 8l = 2 + ad = 0pd = 0as = 64ps = 32 M 1007OutV bV abGndnmosw = 8l = 2 + ad = 0pd = 0as = 0ps = 0 .ends 3.6 SIMULATION CODE: .option scale=1u .include techfile130.txt .include 2xor.spice Vdd Vdd 0 1.2 Va Va 0 PULSE(0 1.2 1n 1n 1n 100n 200n) Va0 Vab 0 PULSE(1.2 0 1n 1n 1n 100n 200n) 10 Vb Vb 0 PULSE(0 1.2 1n 1n 1n 200n 400n) Vb0 Vbb 0 PULSE(1.2 0 1n 1n 1n 200n 400n) Xxor Va Vb Vab Vbb Vdd Out Gnd xor .control tran 0.1n 800n plot v(Out) v(Va) v(Vb) .endc .end 3.7 SIMULATION GRAPH: 3.8 Layout Design (Using Magic) : 11 3.9 Conclusion: In summary, this experiment successfully designed and simulated a 2-input XOR gate, providing practical insights into VLSI design, CMOS logic, and simulation methodologies. The results affirmed the XOR gate’s operational characteristics, a crucial element in digital logic circuits. The acquired knowledge enhances the capacity to construct advanced digital systems, leveraging the XOR gate as a fundamental building block in the field of digital circuit design. 12 4 4.1 Experiment 04: Design and Simulation of A Inverter Aim: The aim of this experiment is to design and simulate a digital inverter using VLSI design tools. The objective is to understand the operation of an inverter and gain practical experience in schematic design, simulation, and layout creation. 4.2 THEORY: 1. An inverter is a fundamental digital logic gate with a single input and a single output. 2. It produces the logical complement of its input, i.e., ’1’ (high) for ’0’ (low) input and ’0’ (low) for ’1’ (high) input. 3. In practical implementation, it often uses an NMOS transistor, where input ’0’ turns the transistor on (output ’1’), and input ’1’ turns it off (output ’0’). 4.3 Truth Table and Diagram: 13 4.4 Circuit Design: 1) An inverter comprises a single NMOS transistor (M1) that forms the pulldown network. M1 is controlled by the input (IN). Its source connects to ground (0 V), and the drain is connected to the output node (OUT). 2) The inverter also includes a single PMOS transistor (M2) in series to create the pull-up network. M2 is controlled by the same input (IN). Its source connects to the power supply voltage (Vdd), and the drain goes to the output node (OUT). 4.5 SPICE CODE: * SPICE3 file created from inv.ext - technology: scmos .option scale=1u .include techfile130.txt .subckt inv vdd gnd in out M1000 out in vdd vdd pmos w=6 l=2 + ad=30 pd=22 as=30 ps=22 M1001 out in gnd Gnd nmos w=6 l=2 + ad=30 pd=22 as=30 ps=22 .ends 4.6 SIMULATION CODE: SPICE3 file created from inv.ext - technology: scmos .option scale=1u .include techfile130.txt .include inv.spice Vdd vdd 0 1.2 Vin in 0 PULSE(0 1.2 2n 2n 2n 50n 100n) Xinv vdd 0 in out inv .control tran 0.1n 300n plot v(out) v(in) .endc .end 14 4.7 SIMULATION GRAPH: 4.8 Layout Design (Using Magic) : 15 4.9 Conclusion: In summary, this experiment effectively designed and simulated a CMOS inverter, offering practical insights into VLSI design, CMOS logic, and simulation techniques. The results validated the inverter’s operational characteristics, fundamental in digital logic circuits. This acquired knowledge enriches the ability to construct sophisticated digital systems, recognizing the inverter’s pivotal role as a foundational component in digital circuit design. 16 5 5.1 Experiment 05: Design and Simulation of D Flip Flop Aim: The aim of this experiment is to design and simulate a D flip-flop using VLSI design tools with transmission gates. The objective is to understand the operation of a D flip-flop based on transmission gates and gain practical experience in schematic design, simulation, and layout creation while exploring the behavior of transmission gate-based flip-flops. 5.2 THEORY: 1. A D flip-flop is a digital circuit that stores a single data bit. 2. It uses a clock signal to control data storage. 3. Transmission gates are employed in D flip-flops for data transfer. 4. Data is transferred based on the clock signal, allowing synchronized storage and retrieval. 5. The flip-flop stores the input data on the clock signal’s transition. 6. D flip-flops are crucial for sequential digital circuits, ensuring controlled data synchronization and storage. 5.3 Truth Table and Diagram: 17 5.4 Truth Table and Diagram: 5.5 Circuit Design: A D flip-flop employs transmission gates to store and transfer data. It consists of two main parts: 1. Data Transmission Stage: a) The D input (D) is connected to one set of transmission gates. b) Another set of transmission gates connects to the complement of the D input (NOT D). c) The clock signal (CLK) controls the transmission gates, allowing data to pass through or be blocked. d) Data is transferred from D to the flip-flop’s internal nodes when the clock is enabled. 2. Latch Stage: a) The flip-flop has two cross-coupled inverters (NOR or NAND gates) that store data. b) The data from the transmission gates is stored in these latches. c) The cross-coupled inverters maintain the output state until the clock signal triggers a new data transfer. 18 5.6 SPICE CODE: * SPICE3 file created for a D Flip-Flop in scmos technology .option scale=1u .include techfile130.txt .subckt transmissiong ate(inoutctrlgndvdd) Mp outinctrlvddpmosw = 6l = 4ad = 48pd = 28as = 48ps = 28 Mn outinctrlgndnmosw = 6l = 4ad = 48pd = 28as = 48ps = 28 .ends .subcktinverter(inoutgndvdd) Mp outinvddvddpmosw = 6l = 2ad = 30pd = 22as = 30ps = 22 Mn outingndgndnmosw = 6l = 2ad = 30pd = 22as = 30ps = 22 .ends .subcktdl atch(V ddGndClkClk0D0GndD) Xtransg ate1 GndV ddClkClk0Dlatch1Out1 transmissiong ate Xtransg ate0 GndV ddClk0ClkDlatch0Out0 transmissiong ate Xinv0 Dlatch1D0GndV ddinv Xinv1 D0Out1GndV ddinv .ends .subcktdf f (V ddGndClkClk0DD0Out) Xdl atch0 V ddClkClk0D0GndDDl atch Xdl atch1 V ddClk0ClkOutGndD0Dl atch C0Clk0Gnd43.87f F C1D0Gnd9.21f F C2ClkGnd5.23f F .ends 5.7 SIMULATION CODE: .option scale=1u .include techfile130.txt .include dflipflop.spice Vdd Vdd 0 1.2 Va Clk 0 PULSE(0 1.2 0n 1n 1n 100n 200n) Vb Clk0 0 PULSE(1.2 0 0n 1n 1n 100n 200n) Vc D 0 PULSE(0 1.2 0n 1n 1n 150n 300n) Xdflipflop Vdd 0 Clk Clk0 D D0 Out dff 19 .control tran 0.1n 1200n plot v(Out) v(Clk) v(D) .endc .end 5.8 SIMULATION GRAPH: 5.9 Layout Design (Using Magic) : 20 5.10 Conclusion: In conclusion, the hybrid design of a D Flip-Flop using D Latches and Transmission Gates offers an effective solution for digital circuit applications. The combination of D Latches for data storage and Transmission Gates for controlled data flow results in a versatile and efficient flip-flop design. This approach optimizes performance, minimizes propagation delays, and allows for flexibility in meeting specific design requirements, emphasizing the importance of thoughtful component selection in digital circuit design. 21 6 6.1 Experiment 06: FINITE STATE MACHINE Aim: To Develop a versatile Finite State Machine (FSM) system capable of handling both Moore and Mealy machine models, along with specialized components for sequence detection. 6.2 THEORY: 1)Moore Machine: Implement a Moore machine with distinct states and associated outputs. Demonstrate the functionality of the Moore machine in a practical application, such as a simple control system. 2) Mealy Machine: Develop a Mealy machine with outputs that depend on both current states and input signals.Showcase the advantages of Mealy machines in scenarios where dynamic and immediate responses are required. 3)Moore Sequence Detector: Create a Moore-based sequence detector capable of recognizing specific input sequences.Illustrate the application of sequence detection in scenarios like pattern recognition or signal processing. 4) Moore Detector: Design a Moore detector that responds to certain conditions in the system.Explore how Moore detectors can be employed for event-driven applications, providing outputs based on the system’s current state.v 6.3 Implementation Steps: 1)Define the system specifications and requirements. 2)Design the state diagrams for both Moore and Mealy machines. 3)Implement the FSM using a programming language or hardware description anguage. 4)Test and validate the functionality of the Moore and Mealy machines separately. 5)Integrate the Moore sequence detector and Moore detector into the FSM framework. 6)Demonstrate the FSM system in various scenarios to showcase its versatility. 22 6.4 VERILOG CODE OUTPUT GRAPH 6.4.1 MEALY MACHINE: CODE: module mealy ( input x, clk, rst, output reg y ); parameter zero = 1’b0; parameter one = 1’b1; // State registers reg state, next_state; always @(posedge clk or posedge rst) begin if (rst) begin state <= zero; y <= 1’b0; // Reset output on reset end else begin state <= next_state; end end always @(x, state) begin // Explicit sensitivity list case (state) zero: begin if (x) begin next_state = one; y = 1’b1; end else begin next_state = zero; y = 1’b0; end end one: begin if (x) begin next_state = one; y = 1’b1; end else begin 23 next_state = zero; y = 1’b0; end end // Add more states as needed default: begin next_state = zero; y = 1’b0; end endcase end endmodule OUTPUT GRAPH: 24 6.4.2 MEALY SEQUENCE DETECTOR : CODE: /*‘timescale 1ns/1ps module seq_det_mealy ( input clk, rst, x, output reg y); reg [1:0] state, next_state; parameter a = 2’b00, b = 2’b01, c = 2’b10; always @(posedge clk or posedge rst) begin if (rst) begin state = a; end else begin state = next_state; end end always @(x, state) begin case (state) a: begin if (x) begin next_state = b; y=0; end else begin next_state = a; y = 0; end end b: begin if (x) begin next_state = c; y=0; end else begin next_state = a; y=0; end end c: begin if (x) 25 begin next_state = c; y=0; end else begin next_state = a; y = 1; end end endcase end endmodule OUTPUT GRAPH: 26 6.4.3 MOORE SEQUENCE DETECTOR : CODE: module seq_det_moore ( input clk, rst, x, output reg y ); reg [1:0] state, next_state; parameter a = 2’b00, b = 2’b01, c = 2’b10, d = 2’b11; always @(posedge clk) begin if (rst) state <= a; else state <= next_state; end always @(x, state) begin case (state) a: begin if (x) next_state else next_state end b: begin if (x) next_state else next_state end c: begin if (x) next_state else next_state end d: begin if (x) next_state else next_state end endcase = b; = a; = c; = a; = c; = d; = b; = a; 27 end always @(state) begin case (state) a: y = 0; b: y = 0; c: y = 0; d: y = 1; endcase end endmodule OUTPUT GRAPH: 28 6.4.4 TESTBENCH: ‘timescale 1ns/1ps ‘include "seq_det_moore.v" module tb; reg x, clk, rst; wire y; seq_det_moore DET(.x(x), .clk(clk), .rst(rst), .y(y)); always begin clk <= 0; #10; clk <= 1; #10; end initial begin $dumpfile("xyz.vcd"); $dumpvars; #300 $finish; end initial begin rst <= 1; #20 rst <= 0; #20 x <= 1; #20 x <= 1; #20 x <= 0; #20 x <= 1; #20 x <= 0; #20 x <= 1; #20 x <= 1; #20 x <= 1; #20 x <= 1; #20 x <= 1; #20 x <= 1; #20 x <= 1; #20 x <= 0; // Add a delay to let the simulation run for a while before finishing #300 $finish; end endmodule 29 6.4.5 YOSYS DIAGRAM: 1) MEALY MACHINE: 2) MEALY SEQUENCE DETECTOR: 30 3) MOORE SEQUENCE DETECTOR: 31 7 7.1 Experiment 07: DECODER Aim: Design and implement a decoder circuit in Verilog using three different modeling styles - structural, behavioral, and dataflow. The project aims to explore and demonstrate a comprehensive understanding of these Verilog modeling paradigms and their applications in digital circuit design. 7.2 THEORY: 1) Structural Model: Develop a structural representation of the decoder using hierarchical modules.Utilize basic logic gates (AND, OR, NOT) and multiplexers to create a modular and well-organized structural model. 2) Behavioral Model: Implement a behavioral model that describes the functionality of the decoder using high-level constructs.Use procedural blocks (always, initial) and conditional statements to capture the decoder’s behavior in terms of input-output relationships. 3) Dataflow Model: Create a dataflow model to represent the decoder’s operation in terms of data flow and concurrent assignments.Utilize continuous assignments and assign statements to express the functional dependencies within the decoder. 7.3 Implementation Steps: 1) Structural Model: Define the module interfaces, inputs, and outputs.Instantiate lower-level modules for gates and multiplexers.Connect the instantiated modules to create the hierarchical structure.Simulate and verify the structural model’s functionality. 2) Behavioral Model: Define the module with inputs, outputs, and internal variables.Use procedural blocks to describe the desired behavior.Implement conditional statements to capture the decoder’s logic.Simulate and verify the behavioral model’s correctness. 32 3) Dataflow Model: Define the module with inputs, outputs, and intermediate signals.Use continuous assignments to express the dataflow relationships.Describe the decoder’s logic in terms of signal assignments.Simulate and verify the dataflow model’s functionality. 7.4 VERILOG CODE OUTPUT GRAPH 7.4.1 DECODER(STRUCTURAL): CODE: module decoder(input a,b,e,output [3:0]d); wire b_bar,a_bar; not n1(a_bar,a); not n2(b_bar,b); and #2 a1(d[0],a_bar,b_bar,e), a2(d[1],a_bar,b,e), a3(d[2],a,b_bar,e), a4(d[3],a,b,e); //and a2(d[1],a_bar,b,e); //and a3(d[2],a,b_bar,e); //and a4(d[3],a,b,e); endmodule OUTPUT GRAPH: 33 7.4.2 DECODER(BEHAVIORAL): CODE: module decoder(input A, B, E, output reg [3:0]D); always @(A or B or E) begin case ({E,A,B}) 3’b000: D = 4’b0000; 3’b001: D = 4’b0000; 3’b010: D = 4’b0000; 3’b011: D = 4’b0000; 3’b100: D = 4’b0001; 3’b101: D = 4’b0010; 3’b110: D = 4’b0100; 3’b111: D = 4’b1000; endcase end endmodule OUTPUT GRAPH: 34 7.4.3 DECODER(DATAFLOW): CODE: module decoder( input A, B, E, output [3:0]D); assign D[1] = D[2] = D[3] = D[0] = ~A & ~B & E, ~A & B & E, A & ~B & E, A & B & E ; endmodule OUTPUT GRAPH: 7.5 TEST-BENCH: module tb_decoder(); reg A,B,E; wire [3:0]D; decoder dec1(A,B,E,D); initial begin $dumpfile("xyz.vcd"); $dumpvars; #10 E<=1’b0; A<=1’b0; B<=1’b0; #10 E<=1’b0; A<=1’b0; B<=1’b1; #10 E<=1’b0; A<=1’b1; B<=1’b0; 35 #10 E<=1’b0; A<=1’b1; B<=1’b1; #10 E<=1’b1; A<=1’b0; B<=1’b0; #10 E<=1’b1; A<=1’b0; B<=1’b1; #10 E<=1’b1; A<=1’b1; B<=1’b0; #10 E<=1’b1; A<=1’b1; B<=1’b1; #10 $finish; end always @(A or B or E) $monitor("At TIME(in ns)=%t, A=%d B=%d E=%d D=%d", $time, A, B, E, D); endmodule 7.6 YOSYS DIAGRAM: 36 8 8.1 Experiment 08: MEMORY Aim: Design and implement a memory module in Verilog capable of read and write operations. The module includes an array of 64 4-bit registers, providing a flexible and configurable memory space. 8.2 THEORY: 1) Configurability: The memory module supports a flexible memory space with 64 registers, each 4 bits wide.Configurable for different memory requirements by adjusting the size of the memory array. 2) Read and Write Operations: Implements both read (rw=1) and write (rw=0) operations.During a read operation, the module outputs the data stored at the specified address (addr) During a write operation, the module stores the input data (datain) at the specified address. 3) Enable Signal: The en signal activates the memory operations. When inactive, the module outputs a high-impedance state (4’bz). 8.3 Implementation Steps: 1) Declare a configurable memory array with appropriate bit width and size. 2) Utilize the always block to control read and write operations based on the enable (en) and read/write (rw) signals. 3) Implement conditional statements to handle read and write cases within the always block. 4) Ensure the module outputs the correct data based on the specified address during read operations. 5) Simulate and verify the module’s functionality in a testbench environment. 37 8.4 VERILOG CODE OUTPUT GRAPH 8.4.1 MEMORY: CODE: module memory ( input en, // Enable signal input rw, // Read/Write signal input [3:0] datain, // Data input input [5:0] addr, // Address input output reg [3:0] dataout // Data output ); reg [3:0] mem [0:63]; // Declare a 64-word memory, indexed from 0 to 63 always @ (en, rw, addr) begin if (en) begin if (rw) // Read operation dataout = mem[addr]; else // Write operation mem[addr] = datain; end else dataout = 4’bz; // Output is high impedance when en is not active end endmodule OUTPUT GRAPH: 38 8.4.2 TEST BENCH: ‘timescale 1ns / 1ps ‘include "memory.v" module tb(input CLK, RST_N); parameter ADDR_WIDTH = 4; parameter DATA_WIDTH = 16; parameter DEPTH = 16; reg clk; reg cs; reg we; reg oe; reg [ADDR_WIDTH-1:0] addr; wire [DATA_WIDTH-1:0] data; reg [DATA_WIDTH-1:0] tb_data; integer i; single_port_sync_ram #(.DATA_WIDTH(DATA_WIDTH)) u0 (.clk(clk), .addr(addr), .data(data), . always #10 clk = ~clk; assign data = !oe ? tb_data : ’hz; initial begin $dumpfile("xyz.vcd"); $dumpvars; {clk, cs, we, addr, tb_data, oe} <= 0; repeat (2) @(posedge clk); for (i = 0; i < 2**ADDR_WIDTH; i= i+1) begin repeat (1) @(posedge clk) addr <= i; we <= 1; cs <=1; oe <= 0; tb_data <=$random; end for (i = 0; i < 2**ADDR_WIDTH; i= i+1) begin repeat (1) @(posedge clk) addr <= i; we <= 0; cs <= 1; oe <= 1; end #20 $finish; end endmodule 39 9 9.1 Experiment 09: FULL ADDER Aim: Design and implement a Full Adder circuit in Verilog using three different modeling styles - structural, behavioral, and dataflow. The project aims to explore and demonstrate a comprehensive understanding of these Verilog modeling paradigms and their applications in digital circuit design. 9.2 THEORY: 1) Structural Model: Develop a structural representation of the Full Adder using hierarchical modules.Utilize basic logic gates (AND, OR, XOR) to create a modular and wellorganized structural model.Implement lower-level modules for the individual XOR, AND, and OR gates. 2) Behavioral Model: Implement a behavioral model that describes the functionality of the Full Adder using high-level constructs.Use procedural blocks (always, initial) and conditional statements to capture the Full Adder’s behavior in terms of input-output relationships.Describe the sum and carry-out generation based on input signals. 3) Dataflow Model: Create a dataflow model to represent the Full Adder’s operation in terms of data flow and concurrent assignments.Utilize continuous assignments and assign statements to express the functional dependencies within the Full Adder.Express the logic relationships between inputs, outputs, and intermediate signals. 9.3 Implementation Steps: 1) Structural Model: Define module interfaces and instantiate XOR, AND, and OR gates.Connect modules hierarchically to create a structural representation. 2)Behavioral Model: Define input and output ports in the module.Use procedural blocks to describe Full Adder behavior based on input-output relationships. 3) Dataflow Model: 40 Define module ports.Express Full Adder’s operation using continuous assignments and functional dependencies. 4) Verification: Simulate each model and verify correct sum and carry-out generation. Analyze and compare outcomes to assess modeling strengths and weaknesses. 9.4 VERILOG CODE OUTPUT GRAPH 9.4.1 ADDER(STRUCTURAL): CODE: ‘timescale 1ns / 1ps module full_adder( A, B, Cin, S, Cout); input A, B, Cin; output S, Cout; wire p,q,r; xor(p,A,B); xor(S,p,Cin); and(r,A,B); and(q,p,Cin); or(Cout,q,r); endmodule OUTPUT GRAPH: 41 9.4.2 ADDER(BEHAVIORAL): CODE: ‘timescale 1ns / 1ps module full_adder( A, B, Cin, S, Cout); input wire A, B, Cin; output reg S, Cout; always @(A begin case (A | 3’b000: 3’b001: 3’b010: 3’b011: 3’b100: 3’b101: 3’b110: 3’b111: endcase end or B or Cin) B | Cin) begin S = begin S = begin S = begin S = begin S = begin S = begin S = begin S = 0; 1; 1; 0; 1; 0; 0; 1; Cout Cout Cout Cout Cout Cout Cout Cout = = = = = = = = 0; 0; 0; 1; 0; 1; 1; 1; endmodule OUTPUT GRAPH: 42 end end end end end end end end 9.4.3 ADDER(DATAFLOW): CODE: ‘timescale 1ns / 1ps module full_adder( A, B, Cin, S, Cout); input A, B, Cin; output S, Cout; wire x,y,z; assign x = A ^ B ; // even one single expression can do. assign y = x & Cin ; assign z = A & B ; assign S = x ^ Cin ; assign Cout = y | z ; endmodule OUTPUT GRAPH: 43 9.5 TEST BENCH odule test_full_adder(input CLK, RST_N); reg A, B, Cin; wire Sum, Cout; full_adder full_adder1(A, B, Cin, Sum, Cout); initial begin $dumpfile("xyz.vcd"); $dumpvars; #10 #10 #10 #10 #10 #10 #10 #10 A A A A A A A A = = = = = = = = 1’b0; 1’b0; 1’b0; 1’b0; 1’b1; 1’b1; 1’b1; 1’b1; B B B B B B B B = = = = = = = = 1’b0; 1’b0; 1’b1; 1’b1; 1’b0; 1’b0; 1’b1; 1’b1; Cin Cin Cin Cin Cin Cin Cin Cin #30 #10 $finish; end endmodule 9.5.1 YOSYS DIAGRAM: 44 = = = = = = = = 1’b0; 1’b1; 1’b0; 1’b1; 1’b0; 1’b1; 1’b0; 1’b1; 10 Experiment 10: AND GATE 10.1 Aim: Design a 2-input AND gate in Verilog to implement the logical AND operation between two input signals. 10.2 THEORY: An AND gate produces a high output (1) only when both of its inputs are high (1). The logical operation is represented as Z = A B, where Z is the output and A and B are the input signals. 10.3 VERILOG CODE OUTPUT GRAPH CODE: module and_gate2 ( input wire A, input wire B, output reg Z ); always @(A or B) begin Z = A & B; end endmodule OUTPUT GRAPH: 45 10.4 TEST BENCH module test_or(input CLK, RST_N); reg A, B; wire Y; and_gate2 and1(A, B, Y); initial begin $dumpfile("xyz.vcd"); $dumpvars; #10 A <= 1’b0; B<=1’b0; #10 A <= 1’b0; B<=1’b1; #10 A <= 1’b1; B<=1’b0; #10 A <= 1’b1; B<=1’b1; #30 #10 $finish; end endmodule 10.4.1 YOSYS DIAGRAM: 46 11 Experiment 11: 2 OR GATE 11.1 Aim: Design a 2-input OR gate in Verilog to implement the logical OR operation between two input signals. 11.2 THEORY: An OR gate produces a high output (1) when at least one of its inputs is high (1). The logical operation is represented as Z = A — B, where Z is the output and A and B are the input signals. 11.3 VERILOG CODE OUTPUT GRAPH CODE: module or_gate2 ( input wire A, input wire B, output reg Z ); always @(A or B) begin Z = A or B; end endmodule OUTPUT GRAPH: 47 11.4 TEST BENCH module test_or(input CLK, RST_N); reg A, B; wire Y; or_gate2 and1(A, B, Y); initial begin $dumpfile("xyz.vcd"); $dumpvars; #10 A <= 1’b0; B<=1’b0; #10 A <= 1’b0; B<=1’b1; #10 A <= 1’b1; B<=1’b0; #10 A <= 1’b1; B<=1’b1; #30 #10 $finish; end endmodule 11.4.1 YOSYS DIAGRAM: 48 12 12.1 Experiment 12: INVERTER Aim: Design and simulate a 1-input inverter (NOT gate) in Verilog and verify its functionality through a testbench. 12.2 THEORY: An inverter, often referred to as a NOT gate, is a fundamental digital logic gate that performs the logical operation of inversion.The logical expression for an inverter is denoted as Z=AZ=A, where ZZ is the output and AA is the input. 12.3 VERILOG CODE OUTPUT GRAPH CODE: module inv(input A, output B); assign B = ~A ; endmodule OUTPUT GRAPH: 49 12.4 TEST-BENCH ‘include "inv.v" module test_inv(input CLK,RST_N); reg A; wire B; inv inv1(A,B); initial begin $dumpfile("xyz.vcd"); $dumpvars; #10 A<=1’b1; #10 A<=1’b0; #10 A<=1’b1; #10 A<=1’b1; #10 A<=1’b0; #10 A<=1’b1; #10 A<=1’b0; #10 A<=1’b1; #10 $finish; end endmodule 12.4.1 YOSYS DIAGRAM: 50 13 13.1 Experiment 13: PROCESSOR Aim: Design and simulate a simple processor in Verilog that performs basic operations, such as addition and subtraction, based on instructions stored in memory. The processor fetches instructions from memory, decodes them, executes the corresponding operation, and stores the result back in memory. 13.2 THEORY: 1. Overview - Processor: Core of a computer; performs operations on data. 2. Registers: - Small, fast storage locations (e.g., ‘PC‘, ‘R0‘). 3. States and FSM: - Operates in fetch, decode, execute, and store states. 4. Control Signals: - ‘r‘ for read, ‘w‘ for write. 5. Instruction Execution: - Fetches, decodes, and executes instructions. 6. Arithmetic Operations: - Performs operations like addition and subtraction. 7. Program Counter (‘PC‘): - Keeps track of the next instruction address. 8. Memory Interaction: - Reads from and writes to memory. 9. Simulation and Verification: - Simulates design for correctness. 10. Finite State Machine (FSM): - Controls operation sequence. 11. Reset Mechanism: - Initializes processor to a known state. 12. Data Flow: 51 - Data moves between registers and bus. 13. Clock Signal: - Synchronizes processor operations. 14. On-Chip Memory: - Stores instructions and data. 15. Processor Types: - Varies in complexity (educational to commercial). 13.3 Implementation Steps: 1. Initialization: - Set initial values for registers (R0, R1, R2, PC, IR). - Start in the fetch state. 2. State Machine: - Use a finite state machine (state, next_state). - Define transitions based on opcode (IR) and control signals (r, w). 3. Memory Interaction: - In fetch state, set ‘r‘ for memory read. - In store state, set ‘w‘ for memory write. 4. Arithmetic Operations: - Perform addition/subtraction per opcode. 5. Program Counter: - Increment PC after each instruction. 6. Data Bus: - Control data bus (data) based on read (‘r‘) or write (‘w‘) signals. 52 13.4 VERILOG CODE OUTPUT GRAPH VERILOG CODE: module processor(input clk, rst, inout [7:0] data, output r, w, output [7:0] P reg [7:0] IR, R0, R1, R2, PC; reg [7:0] tmp_data; initial PC = 8’h00; initial R0 = 8’h20; initial R1 = 8’h15; initial R2 = 8’h00; initial IR = 8’h00; reg [2:0] state, next_state; reg r,w; initial r = 0; initial w = 0; parameter fetch = 3’b000, decode = 3’b001, execute_add = 3’b010, execute_sub = 3’b011, s always @(posedge clk) begin if(rst) state = fetch; else state = next_state; end always @(state) case(state) fetch: begin w <= 0; r <= 1; next_state = decode; end decode: begin #1 IR <= data; #1 53 if(IR == 8’h55) next_state = execute_add; else if(IR == 8’hAA) next_state = execute_sub; else next_state = decode; r <= 0; end execute_add: begin R2 <= R1 + R0; next_state = store; end execute_sub: begin R2 <= R1 - R0; next_state = store; end store: begin tmp_data <= R2; w <= 0; // to write result back make w <= 1, but next instr gets corrupt next_state = fetch; PC <= PC + 1; end endcase assign data = !r & w ? tmp_data : ’hz; endmodule 54 OUTPUT GRAPH: 13.5 TEST-BENCH //‘timescale 1ns / 1ps ‘include "instr_exec.v" module memory(input clk,r, w, input [7:0] PC, inout [7:0] data); reg [7:0] mem[2:0]; reg [7:0] tmp_data; initial mem[0] = 8’h55; initial mem[1] = 8’hAA; initial mem[2] = 8’h00; always @ (posedge clk) begin if (w) mem[PC] <= data; end always @ (posedge clk) begin 55 if (r) tmp_data <= mem[PC]; end assign data = tmp_data; endmodule module tb_instr_exec(input CLK, RST_N); reg clk, rst; wire r,w; wire [7:0] PC; wire [7:0] data; memory M(clk,r,w,PC,data); processor DUT(clk,rst,data,r,w,PC); always begin clk <= 0; #5; clk <= 1; #5; end initial begin $dumpfile("xyz.vcd"); $dumpvars; #100 $finish; end initial begin rst <= 1; #20 rst <= 0; end endmodule 56 13.5.1 YOSYS DIAGRAM 57
