ElecEng 2MM3
Assignment (1)
Question 1 (5 points):
a) Use nodal analysis to determine the output current πΌπ in the circuit shown in Fig. 1.
b) Find the supplied power ππ and the power delivered to the load resistor π
πΏ .
Figure 1
Question 2 (5 points):
(a) Use loop analysis to determine the output voltage ππ in the circuit shown in Fig. 2.
(b) What is the output power πππ’π‘ ?
Figure 2
Page 1 of 2
ElecEng 2MM3
Assignment (1)
Question 3 (5 points):
a) For the circuit shown in Fig. 3, find the current in the 3 Ω resistor using Thévenin’s
theorem.
b) What will be the current value if the value of the resistor is changed to 10 Ω?
c) What is the value of π
πΏ required to achieve a maximum delivered power? Find the
maximum power to be delivered to that load.
Figure 3
THE END.
Page 2 of 2
