Page 1 of 3
Department of Electrical Engineering
University of Engineering & Technology, Peshawar
Circuit Analysis-II
(MAIN CAMPUS)
Assignment No-2, 4th Semester, Spring-2022
Maximum Points: 10
•
To be submitted till 11-06-2023
•
Solve this assignment using pen and paper, take pictures, convert to pdf, and upload as a
single pdf file. In addition, please submit a hard copy of your work in Ph.D. Computer
Lab.
Q: 1.
(CLO-3)
a) Draw the S-Domain Circuit and use nodal analysis to find vo( t ), t > 0, in the network
given below.
b) The switch in the circuit (shown below) has been closed for a long time and is opened
at t = 0. Find i(t) for t > 0.
Page 2 of 3
c) Find Vo(t), t > O, in the circuit given below.
d) Find Vo(t), t > O, in the circuit given below.
Q: 2.
a) Find the Fourier series components for the waveform given below
(CLO-4)
Page 3 of 3
b) For the waveform given below, determine whether it is symmetrical, even, or odd.
Also find the Fourier series components.
c) Find the a’s and b’s if F(x) = 𝑆𝑞𝑢𝑎𝑟𝑒 𝑃𝑢𝑙𝑠𝑒 = {
1
0
𝑓𝑜𝑟 0 < 𝑥 < ℎ
𝑓𝑜𝑟 ℎ < 𝑥 < 2𝜋
d) Find the average power absorbed by the network in Figure given below if
υ (t) = 60 + 36 cos (377t + 45°) + 24 cos (754t − 60°) V
