Drawing for Altmann BYOB speaker 80x40 cm.
You need 11 pc. 80x40 cm (31.5" x 15.75") panels (preferrably spruce /
pine-wood) for a stereo pair incl. open baffles.
400,00 -> 16"
You can also make them 32" x 16".
Thickness I use is 18mm = 0.71" No matter what your standard wood panel
thickness 'd' is (i.e. 0.8" or 1") all that changes is the dimension of the top and
bottom panels (16" x 16-2d"). The front and side panels all stay 32x16" resp.
80x40 cm.
Front View:
Side View:
00
2.9"
3,
Ø7
,00
5.7"
5
Ø14
Tilt, as you like
crossover
00
,
284
800,00 -> 32"
Ø
11.2"
0
,0
20
Ø1
400,00 -> 16"
bass refl.
port
4,7"
400,00
d
I have lacquered boxes and baffles inside outside with colophony dissolved in
turpentine. The side- rear and front-panels have wood-slabs glued in place as
reinforcement. Fluffy blanket is tacked to the inside of each box.
I use small wooden feet (3 per box). Reflex port can also be in rear panel.
