Electronics
Project Progress Report
Submitted by:
Daniyal Tahir 210501016
Abdullah Tafzeel 210501068
Annas Shahid 210501047
Department:
ME-10-B
Submitted To:
Mr Mudassir Qamar
PROGRESS REPORT
The following components were purchased for the Project
•
•
•
Ultrasonic Ranging Module HC-SR04
LCD 1602A
Arduino UNO REV3 SMD
Details of each component is given next
ULTRASONIC RANGING MODULE HC-SR04
Ultrasonic ranging module HC - SR04 provides 2cm - 400cm non-contact measurement
function, the ranging accuracy can reach to 3mm.
The modules include ultrasonic transmitters, receiver, and control circuit.
The basic principle of work:
(1) Using IO trigger for at least 10us high level signal,
(2) The Module automatically sends eight 40 kHz and detects whether there is a pulse signal
back.
(3) IF the signal comes back, through high level, time of high output IO duration is the time from
sending ultrasonic to returning. Test distance = (high level time×velocity of sound (340M/S) / 2,
 Wire connecting direct as following: 5V Supply Trigger Pulse Input Echo Pulse Output 0V
Ground
LCD 1602A
ARDUINO UNO REV3 SMD
Key Features
•
•
•
•
•
•
•
The operating voltage is 5V
The recommended input voltage will range from 7v to 12V
The input voltage ranges from 6v to 20V
Digital input/output pins are 14
Analog i/p pins are 6
DC Current for each input/output pin is 40 mA
DC Current for 3.3V Pin is 50 mA
