AN/APS-143(V)
AN/APS-143(V) is an X-Band maritime surveillance and tracking radar
designed for installation in a variety of fixed-wing aircraft and
helicopters. It is known as OceanEye. The system uses a traveling
wave tube (TWT) transmitter, frequency agility and pulse compression
techniques, and consists of three units: an antenna, transceiver and
signal processor. The antenna system is pitch-and-roll compensated.
Control of the radar may be carried out by a dedicated control panel,
or by a central universal keyset via a MIL-STD-1553B databus.
Features include track-while-scan, air search mode with moving target
indication customised for the individual platform, integrated electronic
support measures interface and an integrated identification friend-orfoe system interface.
The APS-143(V)3 has small-target detection capability and is smaller
in size. This variant features a track-while-scan function and a MILSTD-1553B databus output to a central tactical navigation computer.
Figure 2: AN/APS-143(V)
Figure 1: AN/APS-143(V)3
Specifications
frequency:
pulse
repetition
time (PRT):
pulse
repetition
frequency
(PRF):
pulsewidth
(τ):
receiving
time:
dead time:
peak power:
average
power:
instrumented
range:
range
resolution:
accuracy:
beamwidth:
hits per
scan:
antenna
rotation:
MTBCF:
MTTR:
9 250 …
9 700
MHz
(X-Band)
2 491,
1 513,
750 Hz
(400 800 Hz
in ISAR
mode)
10, 23.4,
or 40 μs
8 kW
256 NM
(≙ 475
km)
50 m
800 hrs
