Types of Piston Rings
Piston Rings and Types of Piston Rings
The piston rings are fixed into the grooves of the piston to maintain a good seal between the piston and
the cylinder wall. There are three functions of the piston rings as follows:
1. To provide a pressure seal to prevent blow-by of burnt gases. Blow-by is the name that defines
the exhaust of burnt gases from the combustion chamber, through the piston, and into the
crankcase.
2. To form the main path for conduction of heat from the piston crown to the cylinder walls.
3. To control the flow of oil to the skirt and rings themselves inadequate quantity while preventing
an excessive amount reaching the combustion chamber with consequent waste and
carbonization.
Types of Piston Rings
Following are two types of piston rings:
1. Compression rings
2. Oil control rings
Read also: List of Car Engine Parts: Its Function (With Pictures)
TheEngineersPost.com
Page 1
Types of Piston Rings
Material: The piston rings are made of fine-grained alloy cast iron. This material possesses excellent
heat and wear-resisting quantities inherent in its graphitic structure.
The elasticity of this material is also enough to impart radial expansion and compression which is
required for assembly and removal of the ring, and especially to enable it to exercise flexible pressure on
the cylinder walls.
The piston rings are split so that they can be expanded and slipped over the piston head and into the
recessed grooves cut in the piston. The rings usually have butt joints, but in some heavy-duty engines,
the joint may be angled, lapped, or of the sealed type.
The outer diameter of the ring is somewhat larger than the cylinder bore and the split point is open.
When it is installed, it is compressed thus giving it an initial tension, the joint is nearly closed. When in
position, it pressed tightly against the cylinder wall.
Compression Rings
TheEngineersPost.com
Page 2
Types of Piston Rings
In modern engines, there are two or three compression rings fitted into the top grooves. The number of
compression rings tends to improve the compression ratio. An oil control ring is fitted into the lower
groove of the piston. Generally, the second and third compression ring are taper-faced and supplied to
improve oil sealing.
Taper-sided compression rings are utilised to control ring-sticking problems in high output engines. It
must not be fitted in grooves other than ones of the same section. A special ridge-dodger ring having a
small step is specially designed for use in worn engines so that the wear ridge left by the original
compression ring is cleared.
In many cases, oil control rings have a series of slots which transfer excess oil through holes in the piston
groove to the inside of the piston and so to the sumps but leave sufficient oil to lubricate cylinder walls.
Oil control rings slightly more radial pressure than compression rings.
Counter Bored and Scraper Rings
In many engines, these types of piston rings are used for the top and second compression ring. During
suction stroke as shown in the figure, the rings twist slightly due to the internal forces produced by
cutting away a corner of the rings.
Read Also: Types of Suspension Springs Used In Automobile Vehicles
TheEngineersPost.com
Page 3
Types of Piston Rings
Thus, as the rings move down they rub off the oil that has been left on the cylinder wall by the oil
control rings. During the compression stroke when the rings move upward, they tend to skate over the
oil film on the cylinder wall. Thus, less oil is sent up into the combustion chamber.
During power stroke as shown in the figure, the combustion pressure causes to untwist the rings, thus
they have full-face contact with the cylinder walls for effective sealing. During the exhaust stroke, the
same action takes place as in compression stroke.
Read also: Two Stroke Cycle Engines
Headland Rings
Headland ring is a special type of compression rings, having L-shaped cross-section. It covers or shields
the headland area of the piston. This is the area of the piston between the top ring groove and the head
of the piston.
This area holds a certain amount of air-fuel mixture that does not burn because the cylinder wall and
piston cool this air-fuel mixture below the combustion point. This unburned air-fuel mixture passes out
of the engine and can produce smog.
Read Also: What is Suspension System: Types, Parts, Working and More
TheEngineersPost.com
Page 4
Types of Piston Rings
By the use of headland ring on the piston of the special type having chamfered top, this space is
eliminated so that the amount of unburned air-fuel mixture exhausted from the cylinder is reduced. This
increases horsepower up to 10 %.
The headland ring also has the advantage of good sealing during the power stroke. As combustion starts,
the pressure acts quickly on the upper lip of the ring, forcing out thus having good sealing with the
cylinder wall.
Why Two Compression Rings?
Usually, two compression rings are installed on the piston. During the power stroke, the pressure
increases as high as 70 kgf/cm2 and would be difficult for a single compression ring to hold this much
pressure.
If there are two rings, this pressure will be divided between the two rings. The load on the upper ring is
reduced so that it does not press quite so hard on the cylinder wall. Wearing of ring and cylinder is also
reduced.
Oil Control Rings
Some connecting rods have an oil split hole which splits oils from the oil pan on the cylinder wall during
each revolution of the crankpin. For more oil reaches on the cylinder wall that is needed. It must be
scraped off and returned to the oil pin. Otherwise, it will go into the combustion chamber and burn.
This would increase oil consumption so that the engine would require the addition of oil at frequent
intervals. Also, the burned oil would foul the spark plug, increase the possibility of knocking and hamper
the action of compression rings.
Instead of having cooling, sealing, cleaning and lubricating effect on the cylinder walls, the oil must be
removed from the cylinder wall every time so that it may not enter the combustion chamber. This is
done by the oil control ring.
TheEngineersPost.com
Page 5
Types of Piston Rings
Types of Oil-control ring
Following are the three different types of Oil-control rings:
1. One-piece slotted cast iron type
2. One-piece pressed steel type
3. Three-piece steel rail type with an expander
1. One Piece Slotted Cast Iron Type
These types of piston rings have slots between the upper and lower faces that carry on the cylinder
wall. The oil scraped off the cylinder wall moves into the slots in the back of the oil ring grooves in a
piston and from there it returns to the oil pan.
Some rings of this type are installed with expander rings. The expander spring increases the pressure of
the ring on the cylinder wall which improves the oil scraping effect.
2. One Piece Pressed Steel Type
One-piece pressed steel type oil control ring mostly used in an engine with worn cylinder walls. It is
made of pressed steel instead of cast iron.
It can seal against only one side of the ring groove in the piston at a time, thus leaving an open path
through which oil can pass upward toward the combustion chamber.
3. Three Piece Steel Rail Type with an Expander
In three-piece steel rail type oil control ring, the expander spring forces the rails not only upward into
contact with cylinder walls but also upward and downward against the upper and lower sides of the ring
grooves in the piston. This provides a more effective seal at these three vital points to provide effective
oil control.
Why Only One Oil-Control Ring?
Usually, four-piston rings were installed on the long skirt pistons of earlier passenger car engines. The
lower two rings were oil-control rings. But the use of lower hood lines reduced the number of rings to
three.
Because two compression rings are necessary to withstand the high combustion pressure, hence there
remains only one oil control ring. It is possible to use one oil-control ring because of manufacturing
improvements and the more effective action of the modern oil-control ring.
Ring Coating
To prevent rapid wear, various coatings are used on the compression rings. The coating also affects
wear-in. The term wear-in means rapid removal of irregularities of new rings.
TheEngineersPost.com
Page 6
Types of Piston Rings
When new, the rings and cylinder wall have certain irregularities and do not fit perfectly, however, after
some time, these irregularities are worn away so that a much better fit is obtained.
Relatively soft substances such as graphite, phosphate and iron oxide, which wear rapidly, are often
used to coat the rings and thus help this wear-in. The rate of wear in the cylinder bore can be
considerably reduced by chromium-plating the top ring rather than the bore. A chrome-plated ring,
however, must not be used in conjunction with a plated bore or hardened linear.
Ring coating also has good oil-absorbing properties. They "soak-up" some oil, thus improving ring
lubrication. The coatings also tend to prevent ring scuffing. The scuffing results from metal to metal
contact, high local temperatures, and actual small area welding of the ring and cylinder wall metal.
Although the weld breaks by further movement of the piston but scratches are left. The coating
prevents such scuffing because a weld cannot take place unless there is actual iron to iron contact.
Piston Ring Gap
Piston rings have a gap so that they may be installed into the piston grooves and removed when worn
out by expanding them. The gap ensures radial pressure against the cylinder wall thus having an
effective seal to prevent leakage of heavy combustion pressure.
This gap must be checked if it is too great due to cylinder bore wear, the radial pressure will be
decreased. To check this gap clean the carbon from the ends of the ring and then check it with feeler
gauges. This gap may be in the region 0-178-0-50 mm governed by the diameter of the bore but it
exceeds 1 mm per 100 mm of bore diameter, new rings must be fitted.
TheEngineersPost.com
Page 7
Types of Piston Rings
The gap between the ring and the groove in the piston should also be checked by feeler gauges. This gap
is usually 0-038-0.102 mm for compression rings and a little less for the oil control rings.
Wear in the piston ring grooves makes the rings rise and fall throughout the movement of the piston, so
creating a pumping action and resulting in heavy oil consumption. Excessive gas blow-by, loss of
compression will also take place if this gap is too much.
During service, the piston ring may have lost some of its elastic properties due to which radial pressure
will be reduced on the cylinder wall. This property can be checked by pressing together worn and a new
ring, as in figure and observing whether the gap of the worn ring closes more than the new ring.
Removing and Fitting the Rings
The piston rings should be carefully removed from the piston either with a special removal and
installation tool or with three brass strips. The tool expands the ring so that it may be easily removed
from the piston. In the latter case, three strips are spaced around the circumference of the piston and
the rings are fitted over them.
The strips can be withdrawn and the ring is dropped into the groove. Ring compressor is used to
compress the rings for inserting it into the cylinder while assembling the piston and cylinder. The gaps of
the rings should not be in line, but they should be staggered so as to prevent the compression from
having a direct path to leak by the piston skirt.
Piston Pin
The piston pin connects the piston and the small end of the connecting rod. The piston pin is generally
hollow and made from case hardened steel heat treated to produce a hard wear-resistant surface.
There are three different methods of connecting piston and connecting rod by the piston pin.
1. The pin is fastened to the piston by set screws through the piston boss and has a bearing on the
connecting rod, thus permitting the connecting rod end to swivel as required by the combined
reciprocating and rotary motion of the piston and crankshaft. As shown in the figure.
TheEngineersPost.com
Page 8
Types of Piston Rings
2. The pin is attached to the connecting rod with a clamp screw. In this case, the piston bosses form the
bearing. A suitable slot is made on the circumference of the piston pin in which the clamp screw is fitted.
As shown in the figure.
3. The pin floats in both the piston bosses and the small end of the connecting rod. It is prevented from
coming in contact with the cylinder wall by two lock rings fitted in grooves in the outer end of the piston
bosses, these rings are called circlips.
This method is now most generally used. In this case, a bushing of phosphor bronze or aluminum is used
in the small end of the connecting rod. The bush develops very little wear and renewal only at long
intervals.
Piston Pin Fitting
Piston pins may be selectively fitted and, if supplied with the piston, are not interchangeable. In very
heavy alternate loading of the piston pins of compression ignition engines, special care is taken to avoid
the risk of fatigue cracks.
The external bearing surface is finished to a very high degree of accuracy to ensure the correct fit in the
piston and connecting rod. Piston pin should be inspected for wear, cracking, or pitting. Circlips should
always be renewed, and where soft end pads are fitted, check that they are not loose or cracked.
TheEngineersPost.com
Page 9
Types of Piston Rings
Conclusion
If you have still any doubts about the “Types of Piston Rings” you can contact us or ask in the
comments.
We have also a Facebook community for you guys. If you want, you can join our community, here is the
link to our Facebook group. If you like our article then please share it with your friends. Have any
questions about any topic just feel free to ask in the comment section.
