PALAMATIC VF TECHNICAL SPECIFICATION

advertisement
TECHNICAL SPECIFICATION
MODELS
VF01
VF02
VF03
VF04
VF05
OVERALL DIMENSIONS IN MM
660
820
1,070
1,070
1,100
FLOW RATE IN T./H.
0à1
1 à 2.5
2.5 à 4
4à6
5à8
Ø PIPING
38
51
63.5
76
104
Ø PRODUCT OUTLET
200
200
250
300
300
Palamatic Process offers the vacuum transport system V-Flow® running on a dense phase principle.
The bulk material is vacuumed through a vacuum pump (electric or pneumatic) to a arrival cyclone (cyclo-filter) with tangential
