Department: Mechanical Department Subject: Metallurgy Assignment (2): Crystal structure Lecturer: Dr. Shaimaa Mostafa Assistants: E. Doaa Bakr Academic Year: 2018 -2019 Semester: Spring 1- What is the relationship between the length of the side a of the BCC unit cell and the radius of its atoms? 2- How many atoms per unit cell are there in the FCC crystal structure? 3- Calculate the volume of an FCC unit cell in terms of the atomic radius R. 4- Show that the atomic packing factor for the FCC crystal structure is 0.74 and for BCC is 0.68. 5- If the atomic radius of aluminum is 0.143 nm, calculate the volume of its unit cell in cubic meters if Al has FCC crystal structure. 6- Calculate the radius of a palladium atom, given that Pd has an FCC crystal structure, a density of 12.0 g/cm3, and an atomic weight of 106.4 g/mol. 7- Calculate the radius of a vanadium atom, given that V has a BCC crystal structure, a density of 5.96 g/cm3, and an atomic weight of 50.9 g/mol. 8- Iron has a BCC crystal structure, an atomic radius of 0.124nm, and an atomic weight of 55.9 g/mol. compute the theoretical density of Iron. 9- Some hypothetical metal has the simple cubic crystal structure shown in Figure. If its atomic weight is 74.5 g/mol and the atomic radius is 0.145 nm, compute its density.
