PCM-3521
Video Modules
PC/104 VGA Module
Features
PC/104 Interface
Topro® TP6508 IQG for Lead-free
1024KB Video RAM
Supports CRT and TTL MONO/DSTN/TFT LCD
Ordering Information
• TF-PCM-3521B1-01
PC/104 Board VGA Module with Topro® TP6508IQG
Specifications
VGA Chip
Topro® TP6508IQG
LCD Interface
Supports 12/18/24-bit LCD
Resolutions
Up to 1024 x 768 for LCD
Up to 1280 x 1024 for CRT
Other
Supports LCD & CRT simultaneous display
True-color and Hi-color display capability with LCD and CRT up to
640x480 resolution
Operating Temperature
32ºF ~ 140ºF (0ºC ~ 60ºC )
PCM-3115C
PCMCIA Modules
PC/104 2-slot PCMCIA Module
Features
PCMCIA Socket Supports Two Type I/II Cards or One
Type III Card
Bootable Function From Linear Flash Card, ATA Card
and SRAM Card
Ordering Information
• TF-PCM-3115C
PC/104 Board 2-slot PCMCIA Module
Specifications
Standard
Complies with PCMCIA v.2.1 and JEIDA v4.2
Memory
Programmable 8KB boot FLASH ROM
Interface
16-bit data bus
Indicator
Busy status LED
Power Requirement
+5V
