Zn/MnO2
2032
Size: CR2032
2.0 mm
MIN.
Lithium-Manganese Dioxide Battery
20.0 mm
19.7 mm
Nominal Voltage:
3 V
Average Weight:
3.14 gm (0.11 oz.)
Volume:
0.63 cm (0.04 in. )
Terminals:
Flat
Operating Temperature
Range:
-20 C to 54 C
o
o
(-4 F to 130 F)
ANSI:
IEC:
5004LC
CR 2032
3
o
3
o
Dimensions shown are IEC/ANSI standards
o
o
3.5
3.3
3.3
3.1
3.1
2.9
2.9
2.7
2.7
Voltage
Voltage
Typical Discharge Characteristics at 21 C (70 F)
3.5
2.5
o
o
Typical Discharge Characteristics at 21 C (70 F)
2.5
2.3
2.3
2.1
2.1
15 K Ohm
6.5 K Ohm
1.9
1.9
1.7
1.7
1.5
1.5
0
100
200
300
Hours of Service
400
500
600
0
200
400
600
800
1000
1200
Hours of Service
Berkshire Corporate Park
Bethel, CT 06801 U.S.A.
Telephone: Toll-free 1-800-544-5454
Internet: www.duracell.com
* Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide.
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
6/08
