DG HD-Breakout Box (HD-BOB)
November 8, 2012
Overview
The HD-BOB allows quick access to signals on DB9, DB15 and DB25 cables. The circuit board
is RoHs compliant, lead free, and allows for .1 to 32VDC with 2.5 Amps of current flow on
each pin. The size of the box is 6.2”x7”x1.75” with a temperature range of -10 to 80ᴼC.
