1-5/16
REF
PO#: XXXXXX
2-3/16"
REF
TOP VIEW
BOTTOM VIEW
ACORN ENGINEERING COMPANY
P.O. BOX 3527 INDUSTRY, CA. 91744
(626)336-4561 FAX (626) 961-2200
TITLE
MATER-TROL DAUGHTER BOARD
JOB OR SECTION
SCALE
1:1
ELECTRICAL COMPONENTS
DATE
12-11-08
DRN. BY
ALP
MATERIAL TYPE
HALB
DRAWING NUMBER
0715-035-000W
ECO REVISION
REV. DATE
1
SHEET
OF
1
TOLERANCES: UNLESS OTHERWISE NOTED, DECIMAL DIMENSIONS .XXX=+/-.005, .XX=+/-.015, BREAK ALL SHARP CORNERS, ALL RADII MINIMUM
