 Lubrication Systems
 Hydraulic Power Units
 Stationary & Portable Filtration &
 Purification Systems
Complete turnkey systems to thoroughly clean, dehydrate and degas lube oils, transformer and insulating oils and hydraulic fluids
Trailer systems for completely purifying insulating oils for transformers, oil filled circuit breakers and load tap changers. These systems are available in a variety of configurations with process flow rates ranging from 5-100 GPM and are capable of removing nearly all free and dissolved water, dissolved gases, and carbon fines to restore dielectric strength.
The onboard Thermo-Vac system is available in High-Vac or Low Vac models with vacuum level capability ranging from
0.5-2.0 Torr. Absolute rated 1 micron filters are used to remove carbon fines and low watt density insulated oil heaters from 16KW-224KW are available.
Features and Options Include:
●Heavy duty trailer with all modern safety features and electric brakes
●Thermo-Vac Oil Purifier with three stage treatment to remove moisture, gases and particulate matter
●Doble moisture in oil sensor providing real time and stored memory information of moisture in oil content in PPM
●Laser particle counter
●Auxiliary vacuum pump
●Onboard diesel generator
●Oil storage and processing tank ●Auxiliary generator power take off options
●Explosion-proof models
●Fullers Earth or other adsorptive media packages
●Fluorescent interior lighting package
The system shown in the example photo is equipped with a 20 GPM Thermo-Vac
Oil Purification System, a 550 gallon oil storage and processing tank and a 65KW diesel generator.
Each system is designed and built to meet the customers specific applications. We have flexibility in layout design and features so please feel free to contact us to discuss your specific needs or requirements.
Our systems are built with pride in the U.S.A.
We are your single source for purification of oil, water, air
& gas, hydraulic fluids, chemicals and petroleum!
