Natural, Analog Interactions
with Surface Computing, Depth
Cameras and Beyond
Andy Wilson
Microsoft Research
Today: “Multi-touch” as “multi-cursor”
• Problem 1: Hit testing
OK
OK
OK
Today: “Multi-touch” as “multi-cursor”
• Problem 2: Correspondence is hard
1
1
Clockwise
motion
3
2
?
3
2
3
Counter
Clockwise
motion
Surface input
There is more to life than
target selection
Representations Matter
• Range of fidelity
– Point vs. contour
– Contour vs. mesh
– Single point motion vs. flow field
• Robustness
– Analog interactions less precise but less likely to fail
catastrophically
• Multiple notions of “tracking”
– 1. we care to actually know which object it is
– 2. we simply want correct motion
Standard Model
•
•
•
•
Sense the world
Reduce to tracked points
Hit test points against UI elements
Take action
Modern Model
• Compute possible actions given state of the
application
• Sense the world
• Interpret sensing data given possible actions
• Select action
