Preparation of compressed air ► Maintenance units and components
3/2-shut-off valve, mechanically operated, Series AS1-BAV
► G 1/4 ► Air supply: right
Version
Ball valve, Can be assembled into blocks
for padlocks
lockable
Working pressure min./max.
0 bar / 12 bar
Medium
Compressed air
Neutral gases
Medium temperature min./max.
-10°C / +50°C
Ambient temperature min./max.
-10°C / +50°C
Actuating element
rotary switch
Max. particle size
25 µm
Materials:
00137244
Housing
Polyamide
Front plate
Acrylonitrile butadiene styrene
Seals
Acrylonitrile Butadiene Rubber
Actuating element
Polyoxymethylene
Technical Remarks
■ The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C.
Port
Exhaust
G 1/4
G 1/4
Qn
Weight
1▶2
2▶3
[l/min]
[kg]
2600
380
0.15
Nominal flow Qn with secondary pressure p2 = 6 bar at Δp = 1 bar
Flow rate characteristic
p2 [bar]
10
8
6
4
2
0
500
1000
1500
2000
2500
3000
3500
4000
qn [l/min]
00137168
p2 = secondary pressure
qn = nominal flow
Part numbers marked in bold are available from the central warehouse in Germany, see the shopping basket for more detailed information
Pneumatics catalog, online PDF, as of 2016-08-30, ©AVENTICS S.à r.l., subject to change
Part No.
R412014742
2
Preparation of compressed air ► Maintenance units and components
3/2-shut-off valve, mechanically operated, Series AS1-BAV
► G 1/4 ► Air supply: right
Rear exhaust
p2 [bar]
10
8
6
4
2
0
250
500
750
1000
1250
1500
qn [l/min]
00137169
p2 = secondary pressure
qn = nominal flow
Dimensions
54
52
27
24.2
43
A1
A2
A3
00137739
A1 = input
A2 = output
A3 = ventilation port
