LOAD CONTROLS INC. JULY 16, 2007
Application :
Feed Rate Control System
The UPC Power Cell and the Action Instruments model
G408 Opto-Isolator work together to control feed to
grinders, saws, crushers or to effect a valve controlling
viscosity in a mixing vessel. The UPC measures motor
HORSE POWER and sends a 0-10V or 4-20ma signal
to the G408 which is set for an INVERSE function so
that an increase in load will slow the feed or control a
valve. This CONTROL FEEDBACK will stabilize the
process for optimum performance. The offset (ZERO)
and gain (SPAN) are set with adjustments on the G408.
UPC POWER CELL
G408-0001
• Field adjustable scale 5 to 150 H.P.
• Adjustable Response Time stops system
oscillations or hunting.
• 0-10V and 4-20ma Analog Outputs
• Works on VFD’s or across the line Starters
For technical data:
www.actionio.com/products/slimpak/g408.html
Analog IN +
0-10V
4-20ma IN
41
42
51
v
v
11
PWR
9 - 30 VDC(+)
21
Isolated
DC/DC Conv.
52
+ OUT Analog
10-0V
OUT 20-4ma
12
22
PWR
Com (-)
9
8
7
L3
.5 “
L3
51 OUTPUT (+)
41 DC INPUT (+)
OUTPUT (-) 52
DC INPUT (-) 42
L2
4.14”
MOTOR
6
5
4
3
2
1
L2
3.48”
INPUT
SPAN
L1
L1
ZERO
ULTRA
SLIM PACK
G408
1 2 3 4 5 6
7 8
9
DC PWR (-) 12
DC PWR (-) 22
3.54”
11 DC PWR (+)
21 DC PWR (+)
DIN Rail Mounted
For data sheet or application help :
sales@loadcontrols.com
LOAD CONTROLS
INCORPORATED
53 TECHNOLOGY PARK RD.
STURBRIDGE, MA 01566
PH.888-600-3247 FX.508-347-2064
Factory Assistance
For additional information on calibration, operation and
installation contact our Technical Services Group.
