Air-cored coils
We produce 90% of our products to suit specific customer
requirements.
Basic data for the coils:
Machine type 1
Machine type 2
Wire gauge
0,02 mm to 0,40 mm
0,10 mm to 1,25 mm
Internal
diameter
1,2 mm to 60 mm
5 mm to 200 mm
External
diameter
1,5 mm to 70 mm
8 mm to 300 mm
Coil width
0,3 mm to 15 mm
1,5 mm to 30 mm
Coil types
similar, bifilar, trifilar
Other wire gauges and dimensions are available on request.
If required, we can also produce coils with HF stranded wire, and taps.
We use our own specially developed software to assist in development and design to meet customer-specific requirements.
hr electronic gmbh
Vogelherd 23
D-78176 Blumberg
Subject to modifications / version 1.1 - 05/2014
Phone: +49 (0)7702-477 960
Fax: +49 (0)7702-477 989
Email: [email protected]
Internet: www.hrelectronic.com
