DC Bridges

advertisement

RICHLAND COLLEGE

School of

Engineering Business & Technology

Rev. 0 – W. Slonecker

Rev. 1 (8/26/2012)– J. Bradbury

Rev. 2 (3/13/2015)– J. Bradbury

INTC 1307

Instrumentation Test Equipment

Assignment 5

Wheatstone Bridge Circuits

Unit 5 Assignment

For this assignment, use your own paper to show solutions. Bridges should be drawn in the form shown to the right. For each problem, draw the schematic, label the parts, show your formulas and calculations.

Underline your final answers.

NO WORK, NO CREDIT

Name _____________________________________

1. Your balanced bridge circuit has:

R1 = 400  , R2 = 4k  , R3 = 5k 

What is R4?

2. You are required to build a bridge using a 60v power supply. R1 = 1k  , R2 = 5k  , Ra is a pot set to 3k  when the bridge is balanced. You calculate Rb to be __________ ohms. The detector is a galvanometer with an internal resistance of 100  . When nulled, the galvanometer has

_________ volts across it and _________ mA through it.

3. You ask your lab partner to duplicate the bridge in problem 2 using a voltmeter instead of a galvanometer. He mistakenly installs a 3k  resistor for Rb. The voltmeter has an impedance of

9M  with its + terminal at Point 1 and its  terminal at Point 2.

Besides following all the page instructions, calculate the voltage reading on the meter and the current through the meter.

4. In problem 3, your lab partner decides the problem is caused by the voltmeter and replaces it with the original galvanometer. Thevenize the bridge and determine the voltage across the galvanometer and the current through it.

Page 1 of 2

5. You have a circuit of two parallel wires, each

1000’ long in a cable. The Murry Loop is balanced when R1 = 200  , R3 = 300  ,

R2 = RX = 80  (LX resistance)

If the wire resistance is 0.1

 /ft., calculate the LX length to the fault.

Use the LX equation on page 7 of Unit 5 and the

LA distance stated in the problem to calculate a new value for LX.

Does it match the first value you got using resistance?

V1

LX

Fault to gnd

R1

U1

+

0.000

-

V

R3

Faulted Good

LB LA

RA ohms

Short

Page 2 of 2
