Addressable Fire Alarm Systems /
Addressable Remote Indicator LED
(ZTA-LE2, ZTA-LE2/10 & ZTA-LE3)
ZTA-LE2 & ZTA-LE2/10
The ZTA-LE2 remote LED indicator has been
designed so that it is loop powered and can
be installed anywhere on the loop (it can
either be connected as part of the loop, or
as a spur from the detector it is indicating).
This minimises the amount of wiring from a
detector to its remote indicator.
It has the same address as the detector it is indicating
and will light whenever the panel tells the detector to
do so.
There is also a version that will listen to a number of
consecutive addresses, designed for when there are
more than one detector out of sight.
ON
1 2 3 4 5 6 7 8
ZTA-LE2 & ZTA-LE2/10
+
+
L2
IO
IO
IO
-R
UT
L2
IN
L1
L1
-R
UT
IN
L1
L1
L2
L1
-R
UT
IN
L1
ON
Loop out to next
detector or return
to panel.
1 2 3 4 5 6 7 8
Loop in from
Fire alarm panel
+
+
L2
IO
IO
IO
Loop in from
Fire alarm panel
Loop out to next
detector or return
to panel.
Remote Indicator
+VE
LED
-VE
ZTA-LE3
-R
UT
L2
IN
L1
L1
-R
UT
L2
IN
L1
Remote Indicator
L1
-R
L1
L1
UT
IN
ZTA-LE3
Remote Indicator
R
IN
L1
Remote LEDs are used in installations where a detector
going into alarm is likely to occur out of sight (for
instance behind a locked door or in a ceiling void). The
indicator will then show the location of the alarm.
The ZTA-LE3 is designed to work with addressable Fyreye
detectors on the Premier AL panel only. They will need
to be programmed to operate and can be triggered from
either a single detector or a group of detectors.
Model
ZTA/LE2
ZTA/LE2-10
ZTA-LE3
48-020A
48-021
Part No.
48-020
Input Voltage
17 - 33V DC
Quiescent Current
1.5 mA
Alarm Current
10mA
Addresses
Repeated
1
Colour
White Plastic, Red LEDs
Operation Colour
Red
Operating
Temperature
-0°C to 50°C
0 mA
1-10
1
Maximum Humidity 95% RH N/C
T
OU
I
L1
Loop in from
fire alarm panel
The ZTA-LE3 is a low cost alternative to the
fully addressable remote LED indicator ZTALE2.
L2
Loop out to next
detector or
return to panel
IP Rating
IP 43
Size (WxHxD mm)
86 x 86 x 23
Weight
40 g
Issue #3 Issue Date 05/07/2010 Revision #2
