007 Switchbox
Type SLB-**M2*, SBB-**M2*, SBS-**M2*
Installation instructions
1.0
Switch Specification
Switch type: M3
Number of switches: 1 or 2
Contacts: Fine silver contacts - Double pole double throw. (D.P.D.T)
Rating 250V AC - 10A Resistive load. 4A Inductive load.
2.0
Electrical terminations - Screw clamp 2.5mm2
Note: Termination details can also be found inside the cover of the switchbox
6 Common (Yellow)
5 Normally Closed (Blue)
4 Normally Open (Red)
3 Common (Yellow)
2 Normally Closed (Blue)
1 Normally Open (Red)
Two switch - SB*-**M31
12 Common (Yellow)
11 Normally Closed (Blue)
10 Normally Open (Red)
9 Common (Yellow)
8 Normally Closed (Blue)
7 Normally Open (Red)
6 Common (Yellow)
5 Normally Closed (Blue)
4 Normally Open (Red)
3 Common (Yellow)
2 Normally Closed (Blue)
1 Normally Open (Red)
Top
Switch
Bottom
Switch
Four switch - SB*-**M32
3.0
Cable entry - M20 x 1.5 or 1/2" NPT.F,
4.0
Switch Cam Setting.
Shaft
The upper switch should be
set to indicate the valve or
actuator open position.
↓
The lower switch should be
set to indicate the closed
position.
Hub
The switch actuation cams are driven via splines located
on their inner diameter which engage with the drive hub.
To adjust the cam position slide the cam off the hub,
compressing the location spring. Rotate to the desired
position and release. Check that the cam has correctly
re-engaged with the hub.
K Controls Limited
2 Crown Way
Crown Business Centre
Horton Road, West Drayton
Middlesex. UB7 8HZ England
Spline
↔
Cam
Spring
Tel: (Int +44) (0) 1895 449601
Fax: (Int +44) (0) 1895 448596
EMail: sales@k-controls.co.uk
http://www.k-controls.co.uk
Doc - KSP-0649 Rev 1
