EDIBON, S.A.
Fecha: 12/01
SBB
BALL AND BEAM SYSTEM
TENDER SPECIFICATIONS
A- TECHNICAL DATA:
1)
1 D.C. motor with gear box and armature controlled, that allows the oscillating movement of the guide adjusted to the motor
axis.
2)
A rod with guide for ball displacement.
3)
1 Ball.
4)
Ball position sensors in the guide (two conducting wires), rod inclination angle (potentiometer), and motor speed (tachometric
dynamo).
B- MANUALS:
This unit will be supplied with the following manuals:
1. Required services manual.
2. Assembly and installation manual.
3. Interface and control software manual (if it is necessary).
4. Starting-up manual.
5. Safety manual.
6. Maintenance manual.
7. Calibration manual.
8. Practices manual.
C- PRACTICES:
This unit is designed to be able to do the following practices:
1. Stabilization of a naturally unstable system, and control of the ball position.
