3F
Condulet® Elbows and Tees
IEC Certifications
Zone 1
Zone 2
Zone 21
Zone 22
3F
FE and FT Series
Applications:
FE and FT conduit fittings are installed in
hazardous areas to:
• Act as draw-in outlets especially for
cables that are stiff due to large size or
type of insulation
• Make 90º bends in conduit systems,
allowing for a straight pull in either
direction
• Provide access to wiring for
maintenance and future system changes
Features:
• Maximum volume for bends within a
compact overall size
• Large openings to facilitate cable pulling
Certifications and
Compliances:
Type of Protection
• Ex d, DIP A21, IP67
Degree of Protection
Ordering Information:
Inspection Elbows and Tees Selection
Cat. #
Type
Entry Size (metric)
FE1
FE2
FT1
FT2
Elbow
Elbow
Tee
Tee
M20
M25
M20
M25
(F)-M20
(F)-M25
(F)-M20
(F)-M25
(F)
(F)
(F)
(F)
Dimensions (mm)
• IP67
Gas Group
• IIB
Approvals
• Ex1108U
Standard Materials:
• Body – Copper-free aluminum
• Cover – Brass
Standard Finishes:
• Natural
Options:
Description
Suffix
NPT & BSP thread sizes Consult Factory
62
