Commodity Data Center Design
James Hamilton
2007-10-08
JamesRH@microsoft.com
http://research.microsoft.com/~jamesrh
Containerized Products
Caterpillar
Portable Power
Nortel Steel Enclosure
Containerized telecom equipment
Rackable Systems Concentro
1,152 Systems in 40’ (9,600 cores/3.5 PB)
Datatainer
ZoneBox
Google WillPower
Will Whitted
1/21/2007
Sun Project Black Box
242 systems in 20’
Rackable Systems Container
Cooling Model
Petabox Internet Archive
Brewster Kahle
2
Cooling, Feedback, & Air Handling Gains
Intel
•
•
•
•
Intel
1/21/2007
Verari
Tighter control of air-flow increased delta-T and overall
system efficiency
Expect increased use of special enclosures, variable
speed fans, and warm machine rooms
CRACs closer to servers for tighter temp control
feedback loop
Container takes one step further with very little air in
motion, variable speed fans, & tight feedback between
CRAC and load
3
Shipping Container as Data Center Module
•
Data Center Module
– Contains network gear, compute, storage, & cooling
– Just plug in power, network, & chilled water
•
Increased cooling efficiency
– Variable water & air flow
– Better air flow management (higher delta-T)
– 80% air handling power reductions (Rackable Systems)
•
Bring your own data center shell
–
–
–
–
•
Political/Social issues
–
•
•
•
•
Just central networking, power, cooling, security & admin center
Can be stacked 3 to 5 high
Less regulatory issues (e.g. no building permit)
Avoids (for now) building floor space taxes
USA PATRIOT act concerns & regional restrictions
Move resources closer to customer (CDN mini-centers)
Single customs clearance on import
Single FCC compliance certification
Distributed, incremental fast built mini-centers
1/21/2007
4
Manufacturing & H/W Admin. Savings
•
Factory racking, stacking & packing much more efficient
– Robotics and/or inexpensive labor
•
Avoid layers of packaging
– Systems->packing box->pallet->container
– Materials cost and wastage and labor at customer site
•
Data Center power & cooling expensive consulting contracts
– Data centers are still custom crafted rather than prefab units
– Move skill set to module manufacturer who designs power & cooling once
– Installation design to meet module power, network, & cooling specs
•
More space efficient
– Power densities in excess of 1250 W/sq ft
– Rooftop or parking lot installation acceptable (with security)
– Stack 3 to 5 high
•
Service-Free
– H/W admin contracts can exceed 25% of systems cost
– Sufficient redundancy that it just degrades over time
• At end of service, return for remanufacture & recycling
– 20% to 50% of systems outages caused by Admin error (A. Brown & D. Patterson)
1/21/2007
5
Systems & Power Density
• Estimating datacenter power density difficult (15+ year horizon)
– Power is 40% of DC costs
• Power + Mechanical: 55% of cost
– Shell is roughly 15% of DC cost
– Cheaper to waste floor than power
• Typically 100 to 200 W/sq ft
• Rarely as high as 350 to 600 W/sq ft
– Modular DC eliminates impossible shell to power trade-off
• Add modules until power is absorbed
• 480VAC to container
– High efficiency DC distribution within
– High voltage to rack can save >5% over 208VAC
• Over 20% of entire DC costs is in power redundancy
– Batteries able to supply up to 12 min at some facilities
– N+2 generation at over $2M each
• Instead, use more smaller, cheaper data centers
• Eliminate redundant power & bulk of shell costs
• Resource equalization
1/21/2007
6
Where do you Want to Compute
Today?
Slides posted soon to: http://research.microsoft.com/~JamesRH
