DOCUMENT #:
GSC15-PLEN-58
FOR:
Presentation
SOURCE:
ETSI
AGENDA ITEM:
PLEN 6.1
CONTACT(S):
Marylin Arndt, TC M2M chair
M2M and Internet of Services
"When the Machines start talking"
Presenter: Joachim Koss,
ETSI Board member
Global Standards Collaboration (GSC)
GSC-15
Highlight of Current Activities (1)
 Developing standards to support an M2M architecture and
a set of capabilities for M2M services. Promoting innovation
across the industry by providing an end-to-end generic
vision of the M2M communications and services. The
multiple vertical applications will be easily deployed in a
general framework, allowing development of services
independently of the underlying network.
 Coordinating with other SDOs and consortia to achieve the
first step of the "Internet of Services".
 First release expected in 2010.
2
Highlight of Current Activities (2)
 Cooperating with ETSI TCs TISPAN, ERM, MSG, PLT and
the other European Standards Organisations (ESOs) on
the work in answer to EC standardisation mandate M/441
on "smart metering".
 Cooperating with ETSI TC TISPAN and TC ERM and the
other ESOs in answering the EC standardisation mandate
M/436 on "RFID privacy and security".
 Other EC mandates to come: smart grid, electric vehicle,
Internet of Things.
 Numerous links with other SDOs and industrial alliances,
that have launched activities on sensor networks,
connected devices, etc., …
3
Inverting the pipes and going to mass
market applications
existing proprietary
vertical
applications…
Business
Application
applications share common
infrastructure, environments
and network elements
Business
Application
Business
Applicationi
Business
Application
Application Infrastructure
Network Infrastructure
Existing
Mobile
Infrastructure
Converged Network
(IP + mobile infrastructure
)
SIM based
dedicated
devices
Gateways
/
Concentrators
M2M Device
M2M Device
#
M2M Device
#
Source: HP
4
ETSI TC M2M Release 1 Plan
1
Stage 1 (requirements) Jan 2010
 Requirements document is stable content wise; some editorial work
remains.
2
Stage 2 (architecture) July 2010
 Architecture:
 Key capability identified
 Message flows documented
 Identified key interfaces for release 1 stage 3 (detailed specs)
3
Stage 3 (protocols) December 2010
 Protocols:
 New WI agreed at the last meeting to progress to stage 3 work for 3
interfaces: mId, dIa and mIa
5
Conclusions
 M2M related technologies are in place, and the
market has massive potential for growth.
 Standardization is essential for long term
development of the technology and for
interoperability of networks and services.
 Operators, integrators and vendors have expressed
the need to standardize end-to-end M2M.
 Regulation in Europe, USA and Asia is pushing for
a standards based solution.
 It is essential to have globally compatible
standards.
6
Supplemental Slides
7
SDOs in the scope of M2M, USN, IOT
 Link with other SDOs
• Identification and Privacy, link with ITU-T and ISO/IEC-JTC1 work
on NGSN and USN
• ETSI SCP on USIM M2M Form factor (need on security PF also)
• 3GPP SA1, SA2 and SA3 work on M2M (TR 22.868, and TR 33.812)
on Mobile NWs, 3GPP GERAN2
• Link with Industrial Alliances on vertical applications (Zigbee, Wosa,
EPCGlobal, OMA, HGI, …)
• IETF (CORE, ROLL and 6Lowpan)
• IEEE 802.xx and ETSI ERM-TG28, ERM-TGUWB
• ETSI TISPAN, TC ITS, EP e-Health
• For M/441 links with CEN TC294, CLC TC13, CLC TC205,
DLMS_UA, ESMIG, IEEE 802.15.4g,
8
M2M Links with other SDOs and Industrial Groups
EPCGlobal
ISO/IEC JTC1
GS1
UWSN
ESMIG
IUT-T
Metering
NGN/Smart Grids FG
OASIS
CEN
CENELEC
Smart Metering
Smart Metering
Capillary
Access networks
Metering
IETF 6LowPAN
WOSA
wireless
Wide Area
Network
IPV6
Hardware and
Protocols
Utilities
Service Platform
W3C
IPSO
HGI
Home Gateway
Initiative
KNX
M2M Gateway
Phy-Mac Over IPV6
W-Mbus
IP Network
IETF ROLL
Routing over Low Power
Lossy Networks
wireline
IEEE
ZCL
802.xx.x
Application
ZigBee Alliance.
ZB Application Profiles
OMA
GSMA
SCAG,…
3GPP
SA1, SA3, ,…
9
