OL 770-ADMS
Automated Display
Measurement System
The OL 770-ADMS is an integrated solution for
automated display measurements.
The
system combines the versatile OL 770
Spectroradiometer with precise modular
positioning stages. The OL 700-MPXYZ 3-axis
Translation Stage locates the imaging
telescope (OL 610/620), and the OL 700MPHV Dual Axis Goniometer orients the
device under test at the required measurement
angle. The two stages and the OL 770
Spectroradiometer are coordinated by a
powerful scripting software package. Example
scripts are available for standard VESA FPD
measurements. Users can write or adapt
scripts to meet custom test requirements or to
perform standardized measurements on
virtually any type or size of display.
Accessories
700-430 Scripting Software
700-MPC 5-Axis Motion Controller
700-MPXYZ 3-Axis Translation Stages
700-MPHV Dual Axis Goniometer
700-MPH 1-Axis Goniometer (horizontal)
700-MPC2 2-Axis Controller
SPECIFICATIONS *
OL 700-MPXYZ 3-Axis Linear Motion Stage
X Axis Motion Range
17.8 cm (7.0 in)
Y Axis Motion Range
17.8 cm (7.0 in)
Z Axis Motion Range
8.6 cm (3.4 in)
Drive Screw Pitch
5.0 mm (0.19685 in)
Incremental Resolution
0.0125 mm (0.0005 in)
Positional Accuracy
0.050 mm (0.002 in)
Positional Repeatability
0.0125 mm (0.0005 in)
Maximum Load Capacity
6.0 kg (13.2 lbs)
OL 700-MPHV Dual Axis Goniometer
180° total
Rotary Motion Range
(± 90° from normal incidence)
Angular Resolution
Angular Accuracy
Angular Repeatability
Maximum Load Capacity
(device under test)
0.005°
< 150 arc-sec (0.04°)
< 50 arc-sec (0.01°)
4.5 kg (10 lbs)
OL 700-MPC Motion Controller
Power Input
Power Consumption
Computer Interface
Universal 100 to 240 VAC
50-60 Hz
200 W
RS232 Serial Interface or
Ethernet Interface
*Custom configurations, ranges, and maximum capacity loads
can be provided
.
Contact: sales@goochandhousego.com
www.goochandhousego.com
As part of our policy of continuous product improvement, we reserve the right to change specifications at any time
Bulletin 82/ Rev 8-09
Page 1 of 2
OL 770-ADMS
Automated Display Measurement System
Application Software
Sample scripting environment
Automated measurement processes in the OL 770-ADMS is user-friendly scripting environment. Features include:
Plug-in architecture
Ability to write custom scripts, performing complex motion control in conjunction with optical measurements
Scripting capabilities of both Excel and PowerPoint
o Advance targets in PowerPoint
o Set cell on any worksheet or spreadsheet for data collection and automated analysis
o Set groups of cells with scan data
Windows XP and Vista compatible
Create complete control sequences in Visual Basic format
Custom built-in functions for:
o User-determined input parameters
o User decisions
o Warnings about system situations or conveying step procedures
Completely expandable and scalable
Plug-ins can be used as standard .NET DLLs for user out programming environment
Drivers as .NET DLLs
OL 700-MPHV Dual Axis Goniometer
OL 700-MPXYZ 3-Axis Transition Stage
See Bulletin 250 on the OL 770-DMS Display Measurement System for further information on related products.
