Nihan Kesim Çiçekli email: nihan@ceng.metu.edu.tr
URL: http://www.ceng.metu.edu.tr/~nihan/ceng302
1

• Instructor: Nihan Kesim Çiçekli
•
Office: A308
• Email : nihan@ceng.metu.edu.tr
•
Lecture Hours: Tue. 10:40-11:30 (IE102);
Thu. 13:40-15:30 (IE102)
•
Course Web page: http://www.ceng.metu.edu.tr/~nihan/ceng302
•
Teaching Assistant:
Ali Anıl Sınacı
2

1.
Raghu Ramakrishnan, Database Management
Systems, McGraw Hill, 3 rd edition, 2003 ( text book ).
2.
R. Elmasri, S.B. Navathe, Fundamentals of
Database Systems, 4 th edition, Addison-Wesley,
2004.
3.
A. Silberschatz, H.F. Korth, S. Sudarshan,
Database System Concepts, McGraw Hill, 4 th edition, 2002.
3

• Assignments 20 %
• Midterm 1
25 %
• Midterm 2
• Final Exam
25 %
30 %
4

• Policy on missed midterm:
– no make-up exam
• Lateness policy:
– Late assignments are penalized up to 10% per day.
• All assignments are to be your own work.
5

• Introduction to Relational Database Management Systems
• The Relational Data Model
• Relational Algebra
• SQL
• QBE
• Entity-Relationship Model
• Relational Database Design: Normalization
• Secondary Storage Devices
• Sequential Files
• Indexed Sequential Files
• Hashing
6


A very large, integrated collection of data.

Models real-world enterprise.
– Entities (e.g., students, courses)
– Relationships (e.g., Tarkan is taking CENG302)

A Database Management System (DBMS) is a software package designed to store and manage databases.
7


Shift from computation to information
–
– at the “low end”: scramble to webspace (a mess!) at the “high end”: scientific applications

Datasets increasing in diversity and volume.
– Digital libraries, interactive video, Human Genome project, EOS project
– ... need for DBMS exploding

DBMS encompasses most of CS
–
OS, languages, theory, “AI”, multimedia, logic
?
8


Data independence and efficient access.

Reduced application development time.

Data integrity and security.

Uniform data administration.

Concurrent access, recovery from crashes.
9


A data model is a collection of concepts for describing data.

A schema is a description of a particular collection of data, using the given data model.

The relational model of data is the most widely used model today.
– Main concept: relation , basically a table with rows and columns.
– Every relation has a schema , which describes the columns, or fields.
10


Conceptual schema:
– Students(sid: string, name: string, login: string,
– age: integer, gpa:real)
Courses(cid: string, cname:string, credits:integer)
– Enrolled(sid:string, cid:string, grade:string)

Physical schema:
– Relations stored as unordered files.
– Index on first column of Students.

External Schema (View):
– Course_info(cid:string,enrollment:integer)
11

Students ( sid : string, name: string, login: string, age: integer, gpa: real ) sid name
53666 Jones
53688 Smith
53650 Smith login jones@cs age gpa
18 3.4
smith@ee 18 3.2
smith@math 19 3.8
12

 Many external schemata, single conceptual(logical) schema and physical schema .
– External schemata describe
– Conceptual schema defines logical structure
– Physical schema describes the files and indexes used.
External
Schema 1
External
Schema
2
External
Schema 3
Conceptual Schema
* Schemas are defined using DDL; data is modified/queried using DML
.
13


Applications insulated from how data is structured and stored.

Logical data independence: Protection from changes in logical structure of data.

Physical data independence: Protection from changes in physical structure of data.
* One of the most important benefits of using a DBMS!
14

 A typical DBMS has a layered architecture.

This is one of several possible architectures; each system has its own variations.
These layers must consider concurrency control and recovery
Query Optimization and Execution
Relational Operators
Files and Access Methods
Buffer Management
Disk Space Management
DB
15
