Quartz Electric Immersion Heater
1.Our quartz electric immersion heaters are CE certified.
2.It’s made of ceramic heating core, PP junction box, and PE protection cover.
3.It has good insulating function and mechanical strength.
4.It is not applicable to heat hydrofluoric acid and strong alkali for long
time.
5.It is matched with overheat protection switch of 95°C or 105°C.
6.Standard wire is 2 meters, longer can be available as customers’ requests.
7.Able to make 110V, 220V, 380V according to customers' requests.
Referential Specifications for Quartz Immersion Heater
OVERALL
LENGTH
(mm)
WATTS
VOLTS
HOT ZONE
(mm)
1000
220/380
250
500
2000
220/380
450
650
3000
220/380
600
800
Single Tube Vertical Metal Electric Immersion Heater
1. Our single tube vertical metal electric immersion heaters are strictly made of
seamless metal tubes, in vertical shape, stainless steel 304, stainless steel
316 and titanium metal material available.
2. Heater diameters of 25mm, 30mm, 38mm, 45mm, 50mm available.
3. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
4. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
5. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
6. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 9kw.
7. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
8. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Single Tube Vertical Metal Electric
Immersion Heater
WATTS
(W)
VOLTS
(V)
1000
2000
3000
4000
5000
6000
7000
8000
9000
220/380
220/380
220/380
220/380
220/380
220/380
380
380
380
TUBE
DIA
(MM)
50
50
50
50
50
50
50
50
50
HOT
ZONE
(MM)
250
350
450
600
750
900
1050
1200
1350
OVERALL
LENGTH
(MM)
430
550
650
800
950
1150
1300
1450
1600
Three Elements Vertical Metal Electric Immersion Heater
1. Our three elements vertical metal electric immersion heaters are strictly
made of seamless metal tubes, diameter 50mm, in vertical shape, stainless
steel 304, stainless steel 316 and titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
5. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 36kw.
6. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
7. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Three Elements Vertical Metal Electric
Immersion Heater
WATTS
(W)
6000
9000
12000
15000
18000
21000
24000
27000
30000
36000
TUBE DIA
VOLTS (V)
(MM)
380
380
380
380
380
380
380
380
380
380
50
50
50
50
50
50
50
50
50
50
HOT ZONE
(MM)
OVERALL
LENGTH
(MM)
350
450
600
750
900
1050
1200
1350
1500
1600
600
750
900
1050
1200
1350
1500
1650
1800
2000
Triple Vertical Metal Electric Immersion Heater
1. Our triple vertical metal electric immersion heaters are strictly made of
seamless metal tubes, diameter 50mm, in vertical shape, stainless steel 304,
stainless steel 316 and titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
5. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 36kw.
6. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
7. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Triple Vertical Metal Electric Immersion
Heater
WATTS
(W)
VOLTS
(V)
6000
9000
12000
15000
18000
21000
24000
27000
30000
36000
380
380
380
380
380
380
380
380
380
380
TUBE
DIA
(MM)
50
50
50
50
50
50
50
50
50
50
HOT
ZONE
(MM)
350
450
600
750
900
1050
1200
1350
1500
1600
OVERALL
LENGTH
(MM)
600
700
850
1000
1150
1350
1450
1600
1750
1850
Flange Three Elements Vertical Metal Electric Immersion Heater
1. Our flange three elements vertical metal electric immersion heaters are
strictly made of seamless metal tubes, with 3 U tubes in vertical shape,
stainless steel 304, stainless steel 316 and titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. Size of the flange is decided by customers.
5. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
6. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 12kw.
7. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
8. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Flange Three Elements Vertical Metal
Electric Immersion Heater
VOLTS
WATTS (W)
(V)
3000
6000
9000
12000
380
380
380
380
HOT
ZONE
(MM)
400
480
550
650
OVERALL
LENGTH
(MM)
650
730
850
950
Vertical Metal Electric Immersion Heater
1. Our vertical metal electric immersion heaters are strictly made of seamless
metal tubes, in vertical shape, stainless steel 304, stainless steel 316 and
titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
5. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 12kw.
6. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
7. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Vertical Metal Electric Immersion Heater
WATTS VOLTS
(W)
(V)
3000
6000
9000
12000
380
380
380
380
HOT
ZONE
(MM)
400
480
550
650
OVERALL
LENGTH
(MM)
650
730
850
950
Six Elements Vertical Metal Electric Immersion Heater
1. Our six elements vertical metal electric immersion heaters are strictly made
of seamless metal tubes, diameter 50mm, in vertical shape, stainless steel 304,
stainless steel 316 and titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
5. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 21kw.
6. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
7. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Six Elements Vertical Metal Electric
Immersion Heater
HOT OVERALL
WATTS VOLTS
ZONE LENGTH
(W)
(V)
(MM)
(MM)
6000
380
300
600
9000
380
400
700
12000
380
500
800
15000
380
600
900
18000
380
700
1000
21000
380
800
1100
Nine Elements Vertical Metal Electric Immersion Heater
1. Our nine elements vertical metal electric immersion heaters are strictly
made of seamless metal tubes, diameter 50mm, in vertical shape, stainless
steel 304, stainless steel 316 and titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
5. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 36kw.
6. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
7. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Nine Elements Vertical Metal Electric
Immersion Heater
HOT
OVERALL
WATTS VOLTS
ZONE
LENGTH
(W)
(V)
(MM)
(MM)
9000
380
300
600
12000
380
400
700
15000
380
500
800
18000
380
600
900
21000
380
700
1000
24000
380
800
1100
27000
380
950
1250
30000
380
1100
1400
36000
380
1300
1700
Single Tube L-shaped Metal Electric Immersion Heater
1. Our single tube L-shaped metal electric immersion heaters are strictly made
of seamless metal tubes, in “L” shape, stainless steel 304, stainless steel
316 and titanium metal material available.
3. Heater diameters of 25mm, 30mm, 38mm, 45mm, 50mm available.
3. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
4. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
5. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
6. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 9kw.
7. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
8. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Single Tube
L-shaped
Metal Electric
Immersion Heater
TUBE DIA
WATTS (W) VOLTS (V)
(MM)
1000
2000
3000
4000
5000
6000
7000
8000
9000
220/380
220/380
220/380
220/380
220/380
220/380
380
380
380
50
50
50
50
50
50
50
50
50
HORIZ.
(MM)
250
350
450
600
750
900
1050
1200
1350
VERT.
LENGTH
(MM)
The vertical
length is up
to customers'
needs.
Three Elements Z-shaped Metal Electric Immersion Heaters
1. Our three elements Z-shaped metal electric immersion heaters are strictly
made of seamless metal tubes, in “Z” shape, stainless steel 304, stainless
steel 316 and titanium metal material available.
4. Heater diameters of 25mm, 30mm, 38mm, 45mm, 50mm available.
3. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
4. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
5. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
6. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 36kw.
7. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
8. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Three Elements Z-shaped Metal Electric
Immersion Heater
WATTS
(W)
6000
9000
12000
15000
18000
21000
24000
27000
30000
36000
TUBE DIA
VOLTS (V)
(MM)
380
380
380
380
380
380
380
380
380
380
50
50
50
50
50
50
50
50
50
50
HORIZ.
(MM)
VERT.
LENGTH
(MM)
350
500
650
750
900
1050
1200
1350
1500
1600
The vertical
length is up
to customers'
needs.
Three Elements L-shaped Metal Electric Immersion Heaters
1. Our three elements L-shaped metal electric immersion heaters are strictly
made of seamless metal tubes, in “L” shape, stainless steel 304, stainless
steel 316 and titanium metal material available.
5. Heater diameters of 25mm, 30mm, 38mm, 45mm, 50mm available.
3. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
4. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
5. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
6. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 36kw.
7. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
8. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Three Elements L-shaped Metal Electric
Immersion Heater
WATTS (W)
6000
9000
12000
15000
18000
21000
24000
27000
30000
36000
VOLTS
TUBE
(V)
DIA (MM)
380
380
380
380
380
380
380
380
380
380
50
50
50
50
50
50
50
50
50
50
HORIZ.
(MM)
VERT.
LENGTH
(MM)
350
500
650
750
900
1050
1200
1350
1500
1600
The vertical
length is up
to customers'
needs.
Muti-tubes Z-shaped Metal Electric Immersion Heaters
1. Our muti-tubes Z-shaped metal electric immersion heaters are strictly made
of seamless metal tubes, in “Z” shape, stainless steel 304, stainless steel
316 and titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
5. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 21kw.
6. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
7. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Muti-tubes Z-shaped Metal Electric
Immersion Heater
WATTS
VOLTS (V)
(W)
6000
9000
12000
15000
18000
21000
380
380
380
380
380
380
HORIZ.
(MM)
VERT.
LENGTH
(MM)
500
600
700
800
900
950
The vertical
length is up
to customers'
needs.
Triple L-shaped Metal Electric Immersion Heaters
1. Our triple L-shaped metal electric immersion heaters are strictly made of
seamless metal tubes, in “L” shape, stainless steel 304, stainless steel 316
and titanium metal material available.
2. Power of the heaters is designed according to the installation location, liquid
chemical property and the deposition of the solid contents in liquid.
3. Hot-zone length of the heaters depends on the power of the heaters,
different power, hot-zone length different. And the cold-zone length is flexible, it
should be designed according to customers' equipment requests.
4. For safety design principle, the hot-zone of the heaters should be at least
100mm below the chemical liquid level.
5. With voltage of 110V/P, 220V/P, 380V/P, 220V/3P, 380V/3P, 415V/3P and
power range from 0.5kw to 12kw.
6. All heaters are matched with overheat protection switch of 95℃ or 105℃，
or matched with heat detector like PT100.
7. All heaters are CE certified, reaching the international standard, which
insure the reliability and service life.
Referential Specifications For Triple L-shaped Metal Electric Immersion
Heater
WATTS VOLTS
(W)
(V)
HORIZ.
(MM)
3000
380
450
6000
380
550
9000
380
700
12000
380
800
VERT.
LENGTH
(MM)
The vertical
length is up
to customers'
needs.
Spiral Vertical PTFE Electric Immersion Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Spiral Vertical PTFE Electric Immersion Heaters Applications:











Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating
Dyeing
Referential Specifications For Spiral Vertical PTFE Electric Immersion
Heaters
HOT
OVERALL
WATTS VOLTS
ZONE
LENGTH
(W)
(V)
(MM)
(MM)
1000
2000
3000
4000
5000
6000
220/380
220/380
220/380
220/380
220/380
380
180
310
420
520
640
750
430
560
670
770
890
1000
Spiral L-shaped PTFE Electric Immersion Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Spiral L-shaped PTFE Electric Immersion Heaters Applications:











Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating
Dyeing
Referential Specifications For Spiral L-shaped PTFE Electric Immersion
Heaters
VERT.
WATTS VOLTS
HORIZ.
LENGTH
(W)
(V)
(MM)
(MM)
1000 220/380
180
The vertical
2000 220/380
310
length is
3000 220/380
420
up to
4000 220/380
520
customers'
5000 220/380
640
needs.
6000
380
750
Round Vertical PTFE Electric Immersion Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Round Vertical PTFE Electric Immersion Heaters Applications:











Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating
Dyeing
Referential Specifications For Round Vertical PTFE Electric Immersion
Heaters
WATTS VOLTS
(W)
(V)
HOTZONE
MAX OD
(MM)
2000
220/380
250
3000
220/380
280
4000
220/380
300
5000
220/380
350
VERT.
COLD-ZONE
(MM)
The vertical
length is up
to customers'
needs.
Vertical PTFE Electric Immersion Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Vertical PTFE Electric Immersion Heaters Applications:











Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating
Dyeing
Referential Specifications For Vertical PTFE Electric Immersion Heaters
WATTS
(W)
VOLTS
(V)
HOT
ZONE
(MM)
OVERALL
LENGTH
(MM)
3000
220/380
450
4000
220/380
500
5000
220/380
600
The vertical
length is
up to
customers'
needs.
Quadrate L-shaped PTFE Electric Immersion Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Quadrate L-shaped PTFE Electric Immersion Heaters Applications:











Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating
Dyeing
Referential Specifications
Immersion Heaters
WATTS VOLTS
(W)
(V)
For
Quadrate
HOT-ZONE
DIAMENSION
（MM）
3000
220/380
300*300*60
4000
220/380
400*400*60
5000
220/380
500*500*60
L-shaped
PTFE
VERT.
COLD-ZONE
(MM)
The vertical
length is up
to customers'
needs.
Electric
Muti-tubes Vertical PTFE Electric Immersion Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Muti-tubes Vertical PTFE Electric Immersion Heaters Applications:











Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating
Dyeing
Referential Specifications
Immersion Heaters
For
Muti-tubes
Vertical
WATTS
(W)
VOLTS
(V)
HOT
ZONE
(MM)
OVERALL
LENGTH
(MM)
3000
4000
5000
6000
9000
12000
220/380
220/380
220/380
220/380
220/380
220/380
300
400
500
600
650
750
600
700
800
900
950
1050
PTFE
Electric
Muti-tubes L-shaped PTFE Electric Immersion
Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Muti-tubes L-shaped PTFE Electric Immersion Heaters Applications:










Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating

Dyeing
Referential Specifications For Muti-tubes L-shaped PTFE Electric
Immersion Heaters
WATTS VOLTS
(W)
(V)
HORIZ.
(MM)
3000
380
450
6000
380
520
9000
380
600
12000
380
700
VERT.
LENGTH
(MM)
The vertical
length is up
to customers'
needs.
Six Elements Vertical PTFE Electric Immersion
Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Six Elements Vertical PTFE Electric Immersion Heaters Applications:










Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating

Dyeing
Referential Specifications For Six Elements Vertical PTFE Electric
Immersion Heaters
WATTS
(W)
VOLTS
(V)
6000
380
HOT
ZONE
(MM)
750
OVERALL
LENGTH
(MM)
1000
Nine Elements Vertical PTFE Electric Immersion
Heater
1. Selecting high-quality SUS316 tube as heaters’core and PTFE tubes as outside cover. It could
be used to heat any chemical solution.
2. Low surface watt design (1.5w/cm2) to make sure a long lifetime.
3. The installation location of
PTFE heaters should pay attention to prevent deposition on its
surface or solution too tight. Sometimes PTFE tubes burnt out causing cold zone is too short (less
than 150mm).
4. PTFE heaters volume size is not allowed to be changed into small and small surface area, or it
could make the heaters surface power oversize and short the lifetime.
5. All PTFE heaters can be ancillary matched with temperature sensor (PT100) to make sure a long
term lifetime and keep the equipment safety.
6. PTFE tubes got excellent corrosion-resistant, so its widely used in oxidation of three polishing,
chemical gold plating, chemical silver plating, chemical nickel plating and varieties of high demand
solution.
7. PTFE heaters can be designed into Vertical- shaped, Spiral-shaped, L-shaped, U-shaped,
W-shaped, Coil-shaped, SPD combination-shaped and so on.
8. All PTFE heaters are certified by the CE Certification of EU Market and ISO9001:2008 quality
test.
Nine Elements Vertical PTFE Electric Immersion Heaters Applications:










Aqueous and semi-aqueous cleaning
Various corrosive fluid
Evaporation tanks
Chemical etching
Chemical mixing
Phosphatizing
Rinse tanks
Anodizing
Pickling
Plating

Dyeing
Referential Specifications For Nine Elements Vertical PTFE Electric
Immersion Heaters
WATTS
(W)
VOLTS
(V)
9000
10000
380
380
HOT
ZONE
(MM)
700
850
OVERALL
LENGTH
(MM)
1000
1100
Board Shape PTFE Electric Immersion
Heater
Board shape PTFE heater is invented by our company. As one of our patented
products, it owns high reputation in the line and is in great demand. It is resistant to
metal ions and corrosion. Also, it is not sticky, save, energy-saving and
environment-friendly. It is applicable to heat different corrosive liquids and can save
20% energy than other heaters of the same power.
Referential Specifications For Board Shape PTFE Electric Immersion
Heaters
WATTS (W)
VOLTS (V)
DIMENSION
(MM)
4500
6000
9000
12000
15000
24000
380
380
380
380
380
380
830*185*40
830*185*40
830*185*40
850*300*40
850*350*40
700*700*40
Coil-shaped
Heater
PTFE
Electric
Immersion
1. It is made of superior thermal fuses and covered with imported fluoroplastics.
2. It has strong resistance to different corrosive solutions.
3. It is not sticky, save, energy-saving and environment-friendly. It is applicable to
heat different corrosive liquids and can save 20% energy than other heaters of the
same power.
4. Low power is designed on the surface which insures service year of the product.
5. Attention should be paid on the location of the installation of electric heaters:
prevent solid contents sinking on the surface of the heater, or liquid too cohesive.
Also, if the water level is too low, it will lead to short circuit.
6. It can be matched with overheat protection switches or PT100 heat detector to
insure the service year and security of accessory.
7. It has passed the CE certification of EU market.
Referential Specifications For Coil-shaped PTFE Electric Immersion
Heaters
WATTS (W)
VOLTS (V)
DIMENSION
(MM)
3000
6000
9000
12000
380
380
380
380
260*50
350*110
350*150
350*180
