Post and lintel

advertisement
Universidad Simón Bolívar
Ingles II para Arquitectura y Urbanismo
ID2125
Prof. Carolina Lista
Andrea Merle 10-10456
Marielena de Jesús 10-10183
•Introduction
•Definition. Post and Lintel
•Post
•Lintel
•Advantages and Disadvantages
•Actual Uses
•Conclusion
There are many constructive methods
and techniques to build any space. Those
constructive systems determine and
characterize the environment which is
located and the personality and needs of
the people who will or are using that
space
In the following presentation we will be
talking about "post-and-lintel",
describing this method, it's advantages
and disadvantages as structural and
decorative elements.
•Simple construction method
•Upright members: posts, columns
or piers
•Hold a third member horizontally:
lintel, beam, girder or rafter.
•In this system acts two forces,
compression and tension.
•Post and lintel constructionpieces must fit together exactly.
•Support the lintel
•Failure caused because excessive weakness or lenght
•Material must be strong in compression
•Stone, Iron, Steel and Reinforced Concrete
•Brick highly efficient, and monolithic stone columns.
•Has to be able to support without crushing or breaking.
•Bear the loads that rest on it
•Failure: Material is too weak or too long
•Materials
•weak in bending: must be short. (Stone)
•Strong in bending: Bigger openings (Steel)
•Masonry Lintels are inefficient, but lintels of monolithic stone,
wood and stronger materials are employed.
•Has to be able to bear without deforming or breaking.
•Simplicity building time is
shorter.
•The walls to fill in between
the posts are prefabricated.
•Stability.
•The lintel will deform by sagging in
the middle
•Limited weight that can be held up.
•The small distances required
between the posts.
•It’s not nearly as common as
platform construction.
•The weight of each piece.
Nowadays, most post and
lintel construction has a third
component, the wall, which
adds additional support and
hides the post and lintel
design within the framework.
It can still be seen in
doorways and columns, in
which the space between the
vertical supports is open.
The Post and Lintel offered a solution
for constructive problems in the early
days, it allowed bigger and stronger
buildings to be constructed. Thanks to
its simplicity it is still used in modern
architecture and the construction
systems developed form it, helped us
shape the world we live in.
