ME23C19
INTEGRATED PRODUCT DESIGN AND
MANUFACTURING USING GD&T
ASSIGNMENT-1
SUBMITTED BYFAHADH A
BATCH-B
2023111301
PART A – TRUE / FALSE
1. One purpose of dimensions and tolerances is to define the manufacturing
setup.
Answer: False
2. Relationships between part surfaces should be defined based on their
function in the product.
Answer: True
3. The nominal size of a dimension is always the mean of the tolerance values.
Answer: False
4. Under ASME Y14.5, all dimensional limits are absolute.
Answer: True
5. A single feature control frame is required to have five or more compartments.
Answer: False
6. Basic dimensions are usually specified by enclosing the dimension in a
rectangle.
Answer: True
7. The sequence of listing notes indicates the importance of notes (1 is more
important than 4).
Answer: False
8. Using CAD models rather than an engineering drawing will eliminate most
sources of variation.
Answer: False
9. Dimensions are used to define size, location, orientation, and filtering of a part
feature or feature of size.
Answer: False
10. The two common linear units of measure are the decimal inch and the meter.
Answer: False
11. Coordinate tolerancing refers to tolerances verified with a coordinate
measuring machine (CMM).
Answer: False
12. There are four major shortcomings of using coordinate tolerancing.
Answer: True
13. An undefined measurement setup is one of the major shortcomings of
coordinate tolerancing.
Answer: True
14. Part acceptance disputes are one consequence of coordinate tolerancing.
Answer: True
15. The design philosophy of GD&T is to assign tolerances so that manufacturing
is economical.
Answer: True
16. One benefit of GD&T is that it improves communication.
Answer: True
17. GD&T eliminates the problem of tolerance accumulation through the use of
basic dimensions.
Answer: True
18. There are three major components of GD&T.
Answer: True
19. Geometric tolerances should be used whenever you want to increase
manufacturing costs.
Answer: False
PART B – MULTIPLE CHOICE QUESTIONS
1. Which areas of a company are most directly impacted by dimensions and
tolerances?
Answer: D. All of the above
2. Which is the correct means of using plus-minus tolerances to permit 0.6 mm
of variation?
Answer: D. All of the above
3. In the specification 20−0.2+0.420^{+0.4}_{-0.2}20−0.2+0.4, the value 20 is
known as the ______ value.
Answer: A. Nominal
4. Dimensions and tolerances are used to...
Answer: D. All of the above
5. Dimensions and tolerances may be related to a CAD model by:
Answer: D. Both A and B
6. Engineering drawing notes should be:
Answer: C. Expressed in the present tense
7. The proper use of zeros for plus/minus tolerances expressed in millimeters
requires:
Answer: D. All of the above
8. When inspecting a coordinate toleranced dimension, the measurement may
originate from ______.
Answer: D. All of the above
9. The use of coordinate tolerances for cylindrical holes results in ______
tolerance zones.
Answer: B. Rectangular
10. The fact that functional parts may be scrapped is the result of using...
Answer: B. Square-shaped tolerance zones
11. The "Great Myth of GD&T" is that...
Answer: D. GD&T raises part costs
12. Where coordinate tolerances are used to locate or orient features of size or
surfaces, the result may be...
Answer: C. Build (assembly) problems
13. GD&T uses a design philosophy that defines the...
Answer: C. Functional requirements of a part
14. The term "UNSAFE" applies to:
Answer: B. Coordinate tolerancing
15. GD&T eliminates the shortcoming of undefined measurement setup by using:
Answer: B. The datum system
