ENGR2140 (Spring 2026)
Sangster
Advanced SolidWorks Textbook
Certified SolidWorks Professional (CSWP) – Part 1
Due Monday, April 6 at 11:59 p.m.
Value: 15 points
These exercises took approximately: ___ hours
Deliverables: Submit a summary PDF document with screen captures of your work, as
well as any SolidWorks files you create in the process of completing these exercises.
Challenge 1. (15 points) Complete the exercise on pages 24-2 through 24-17.
Start with a new part file and save it as: “ENGR2140_Lastname_Challenge1.sldprt”
o Follow the instructions from the textbook walkthrough.
o Record the mass of the object as directed on page 24-10, 24-12, and 24-17.
o Take a screen capture of your work to add to a summary document.
Wrapping up your deliverable:
Compile all of your screen captures into a single PDF document (don’t forget to estimate
time spent) and submit the PDF along with the SolidWorks files you created this week.
