ESM 2204
Mechanics of Deformable Bodies
Mock Test 3
Last Name:
First Name:
Sign the following pledge:
I have neither given nor received unauthorized aid on this exam.
______________________________________________
Time allowed: 1h and 15 minutes
Documents are not allowed, but you may use one A4 formula sheet.
You should attempt to answer all questions. Problems are equally weighted
but their sub questions are not. Answer in the space provided. Extra sheets
are provided at the back.
Show all expressions and methods. Partial credit will be awarded for
incomplete/incorrect answers. Please put your final answers in boxes
3) A point on a structural member is subjected to the stresses indicated on the stress
element. Determine the principal stresses and maximum in-plane shear stress acting at
this point. Also give the orientations that these stresses occur at.
4) The pressure tank is fabricated from spirally wrapped metal plates that are welded at
the seams in the orientation shown. The tank has an inside diameter of 780 mm and a
wall thickness of 10.2 mm. For a gage pressure of 0.82 MPa, determine (a) the normal
stress perpendicular to the weld (use positive for tension, negative for compression) and
(b) the shear stress (absolute value) parallel to the weld. Assume β=55∘
5)
Use this extra space to complete questions if required. Be sure to clearly indicate the
question number.
