Project
ProNo.
Page
1
Item
PZ21_PV18
HALFEN HDB Punching Shear Reinforcement, ETA-12/0454 (Italy)
HALFEN Calculation Program HDB, version 13.71
HALFEN USA Inc. (part of Leviat), 4965 Eisenhauer Rd. Suite 101, TX 78218 San Antonio, Tel.: +1 210.585.9400, Fax: +1 877.683.4910
© Leviat GmbH, Langenfeld, Germany
The design - including the static values - does only apply to the designated HALFEN product. The load bearing capacity of third party products, appearing to be
identical in construction, might differ. For this reason, the software provider does not extend warranty if external products are used.
Proof of Punching Shear Resistance, circular corner column (In-situ concr.)
Applied factored load
Load increase factor
Slab thickness
Effective depth
Column diameter
Distance from Edge / Inclination
Distance from Edge / Inclination
Concrete cover top / bottom
Concrete grade / steel grade / HDB
Area of Reinforcement
Area of Reinforcement
Flexural reinforcement ratio
VEd
β
h
dm
Ø
c/α
e/α
cnom,o / cnom,u
asx
asy
ρ
at the control perimeter u1
Shape of the perimeter analogous to internal column
specific column perimeter
u0 / dm
u1
k = min { 1 + 200/d[mm] ; 2 }
Pre-factor for vRd,c,1
CRd,c
vRd,c,1 = CRd,c · k · (100 · l · fck ) 1/3
vRd,c,2 = vmin = 0.0525/ C · k 3/2 · fck 1/2
VRd,c = max {vRd,c,1 ; vRd,c,2 } · u1 · d = 508.3 kN < 517.5 kN = VEd ·
VRd,max = 1.96 · VRd,c = 996.3 kN > 517.5 kN = VEd ·
=
=
=
=
=
=
=
=
=
=
=
=
345.0 kN
1.50
30 cm
24.9 cm
60 cm
34.8 cm / 17 °
130 cm / 0 °
3.5 cm / 3.5 cm
C35/45 / BSt 500 / B500
10.05 cm²/m (ρx = 0.40 %)
10.05 cm²/m (ρy = 0.40 %)
0.40 % < 2.00 %
=
=
=
=
=
=
7.6
371 cm
1.90
0.12
550.24 kN/m²
540.67 kN/m²
at the outer perimeter uout
uout, req = 335.5 cm < 395.4 cm = uout, prov : Shape of the perimeter analogous to internal column
ls, req = 0 cm < 25.5 cm = ls, prov
/ (1.2 + · ls, prov /(15 · d)) ; 1.1 }
= 1.15
red = max {
Pre-factor for vRd,c,out,1
CRd,c,out
= 0.12
vRd,c,out,1 = CRd,c,out · k · (100 · l · fck ) 1/3
= 550.24 kN/m²
vRd,c,out,2 = vmin = 0.0525/ C · k 3/2 · fck 1/2
= 540.67 kN/m²
VRd,c,out = max {vRd,c,out,1 ; vRd,c,out,2 } · uout, prov · d = 541.7 kN > 397.3 kN = VEd · red
Stud diameter dA :
Section C :
Type chosen:
12 mm
12
inside :
outside :
20 mm
4
25 mm
3
Number of columns = 1
· fyd / = 666.7 kN > 517.5 kN = VEd ·
inner/outer element distance
16 mm
7
HDB-16/235-2/340
--
Number of combinations per column mC = 4
VRd,sy = mC · nC · dA ² / 4 ·
14 mm
9
( = 1.05)
= 28.4 cm / 28.7 cm
HDB 13.71
16/06/2025
Project
ProNo.
Page
2
Item
PZ21_PV18
HALFEN HDB Punching Shear Reinforcement, ETA-12/0454 (Italy)
HALFEN Calculation Program HDB, version 13.71
identical in construction, might differ. For this reason, the software provider does not extend warranty if external products are used.
Laying drawing
Section
Scale 1:24
1
30
8.5
8.5
23.5
3.5
17
25.5
1
4x 1x HDB-16/235-2/340
[cm]
Scale 1:32
62.9
Plan view
17°
y
x
cr=3
2
e =130
HALFEN USA Inc. (part of Leviat), 4965 Eisenhauer Rd. Suite 101, TX 78218 San Antonio, Tel.: +1 210.585.9400, Fax: +1 877.683.4910
© Leviat GmbH, Langenfeld, Germany
The design - including the static values - does only apply to the designated HALFEN product. The load bearing capacity of third party products, appearing to be
c = 34.8
Ø = 60
49.8
Minimum bar length: lbar,min,x = 169.5 cm + l bd ; lbar,min,y = 264.7 cm + l bd ; l bd is the anchorage length
Minimum bar length was determined according to booklet 600 (2nd edition 2020).
Note: Due to other verifications, different minimum bar length can be decisive.
Bar length calculated without the required design anchorage length at the free edge. The anchorage length at the free
edge has to be determined separately.
